SUMITOMO

  • 6180-2181 Sumitomo MT Sealed 2.3mm 2Way Female Housing | Direct Sourcing – SuQin

    6180-2181 Sumitomo MT Sealed 2.3mm 2Way Female Housing | Direct Sourcing – SuQin

    • Product Identity: Sumitomo Wiring Systems (SWS) MT Sealed Series (2.3mm / 090 Size), Part Number 6180-2181 (2-Way Inline Female Housing).

    • Technical Specs: 2 Positions (2Way), 1 Row, 2.3 mm [.090 in] Terminal Tab Width, Free Hanging In-Line Mount, Waterproof Sealed.

    • Ratings & Environment: ≥ 49.0 kPa Initial Seal Pressure (≥ 29.4 kPa Post-Durability) | ≤ 3 mΩ Contact Resistance | ≤ 100 μA Leak Current | ≥ 100 MΩ Insulation.

    • Material & Structure: Polybutylene Terephthalate (PBT) | Natural (White) | Dual Cylindrical Wire Seal Barrels with Shrouded Positive Latch.

    • B2B Sourcing: Direct RFQ processing, standard 100 pcs factory bag packaging (SWS), volume discount tiers, COC supported.

  • 6098-1104 Sumitomo TS Series 8.0mm 2Way Female Housing | Direct Sourcing – SuQin

    6098-1104 Sumitomo TS Series 8.0mm 2Way Female Housing | Direct Sourcing – SuQin

    • Product Identity: Sumitomo Wiring Systems TS Series (8.0mm / 312 Size), Part Number 6098-1104 (2-Way Inline Female Housing).

    • Technical Specs: 2 Positions (2Way), 1 Row, 8.0 mm [.312 in] Terminal Tab Width, Free Hanging In-Line Mount, Unsealed.

    • Ratings & Environment: ≤ 3 mΩ Initial Contact Resistance (≤ 10 mΩ Post-Durability) | ≥ 100 MΩ Insulation Resistance | ≤ 3 mA Leak Current.

    • Material & Structure: Polybutylene Terephthalate (PBT) | Natural (White) | Protected Positive Latch Lock with Dual-Cavity Guide Rails.

    • B2B Sourcing: Direct RFQ processing, standard 100 pcs factory bag packaging (SEWS-CT), volume tier discounts, COC supported.

  • 6188-5544 Sumitomo RS Series 8Way Male Housing | Direct Sourcing – SuQin

    6188-5544 Sumitomo RS Series 8Way Male Housing | Direct Sourcing – SuQin

    • Product Identity: Sumitomo Wiring Systems (SWS) RS Series, Part Number 6188-5544 (8-Position 2.3mm Male Connector Housing).

    • Technical Specs: 8 Positions, 2.3 mm (090) Terminal Size, Male Gender, STANDARD Type1 Design.

    • Ratings & Environment: Initial Sealing 98kPa Min (Post-test 98kPa Min) | Initial Contact Resistance 3mΩ Max | 100MΩ Min Insulation.

    • Material & Structure: Polybutylene Terephthalate (PBT) | Gray | Integrated Mating Latch & Mounting Bracket Retainer.

    • B2B Sourcing: Direct RFQ processing, standard 100 pcs bag packaging, volume discount tiers, Certificate of Compliance (COC) available.

  • Sumitomo 6189-7039 040 Series 4 Way Sealed Female Connector Housing

    Sumitomo 6189-7039 040 Series 4 Way Sealed Female Connector Housing

    • Product Identity: Sumitomo Electric 040 Series, Part Number 6189-7039.

    • Configuration: 4-way, dual-row (2×2 layout) socket housing for 1.0mm (.040) flat receptacle contacts on a 4.1 mm pitch and 5.2 mm row spacing.

    • Sealing & System: Single wire sealed (SWS) free-hanging wire-to-wire automotive connector equipped with a silicone rubber interface seal and separate TPA capability.

    • Material & Specs: Molded in black Polybutylene Terephthalate (PBT) thermoplastic; engineered for 0.30 to 1.25 mm² wire gauge ranges in harsh automotive sensor and actuator applications.

