63658-1 Magnet Wire Terminals MAG-MATE 300 Poke-In TE
Short Description:
Poke-In
.57 – .72 mm Aluminum Wire
20 – 18 AWG Lead Wire
.5 – .9 mm² Lead Wire
.45 – .64 mm Magnet Wire
MAG-MATE 300
Magnet Wire Terminals
Product Detail
Product Tags
The 63658-1 Magnet Wire Terminals by TE Connectivity, featuring the MAG-MATE 300 Poke-In design, are precision-engineered for reliable electrical connections in magnet wire applications. These terminals combine ease of use with robust performance to streamline wire termination processes across diverse industries.
Data Overview
| Magnet Wire Terminal Type | Poke-In |
| Compatible With Cavity Size | Size 2 |
| Aluminum Wire Size (mm) | .57 – .72 |
| Lead Wire Size (AWG) | 20 – 18 |
| Lead Wire Size (mm²) | .5 – .9 |
Contact Features
| Terminal Height | 7.62 mm [ .3 in ] |
| Magnet Wire Size (mm) | .45 – .64 |
| Magnet Wire Size (AWG) | 25 – 22 |
| Stock Thickness (Magnet Wire Side) | .41 mm [ .016 in ] |
| Product Length | 7.87 mm [ .31 in ] |
