HVSLS600082A116 2 Positions cable connector
Short Description:
Model number:HVSLS600082A116
Brand:Amphenol
Number of Positions:2
Gender:Plug (RP – Female)
Termination Style:Crimp
Contact Plating:Silver
Contact Material:Copper Alloy
Current Rating:120 A
Housing Material:Zinc Alloy
Product Detail
VEDIO
Product Tags
Amphenol HVSLS600082A116 2-Position CableConnector
Manufacturer：Amphenol Industrial
Series:HVSLS600
Part Number:HVSLS600082A116
Type:2-position wire-to-wire housing (non-sealed)
Color:Orange
Key Identifier:A-type keying
Mounting Style:Cable-mounted
Compliance:EN 60664-1
Current Rating :120A @120°C
Voltage Rating :36VDC
Contact Resistance :<5mΩ
Insulation Resistance:1000MΩ @500VDC
Dielectric Strength:1500VAC
Terminal Type:6.3mm female crimp contacts
Wire Compatibility:14-20 AWG (16 mm²)
Material:PBT GF10 (UL94 V-0 flame retardant)
Operating Temperature:-40°C to +125°C
Mating Cycles :50+ (with TPA engaged)
Dimensions:79.9mm (H) × 65mm (W) × 55.2mm (D)
Data Overview
| part category | male cable connector |
| gender | male |
| number of positions (w/o PE) | 2 |
| IP-class mated | IP69k |
| termination | crimp |
Contact Features
| coding position | A-coding |
| rated voltage | 1,000 V |
| rated current (40 °C) | 120 A |
| upper temperature | 125 GC |
| lower temperature | -40 GC |
