2-1703498-3Automotive Connectors2 PositionHousing,Housing for Male TerminalsTE
Short Description:
2 Position Housing
Housing for Male Terminals
Wire-to-Wire
4 mm [.15 in] Centerline
Sealable
Gray
Wire & Cable
Power
MCON 1.2mm
Product Detail
Product Tags
The 2-1703498-3 is a sealed male connector housing from TE Connectivity's MCON Interconnection System, 2-position housing for male terminals with 4 mm (0.157 in) centerline spacing, optimized for 1.2 mm male pins.IP68-rated sealability against moisture, dust, and fluids, validated for -40°C to +130°C extreme automotive conditions.Gray PBT GF (glass-fiber reinforced polymer) housing with fuel/oil resistance.Wire-to-wire crimp interface supporting 10–12 AWG cables, with strain relief and keyed alignment for error-proof mating.25A current capacity and 14 VDC operating voltage for power circuits.Meets EU RoHS, ELV, and China RoHS 2.0 environmental standards.
Data Overview
| Connector & Housing Type | Housing for Male Terminals |
| Number of Positions | 2 |
| Sealable | Yes |
| Operating Temperature Range | -40 – 125 °C [ -40 – 257 °F ] |
| Number of Rows | 1 |
Contact Features
| Connector Shape | Rectangular |
| Mixed & Hybrid Connector | No |
| Primary Locking Feature | Locking Lance |
| Connector System | Wire-to-Wire |
| Connector & Contact Terminates To | Wire & Cable |
