  • Molex MX150 Series 0334721206 12-Position Sealed Receptacle Housing | Suqin

    Molex MX150 Series 0334721206 12-Position Sealed Receptacle Housing | Suqin

    • Manufacturer & Series: Manufactured by Molex under the high-performance MX150 sealed connector family (Part Number: 0334721206 / Base Number: 033472).

    • Configuration & Pitch: Features a 12-position rectangular housing in a dual-row (2 x 6) layout with a 3.50 mm [0.138 in] centerline pitch.

    • Locking & CPA Security: Utilizes an integrated latch holder mechanism coupled with a red Connector Position Assurance (CPA) slide lock to prevent accidental unmating under high vibration.

    • Material Composition: Constructed from a rugged, glass-filled Polyamide and Syndiotactic Polystyrene alloy blend (PA/SPS-GF20) for enhanced dimensional stability and chemical resistance.

    • Mating & Contacts: Designed to accommodate MX150 female socket crimp terminals (sold separately) and mates with corresponding MX150 male blade housings (such as the 33482 series).

    detail
  • Molex Micro-Fit 3.0 0436450600 6-Position Receptacle Housing | Suqin

    Molex Micro-Fit 3.0 0436450600 6-Position Receptacle Housing | Suqin

    • Manufacturer & Series: Manufactured by Molex under the Micro-Fit 3.0 product family, belonging to the 043645 base product series with part number 0436450600.

    • Configuration & Layout: Features a 6-position single-row in-line configuration with a 3.00 mm (0.118 in) centerline pitch.

    • Locking Mechanism: Equipped with an integrated external passive latch lock mechanism to secure mechanical retention and prevent accidental unmating under physical stress.

    • Material Composition: Injection-molded from black thermoplastic polyester material, offering an operational temperature rating of -40°C to 105°C.

    • Mounting & Termination: Designed for free-hanging (in-line) cable wire harness assemblies, utilizing crimp termination methods for female socket contacts.



    detail
  • Molex MicroClasp 0513534000 40-Position Receptacle Housing | Suqin

    Molex MicroClasp 0513534000 40-Position Receptacle Housing | Suqin

    • Manufacturer & Series: Manufactured by Molex under the MicroClasp product family, belonging to the 051353 base product series with part number 0513534000.

    • Configuration & Layout: Features a high-density 40-position dual-row matrix layout with a 2.00 mm (0.079 in) centerline pitch and 5.00 mm (0.197 in) row-to-row spacing.

    • Locking Mechanism: Equipped with an integrated centralized external latch lock mechanism to secure structural retention against inadvertent demating under vibration.

    • Material Composition: Injection-molded from unsealed white Polyamide (PA66, Nylon 6/6) thermopolymer material offering a continuous operational temperature rating of -40°C to 105°C.

    • Mounting & Termination: Designed for free-hanging (in-line) cable wire harness assemblies, utilizing crimp termination methods for female socket contacts.

    detail
  • Molex Mini-Fit Jr. 0039012066 6-Position Panel Mount Plug Housing | Suqin

    Molex Mini-Fit Jr. 0039012066 6-Position Panel Mount Plug Housing | Suqin

    • Manufacturer & Series: Manufactured by Molex under the Mini-Fit Jr. product family, belonging to the 5559 series with base part number 003901.

    • Configuration & Layout: Designed as a 6-position dual-row (2 x 3 matrix) rectangular connector housing with a 4.20 mm (0.165 in) pitch and row spacing.

    • Mounting & Integration: Engineered for panel mounting applications featuring integrated snap-in ears for toolless, secure chassis installation.

    • Material & Flammability: Constructed from high-integrity Polyamide (PA66, Nylon 6/6) insulation polymer in an ivory color finish.

    • Mating & Security: Utilizes a positive locking ramp mechanism for secure connection with compatible mating receptacle housings.

    detail
  • Molex stAK50h 1600290013 27-Position Hybrid Receptacle Housing | Suqin

    Molex stAK50h 1600290013 27-Position Hybrid Receptacle Housing | Suqin

    • Manufacturer & Series: Manufactured by Molex within the stAK50h product family, designated under the 160029 base series with part number 1600290013.

    • Configuration & Layout: Features a hybrid rectangular 27-position matrix layout, partitioned into 19 dedicated signal channels and 8 dedicated power channels.

    • Mechanical Locking & Verification: Equipped with an integrated primary latch lock mechanism paired with a secondary Connector Position Assurance (CPA) component.

