TE Connectivity MCON 1.2 Series 1-1564559-1 4-Pin Male Tab Housing | Suqin
Manufacturer & Series: Manufactured by TE Connectivity under the MCON 1.2mm product family, carrying the part number 1-1564559-1.

Configuration & Layout: Designed as a 4-position, single-row rectangular housing configured for male 1.2mm tab contacts.

Environmental Sealing: Features a sealable inline design supporting waterproof automotive wiring assemblies under harsh conditions.

Material Composition: Injection-molded from 30% glass-fiber reinforced Polybutylene Terephthalate (PBT GF30) in standard black, operational within temperatures from -40°C to 125°C.

Mating & Keying: Integrates mechanical Keying Code A and a primary locking lance feature for secure terminal retention and correct connector alignment.
inquiry detail
TE Connectivity VAL-U-LOK 1-794954-0 10-Position Receptacle Housing | Suqin
Manufacturer & Series: Manufactured by TE Connectivity under the VAL-U-LOK product family, designated with part number 1-794954-0 as a receptacle housing product type.

Configuration & Layout: Features a 10-position dual-row matrix configuration with a 4.2 mm (0.165 in) centerline pitch and matching row-to-row spacing.

Electrical Ratings: Engineered to support an operating voltage up to 600 VAC for concurrent power and signal circuit applications.

Material & Flammability: Molded from natural-colored nylon thermopolymer material achieving an industrial UL 94V-2 flammability rating.

Mechanical Mounting & Range: Designed for free-hanging (cable mount) termination utilizing crimp methods, compatible with insulation diameters ranging from 1.2 mm to 3.1 mm (0.047 in to 0.122 in).
inquiry detail
TE Connectivity 794954-2 2-Position VAL-U-LOK Receptacle Housing | Suqin
Manufacturer & Series: Manufactured by TE Connectivity under the VAL-U-LOK product family, designated with part number 794954-2 as a receptacle housing.

Configuration & Layout: Features a 2-position dual-row (2 x 1 grid) inline configuration with a 4.2 mm (0.165 in) centerline pitch and row-to-row spacing.

Electrical Ratings: Engineered to support an operating voltage up to 600 VAC for concurrent power and signal circuit applications.

Material & Flammability: Molded from natural-colored nylon thermopolymer resin achieving a standard UL 94V-2 flammability rating.

Mechanical Mounting & Range: Designed for free-hanging (cable mount) termination utilizing crimp methods, compatible with insulation diameters ranging from 1.2 mm to 3.1 mm (0.047 in to 0.122 in).
inquiry detail
TE Connectivity MCON 1.2 1-1718643-1 2-Position Automotive Plug Housing | Suqin
Manufacturer & Series: Manufactured by TE Connectivity under the MCON 1.2mm product series, designated with part number 1-1718643-1 as a sealed rectangular housing for female terminals.

Environmental Protection: Engineered with integrated high-performance environmental sealing verified to meet IPX4K and IPX9K ingress protection standards for harsh environments.

Electrical Architecture: Designed to support 12 V, 24 V, and 48 V nominal voltage power circuits with a continuous contact current capacity maxing out at 25 A.

Material & Layout: Molded from rugged PA66 GF30 (30% glass fiber reinforced polyamide 66) material with a 4 mm (0.157 in) centerline pitch.

Configuration & Mating: Features a single-row, 2-position cable mount (free-hanging) layout utilizing a locking lance primary retention feature and standard Keying Code A.
inquiry detail
TE Connectivity 1-2112891-4 36-Position Automotive Housing Blue | Suqin
Manufacturer & Type: TE Connectivity 36-position rectangular housing for male terminals, part number 1-2112891-4.

Application & Voltage: Designed for unsealed wire-to-wire automotive systems, supporting 12V / 24V nominal voltage architectures (36 VDC maximum).

Material Classification: Molded from blue PBT GF10 (glass fiber reinforced) thermoplastic with a UL 94HB flammability rating.

Locking & Retention: Equipped with an integrated primary locking mechanism and Terminal Position Assurance (TPA) for contact retention.

