7123-6327-80Wire Harness Connector 91 Connectors M-LC Type Housing 2P Female Yazaki
Short Description:
Product Model ：7123-6327-80
Brand：Yazaki
Connector Type：M-LC (Miniature Locking Connector)
Gender：Female (2P)
Housing Material：Thermoplastic (UL94-V0 flame retardant)
Current Rating ：5–10A
Voltage Rating：12V–24V
Product Detail
Product Tags
Model Number：7123-6327-80
Brand：Yazaki
Type：M-LC Type Housing 2P Female
Application：Automotive wiring harness systems
Contact Configuration：2P (2-position) Female
Tab Width：Likely 6.3mm (based on M-LC type standards)
Material (Housing)：Nylon66 or PBT
Temperature Range：-40°C to +120°C
Current Rating ：Estimated 10A–60A
Insulation Resistance：≥100MΩ at 500VDC
Withstanding Voltage：1000V AC
Data Overview
| Number of Poles | 2 |
| Allowable Current(Ref.) | 20A(Ref) |
| Insulation resistance | 100Megohm Min.(at 500VDC) |
| Withstand voltage | 1000V AC (1min.) |
| Materials | PBT |
Contact Features
| Classified Parts | Housing |
| Family | 91 Connector M-LC Type |
| Connection Type | Wire Harness Connector |
| Male/Female | Female |
| Unsealed/Seald | Unsealed |
Our advantage
● Brand supply diversification,
Convenient one-stop shopping
● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.
● Complete information, fast delivery
Reduce intermediate links
● Good after-sales service
Quick response, professional reply
● Original genuine guarantee
Support professional consultation
● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.
Product Display
