  • TE 206430-1 AMP CPC Shell Size 11 4-Pin Socket Receptacle | Suqin

    TE 206430-1 AMP CPC Shell Size 11 4-Pin Socket Receptacle | Suqin

    • Part Number & Brand: TE Connectivity AMP Connectors | Part Number: 206430-1

    • Product Series & Type: AMP Circular Plastic Connectors (CPC) Series 1 | Shell Size 11 Square Flange Receptacle Housing

    • Circuit & Gender Layout: 4-position reverse-gender configuration accepting Size 16 socket contacts; Keyed Polarization Code A alignment

    • Material & Flammability: Black thermoplastic nylon housing; UL 94V-0 flammability rated with non-shielded, unsealed construction

    • Thermal Limits & Mounting: Operating temperature range from -55°C to +105°C; panel-mount square flange with 5/8-24 UNEF-2A threaded coupling

  • TE 2-1564559-1 MCON 1.2mm 4 Pos Male Tab Housing Gray | Suqin

    TE 2-1564559-1 MCON 1.2mm 4 Pos Male Tab Housing Gray | Suqin

    • Part Number & Brand: TE Connectivity AMP Connectors | Part Number: 2-1564559-1

    • Product Series & Type: MCON 1.2mm Interconnection System | 4-Position 1-Row Housing for Male Terminals (Tab Housing)

    • Pitch & Keying Layout: 4.00mm (0.157″) centerline pitch; 1 x 4 contact matrix with Key Code B mechanical polarization

    • Material & Locking: Gray 30% glass-filled polybutylene terephthalate (PBT GF30) housing with locking lance primary retention and sealable interface

    • Thermal Limits & Mounting: Operating temperature range from -40°C to +125°C; free-hanging (in-line) wire-to-wire power and signal configuration

  • TE 2035170-1 Generation Y Receptacle Terminal 22-20 AWG Tin | Suqin

    TE 2035170-1 Generation Y Receptacle Terminal 22-20 AWG Tin | Suqin

    • Part Number & Brand: TE Connectivity | Part Number: 2035170-1

    • Product Series & Type: Generation Y Connector System | 0.64mm Clean Body Receptacle Terminal (Female Crimp Contact)

    • Wire Gauge & Mating Specs: 22 – 20 AWG (0.35 – 0.5 mm²); accepts 0.8mm W x 0.64mm T (.031″ x .025″) mating tabs with 1.5 – 1.85mm wire insulation diameter

    • Material & Plating: Stamped & formed copper alloy contact with tin (Sn) interface and crimp plating; 8A typical current rating

    • Thermal Limits & Features: Operating temperature range from -40°C to +125°C; F-crimp style, family seal compatible, SAE/USCAR-2 and USCAR-21 compliant

  • 172161-1 TE Connectivity Mini-Universal MATE-N-LOK 9 Pos Cap Housing | Suqin

    172161-1 TE Connectivity Mini-Universal MATE-N-LOK 9 Pos Cap Housing | Suqin

    • Part Number & Brand: TE Connectivity AMP Connectors | Part Number: 172161-1

    • Product Series & Type: Mini-Universal MATE-N-LOK Series | 9-Position 3-Row Panel Mount Cap / Receptacle Housing

    • Pitch & Grid Layout: 4.14mm (0.163″) centerline pitch; 4.14mm (0.163″) row spacing in a 3 x 3 contact matrix

    • Material & Locking: Natural Polyamide 6/6 (PA66) nylon housing with positive locking ramp mechanism and flexible snap-in panel mounting wings

    • Thermal Limits & Mounting: Operating temperature range from -20°C to +105°C; snap-in panel mount or free-hanging wire-to-wire configuration

  • TE 1-1827864-0 Dynamic D-1200 20 Position Receptacle Housing | Suqin

    TE 1-1827864-0 Dynamic D-1200 20 Position Receptacle Housing | Suqin

    • Part Number & Brand: TE Connectivity AMP Connectors | Part Number: 1-1827864-0

    • Product Series & Type: Dynamic D-1200 Series (D-1200D) | 20-Position 2-Row Receptacle Housing for Female Contacts

