RTS6BS14N12S03 Conector circular estándar Plug 12 Position Amphenol
Short Description:
RTS6BS14N12S03 Plug
12 Position
Female,
Shell Size 14
Silicone Seal with Individual Wire Sealing
Product Detail
Product Tags
RTS6BS14N12S03 is a rugged circular plug connector from Amphenol SINE Systems, engineered for industrial automation, machinery control, and high-reliability applications requiring secure electrical connections in harsh environments.
Key Features & Specifications
Positions: 12-pin configuration without socket contacts, compatible with mating receptacles like RTS014N12P03.
Shell Size: Size 14 shell (diameter ≈30.6 mm), constructed from UL 94 V-0 flame-rated thermoplastic for safety and resilience.
Orientation: Straight plug with "N" keying for secure alignment.
Current/Voltage: Rated for 13A per contact and 350V AC/DC (or 500V AC/DC, depending on variant).
Environmental Protection: IP67-rated (dustproof/waterproof up to 1m immersion); some variants support IP69K for high-pressure washdown resistance.
Temperature Range: Operates from -40°C to +125°C, suitable for extreme industrial settings.
Durability: 500+ mating cycles for long-term reliability.
Data Overview
| Número de posiciones | 12 Position |
| Género del contacto | Socket (Female) |
| Tamaño de la carcasa | 14 |
| Estilo de montaje | Free Hanging |
| Estilo de terminación | Crimp |
Contact Features
| Tipo de accesorio | Plug |
| Clasificación IP | IP67, IP69k |
| Régimen de corriente | 13 A |
| Régimen de inflamabilidad | UL 94 V-0 |
| Indicador de cable | 26 AWG to 14 AWG |
