174090-2 TE Connectivity / AMP Receptacle Terminal Housing, 1 Position
Short Description:
Manufacturer:TE Connectivity / AMP
Model Number:174090-2
Description: PL .250 (6.3 MM) HOUSING
Terminal Type : Receptacle
Connector & Housing Type : Plug
Primary Product Color :Black
Connector Mounting Type :Cable Mount (Free-Hanging)
Product Detail
Product Tags
Manufacturer:TE Connectivity / AMP
Model Number:174090-2
Product Type:Receptacle Terminal Housing (1 Position)
Color:Black
Key Features:High-temperature resistance, crimp termination, automotive-grade reliability
Housing Material:Nylon
Terminal Type:Socket (Female)
Termination Method:Crimp
Contact Size:6.35 mm (0.250")
Mounting Style:In-Line
Length:24.3 mm
Width:10.4 mm
Unit Weight:1.080 g
Series:250 FASTON
RoHS Compliance:Yes
Operating Temperature:-40°C to +130°C (typical for automotive applications)
Data Overview
| Terminal Type | Receptacle |
| Connector & Housing Type | Plug |
| Number of Positions | 1 |
| Terminal Orientation | Straight |
| UL Flammability Rating | UL 94V-2 |
Contact Features
| Connector System | Wire-to-Wire |
| Sealable | No |
| Connector & Contact Terminates To | Wire & Cable |
| Mating Alignment | With |
| Connector Mounting Type | Cable Mount (Free-Hanging) |
