ATP04-2P-RD01Automotive Connectors 2-Way Receptacle Amphenol
Short Description:
ATP04-2P-RD01
2-Way Receptacle
Male
Reduced Diameter Seal
Comparable to PN# DTP04-2P-C015
Product Detail
Product Tags
The Amphenol ATP04-2P-RD01 is a high-performance 2-way automotive receptacle connector designed for reliability in harsh environments. Featuring vibration-resistant construction, IP67-rated sealing against dust/water, and an operational range of -40°C to +125°C, it ensures stable electrical connections for ECUs, sensors, and lighting systems. Its gold-plated phosphor bronze contacts support 5A current per circuit, while tool-free terminals enable 30% faster installation.
Data Overview
| Amperage | 25A |
| Wire Range |
12-14 AWG (4.0-2.0mm²) |
| Contact Size |
16 |
| Contact Type (Pin/Socket) | Socket |
| Dielectric Value | 1500V minimum |
Contact Features
| Housing Material | Thermoplastic |
| Insulation Resistance | 1000 megohms at 25°C |
| No. of Positions | 2-Way |
| Operating Temperature | -55°C to +125°C |
| Seal Diameter | 2.46mm(.097") - 4.01mm(.158") |