Pitch & Geometry: Features a 4 mm [.157 in] centerline pitch, 4.2 mm [.165 in] row-to-row spacing, and a 180° straight cable exit angle.
inquiry detail
Original TE Connectivity 1544334-1 2-Pin Automotive Male Housing | Suqin
Genuine TE Connectivity Component: 100% factory-original 2-position single-row automotive male housing (Part Number: 1544334-1) engineered for high-reliability wire-to-wire power connections.

Heavy-Duty 8mm Contact Channel: Purpose-built to house massive 8mm wide male mating tabs with an expanded 12mm centerline pitch for maximum high-current circuit isolation.

Glass-Filled PBT Engineering: Molded from premium, rugged glass-filled Polybutylene Terephthalate rated at UL 94HB, ensuring excellent dimensional stability inside harsh engine bays.

Integrated Dual-Lock Security: Outfitted with a heavy-duty built-in housing lock reinforced by a factory-installed yellow Terminal Position Assurance (TPA) mechanism to prevent terminal back-out.

Authorized B2B Channel Supply: Distributed directly by Suzhou Suqin for 12V nominal vehicle platforms and hybrid power links, offering full traceability and rapid technical sampling.
inquiry detail
TE 282090-1 6-Pin AMP Superseal 1.5mm Female Housing | Suqin
Genuine AMP Superseal 1.5mm Series: Rugged 6-position waterproof automotive housing engineered for female receptacle contacts with original factory part number 282090-1.

IP67 Environmental Protection: Pre-equipped with a high-grade yellow silicone rubber perimeter seal ensuring dust-tight and watertight performance under harsh road conditions.

Heavy-Duty PA66 GF Matrix: Molded from robust glass-fiber reinforced polyamide 66 to deliver outstanding mechanical impact strength and thermal durability up to 125°C.

Power Circuit Optimization: Engineered with a wide 6mm centerline pitch supporting a high contact current capacity up to 14A for 12V, 24V, or 48V automotive electrical architectures.

B2B Procurement Support: Distributed by Suzhou Suqin for commercial wire-to-board, wire-to-device, and wire-to-wire harness systems, with rapid sampling available for design verification.
inquiry detail
TE 1-353908-0 10-Pin AMP Mini CT Receptacle Housing 1.5mm | Suqin
Genuine AMP Mini CT Series: Premium 10-position wire-to-board receptacle housing with original TE Connectivity part number 1-353908-0.

Compact 1.5mm Centerline Pitch: High-density single-row configuration engineered to maximize space efficiency on PCBs and inside compact terminal layouts.

Detent Mating Retention: Built with a precise mechanical detent lock structure to ensure secure mating integrity and prevent accidental pull-out under minor cable strain.

UL 94V-0 Nylon 66 Shroud: Molded from reliable flame-retardant white Nylon 66 material, supporting a stable working temperature environment from -30°C up to 105°C.

B2B Supply & Sampling: Sourced and distributed by Suzhou Suqin for commercial signal and power harness assemblies, with sample support available for engineering evaluations.
inquiry detail
TE 2-1718645-1 4-Pin MCON 1.2mm Female Housing Code B | Suqin
Genuine TE Connectivity MCON Series: Premium 4-pin sealed automotive female housing with original factory part number 2-1718645-1, engineered for high-performance MCON 1.2mm terminal systems.

Keying Code B Interface: Features a precision-molded mechanical keying configuration and integrated accent color sub-assembly to guarantee error-proof mating alignment.

Heavy-Duty Environmental Protection: Rated at strict IPX4K and IPX9K waterproof standards, utilizing an advanced sealing design to withstand high-pressure steam jet cleaning.

Robust PA66 GF30 Matrix: Molded from 30% glass-fiber reinforced polyamide to ensure exceptional structural rigidity and stable performance across an extended temperature range of -40°C to 130°C.

B2B Supply & Sampling: Distributed by Suzhou Suqin in standard industrial packages optimized for wire-to-board and wire-to-device power applications, with sample support available for harness design verification.
inquiry detail
