TE 2299284-3 DEUTSCH DT 3-Way Sealed Plug | Black Code C

Short Description:

Manufacturer: TE Connectivity / DEUTSCH
Part Number: 2299284-3
Series: DEUTSCH DT (Heavy Duty)
Number of Positions: 3 Position
Connector Type: Housing for Male Terminals (Tab)
Coding / Keying: Code C (Black)
Sealable: Yes (Integrated Silicon Seals)
Connector System: Wire-to-Wire
Primary Product Color: Black
Operating Temp: -55°C to +125°C (Extreme Range)
Ingress Protection: IP68, IP6K9K (High Pressure Wash Resistant)

Product Detail

Product Tags

Shop TE 2299284-3. A 3-position DEUTSCH DT series sealed housing for male terminals (Tab). Black, Code C keying, IP68 rated for heavy-duty industrial and automotive wire-to-wire connections.

Data Overview

Attribute Category	Technical Specification
Brand	TE Connectivity / DEUTSCH
Model	2299284-3
Connector Series	DT Series
Positions	3
Centerline (Pitch)	4.45 mm [.175 in]
Terminal Size	Size 16 (1.5mm)
Voltage Rating	250 VDC/VAC
Current Rating	13 Amps (Per Contact)
Body Material	PA 66 GF (Polyamide Glass Fiber)
Sealing Level	IP68 / IP6K9K
Mating Orientation	Straight / Inline
Weight	Approx. 7.5g

Product Details

Features & Technology	Engineering Advantages	Customer Strategic Benefits
Thermoplastic PA GF Housing	Rugged glass-filled polyamide body offers high impact and chemical resistance.	Ultimate Durability: Prevents housing cracks and degradation when exposed to hydraulic fluids, diesel, and salt spray in harsh environments.
Integrated IP68/IP6K9K Seal	Features a multi-lip internal seal that maintains integrity under high-pressure cleaning.	Total Circuit Security: Eliminates moisture-induced short circuits and corrosion, significantly reducing vehicle downtime and maintenance costs.
Distinctive Code C Keying	Specialized mechanical polarization (Keying) unique to the Black Code C version.	Zero Assembly Errors: Ensures correct mating in complex multi-harness systems, preventing costly equipment damage caused by accidental cross-connection.
Snap-Lock Mating Mechanism	Features a tactile and audible “click” when the connector is fully engaged.	Vibration-Proof Performance: Guarantees connection stability on heavy engine-mounted modules, preventing terminal fretting and signal loss.

Our advantage

● Brand supply diversification,
Convenient one-stop shopping

● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.

● Complete information, fast delivery
Reduce intermediate links

● Good after-sales service
Quick response, professional reply

● Original genuine guarantee
Support professional consultation

● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.

Q1: What are the required accessories for 2299284-3?

A: To complete the assembly, you need: 1. DEUTSCH Size 16 Male Terminals (Pins), and 2. A matching Wedgelock (W3P). The wedgelock ensures the pins are perfectly aligned and provides secondary locking.

Q2: What is the difference between 2299284-3 (Black) and other 3-pin DT plugs?

A: The “-3” and the Black color denote Code C Keying. This means it will only mate with a Code C receptacle. This prevents mis-plugging when multiple 3-pin connections are used in the same area.

Q3: Can 2299284-3 withstand steam cleaning?

A: Yes, the 2299284-3 is rated IP6K9K. This “K” rating means it can survive high-pressure, high-temperature washdowns (steam jets), which is standard for agricultural and construction equipment.