    • Material Composition: Injection-molded from glass-filled Syndiotactic Polystyrene (SPS) insulation polymer, finished in a blue housing color specification.

    • Mounting & Termination: Optimized for free-hanging (in-line) cable mounting configurations utilizing crimp contact termination methods for female sockets.

    detail
  • Molex Mini-Fit Jr. 39-01-2145 14-Position Receptacle Housing | Suqin

    Molex Mini-Fit Jr. 39-01-2145 14-Position Receptacle Housing | Suqin

    • Manufacturer & Series: Manufactured by Molex under the Mini-Fit Jr. product family, designated with part number 39-01-2145 within the 5557 series.

    • Configuration & Layout: Features a 14-position dual-row matrix layout with a 4.2 mm (0.165 in) centerline pitch and 4.2 mm (0.165 in) row-to-row spacing.

    • Electrical Capacity: Engineered to support power and signal applications with a maximum current rating of up to 13 A per circuit.

    • Material & Flammability: Molded from natural-colored nylon material achieving an industrial UL 94V-0 flammability rating for enhanced fire retardation.

    • Mechanical Mounting & Integrity: Designed for free-hanging (cable mount) configuration utilizing crimp termination methods for secure female socket contact retention.

    detail
  • Molex MX150 477259020 12-Position Panel Mount Male Plug Housing | Suqin

    Molex MX150 477259020 12-Position Panel Mount Male Plug Housing | Suqin

    • Manufacturer & Series: Manufactured by Molex under the MX150 product family, designated with part number 477259020 (alternate factory alias 0477259020) as a male plug crimp housing.

    • Configuration & Layout: Features a 12-position dual-row (2×6 grid) straight mounting angle layout with a 3.5 mm (0.138 in) centerline circuit pitch.

    • Mechanical Mounting: Engineered specifically for panel mount applications, incorporating an integrated mounting flange with Option B keying alignment for secure wire-to-wire power systems.

    • Material & Flammability: Molded from rugged light gray nylon thermopolymer material achieving a certified UL 94 V-0 flammability safety rating.

    • Wire Capability & Thermal Range: Supports a wire gauge range from 22 AWG minimum up to 14 AWG maximum, rated for stable operation across an environmental profile of -40°C to +125°C.

    detail
  • Molex 105308-1216 Nano-Fit TPA Receptacle Housing Dual Row 16 Ckt | Suqin

    Molex 105308-1216 Nano-Fit TPA Receptacle Housing Dual Row 16 Ckt | Suqin

    • Manufacturer and Series: Molex Nano-Fit 105308 Series, Part Number 105308-1216 (Aliases: 1053081216 / 01053081216).

    • Housing Type: Dual-row crimp receptacle housing with 16 circuits (positions), designed for straight wire-to-board applications.

    • Pitch and Spacing: Features 2.5 mm pitch and 2.5 mm row spacing for high-density electronic layouts.

    • TPA Integration: Compatible with optional Nano-Fit Terminal Position Assurance (TPA) retainers to secure terminals.

    • Electrical Ratings: Maximum current rating of 6.5A per circuit, compatible with socket (female) contact crimp terminals.

    • Material and Temperature: Molded from black Nylon meeting UL 94 V-0 flammability standards; operating range from -40 to +115 degrees Celsius.

    • Sourcing Availability: Factory-direct wholesale distribution via Suzhou Suqin with standard bulk packaging for tier-1 manufacturing supply chains.

    detail
  • Molex 5016461600 16-Pin iGrid 2.00mm Dual Row Receptacle Housing | Suqin

    Molex 5016461600 16-Pin iGrid 2.00mm Dual Row Receptacle Housing | Suqin

    • Brand Manufacturer: Molex

    • MPN (Part Number): 5016461600

    • Part Number Aliases: 501646-1600

    • Product Series: iGrid 501646 Series

    • Connector Type: Rectangular Connectors / Receptacle Housing

    • Total Position Count: 16 Position

    • Pitch Size: 2.00 mm (0.079 in)

    • Row Configuration: 2 Row (2 x 8 Grid Layout)

    • Row Spacing: 2.00 mm (0.079 in)

    • Mounting Configuration: Free Hanging (In-Line)

    • Termination Method: Crimp Terminal Integration

    • Contact/Housing Gender: Receptacle (Female Socket Cavities)

    • Locking Mechanism: Positive Latch Lock System

    • Insulation Material: Polyamide (PA66), Nylon 6/6

    • Operating Temperature Range: -40°C to +105°C

    • Standard Packaging: Bulk

    detail