  • Sumitomo original 6098-0514 automotive connector sheath rubber shell in stock

    Sumitomo original 6098-0514 automotive connector sheath rubber shell in stock

    • Part Number & Series: Sumitomo Wiring Systems (SWS) | Part Number: 6098-0514 (60980514) | Series: Automotive Connector Series

    • Product Type & Circuit Layout: Wire-to-Wire / Wire-to-Board Receptacle Housing (Female Socket); 4-position (4POS / 4 Pin) configuration

    • Locking Mechanism & Sealing: Integrated positive locking latch mechanism; non-sealed (unsealed) housing structure

    • Material & Thermal Rating: Natural Polyamide 6/6 (PA66 / Nylon 6/6) resin; operating temperature range from -40°C to +125°C

    • Packaging & Availability: In-stock bulk packaging; accepts Sumitomo female crimp terminals; mates with corresponding Sumitomo 4POS male connector housings; RoHS compliant

  • 6189-1083 Sumitomo 6-Way Sealed Female Automotive Connector | Suqin

    6189-1083 Sumitomo 6-Way Sealed Female Automotive Connector | Suqin

    • Part Number & Brand: Sumitomo | Part Number: 6189-1083

    • Type & Layout: 6-Way (6-Position) Sealed Female Connector Housing Plug

    • Electrical Performance: Initial contact resistance ≤8 mΩ (≤16 mΩ after durability testing), leakage current ≤50 μA, insulation resistance ≥100 MΩ

    • Cable & Wire Compatibility: Designed for 16 AWG to 22 AWG automotive wire sizes

    • Housing Material & Protection: Black PBT (Polybutylene Terephthalate) housing, environmentally sealed for automotive wire harness applications

  • SUMITOMO 3 pins waterproof auto wire harness connector 6189-0099

    SUMITOMO 3 pins waterproof auto wire harness connector 6189-0099

    • Part Number & Series: Sumitomo 6189-0099 | TS Waterproof Series (2.3mm / 090 System)

    • Type & Mounting: 3-Position, 1-Row Male Connector Housing, Integrated 9 mm T-Type Bracket Fixation Structure

    • Terminal & Contact: Accepts 2.3 mm (.090 in) male tab terminals, initial contact resistance <= 3 mΩ (including crimp), post-durability resistance <= 10 mΩ

    • Sealing & Electrical Specs: Waterproof sealed design with initial leak test rating >= 50 kPa (post-durability >= 30 kPa), insulation resistance >= 100 MΩ, max leakage current 100 μA

    • Material & Color: Polybutylene Terephthalate (PBT) gray housing, engineered for automotive wire-to-wire and wire-to-bracket applications

  • Sumitomo 6099-0610 2-Way Automotive Connector Housing | Suqin

    Sumitomo 6099-0610 2-Way Automotive Connector Housing | Suqin

    • Manufacturer Identifiers: Manufactured by Sumitomo Electric Wiring Systems (SEWS) under Mfr. #: 6099-0610 and Part Name: US120A02MA-B3.

    • Structural Configuration: 2-position 1-row rectangular automotive connector housing engineered for wire-to-wire and inline wiring harness connections.

    • Material & Thermal Integrity: Molded from black PBT (Polybutylene Terephthalate) thermoplastic, offering mechanical durability, chemical resistance, and thermal stability in automotive environments.

    • Retention & Locking Mechanism: Features a pre-assembled white TPA (Terminal Position Assurance) secondary retainer to lock crimped terminals securely and prevent contact backing under high vibration.

    • Packaging & Supply: Supplied in standard original factory bulk bags containing 400 pieces per unit package (SEWS-CHZ).

  • Sumitomo 6189-0372 4-Pin Waterproof Female Connector Gray | Suqin

    Sumitomo 6189-0372 4-Pin Waterproof Female Connector Gray | Suqin

    • Genuine Sumitomo Series: Premium 4-pin waterproof automotive female connector housing with original factory part number 6189-0372.

    • Factory Designated Design: Officially designated under factory part name 11292W9A04F-GR, precision-molded in industrial Dark Gray.

    • Advanced Ingress Protection: Equipped with an internal high-performance silicone rubber seal to safeguard critical electrical contacts against fluid and humidity.

    • Integrated Terminal Positioning: Features a pre-installed white front-loaded retainer lock to ensure secure pin seating and prevent unexpected back-out.

    • B2B Supply & Sampling: Distributed by Suzhou Suqin in genuine industrial lot packaging of 100 pieces per bag, with sample support available for technical verification.

123456 Next > >> Page 1 / 11