    • Pitch & Grid Layout: 2.50mm (0.098″) centerline pitch; 3.30mm (0.130″) row spacing in a 2 x 10 contact matrix

    • Material & Locking: Black glass-filled thermoplastic polyester housing with integrated center latch lock and “X” polarization keying

    • Thermal Limits & Mounting: Operating temperature range from -55°C to +105°C; free-hanging (in-line) crimp termination configuration

  • 1743636-2 TE Connectivity 36 Position Hybrid Female Housing | Suqin

    1743636-2 TE Connectivity 36 Position Hybrid Female Housing | Suqin

    • Part Number & Brand: TE Connectivity / AMP | Part Number: 1743636-2

    • Product Type & Architecture: 36-Position 5-Row Mixed & Hybrid Receptacle Housing for Female Terminals (Wire-to-Wire In-Line Connector System)

    • Contact Accommodation & Pitch: Accepts 1.6 mm (.063 in) and 2.8 mm (.11 in) receptacle contacts with 4 mm (.157 in) centerline pitch and row-to-row spacing

    • Material & Protection: Black glass-filled PBT housing with locking lance primary retention, sealable environmental protection, and UL 94HB flammability rating

    • Electrical & Thermal Limits: Rated for 12 VDC operating voltage architecture across operating temperatures from -40°C to 120°C (-40°F to 248°F)

  • 208652-1 TE Connectivity AMP CPC Shell Size 17 Sealing Cap | Suqin

    208652-1 TE Connectivity AMP CPC Shell Size 17 Sealing Cap | Suqin

    • Part Number & Brand: TE Connectivity / AMP | Part Number: 208652-1

    • Product Type & Accommodation: Sealing Cap / Protective Dust Cover for Shell Size 17 AMP Circular Plastic Connectors (CPC)

    • Material & Construction: Black thermoplastic housing body with internal elastomer sealing disk and metal bead chain retention lanyard

    • Thermal & Environmental Specs: Operating temperature range from -40°C to 80°C (-40°F to 176°F); provides environmental protection against dust and moisture ingress

    • Flammability Standard: Complies with UL 94V-1 flammability rating requirements

  • 5-103957-4 TE AMPMODU MTE 5-Position 2.54mm Receptacle Assembly | Suqin

    5-103957-4 TE AMPMODU MTE 5-Position 2.54mm Receptacle Assembly | Suqin

    • Part Number & Series: TE Connectivity AMPMODU MTE | 5-103957-4

    • Type & Configuration: 5-Position, 1-Row, 2.54 mm (.100 in) Centerline Receptacle Connector Assembly (Wire-to-Board, Free-Hanging)

    • Contact Specs & Rating: Phosphor Bronze Socket Contacts, 3 A maximum current rating, 600 VAC dielectric withstanding voltage, 15 mΩ max termination resistance

    • Wire Accommodation: Accepts 26 – 22 AWG (0.12 – 0.4 mm²) discrete wire or ribbon cable with maximum insulation diameter of 1.37 mm (.054 in) via Crimp or Insulation Displacement (IDC)

    • Housing & Standards: Black thermoplastic housing with positive latching and locking lance retention, UL 94V-0 flammability rating, certified to UL E28476 and CSA LR7189, operating temperature range -65 deg C to +105 deg C

  • 794894-1 TE Connectivity Mini-Universal MATE-N-LOK 2-Pin Plug | Suqin

    794894-1 TE Connectivity Mini-Universal MATE-N-LOK 2-Pin Plug | Suqin

    • Part Number & Series: TE Connectivity 794894-1 | Mini-Universal MATE-N-LOK Series

    • Type & Layout: 2-Position, 1-Row, 4.14 mm (.162 in) Pitch, Male Plug Housing (Free Hanging / In-Line)

    • Electrical & Flammability: 600 VAC/VDC operating voltage rating, UL 94V-0 rated natural PA 66/6 housing material

    • Sealing & Temp: Sealable design (supports wire & interface seals), -40 deg C to +90 deg C operating temperature range

    • Termination & Mating: Crimp termination; accepts Mini-Universal MATE-N-LOK socket contacts (sold separately)
