Automotive Plug AAUS01AS0-028K01-Pos Right Angle HV Connector | 2.8mm 1000V Plug
Short Description:
-
Product Series: AAUS (High Voltage Power System)
-
Full Model: AAUS01AS0-028K01
-
Contact Size: 2.8 mm (High-Efficiency Copper System)
-
Configuration: 1-Position, 90-Degree Right Angle
-
Rated Voltage: 1000V DC / 600V AC
-
Current Rating: 25A – 40A (Based on 2.5mm² – 6.0mm² wire)
-
Shielding: 360° Fully Shielded Shell
-
Ingress Protection: IP67, IP68 (Mated)
-
Keying/Coding: K01 (Specific Mechanical Keying)
-
Application: EV/HEV PDU, Battery Packs, Motor Controllers
Product Detail
Product Tags
Shop AAUS01AS0-028K01. A 1-position 90° right-angle high voltage connector with 2.8mm contacts. Supports 1000V DC, features 360° EMI shielding and IP67 rating for EV powertrain & PDU modules.
Data Overview
| Attribute Category | Technical Specification |
| Manufacturer | LOTES |
| Part Number | AAUS01AS0-028K01 |
| Circuit Number | 1 Position |
| Orientation | 90° Right Angle |
| Mating Contact Size | 2.8 mm Socket |
| Operating Voltage | 1000V DC Max |
| Dielectric Withstanding | 3000V AC (1 Minute) |
| Insulation Resistance | ≥ 1000 MΩ (at 500V DC) |
| Shell Material | PA66 + GF (High Temp Thermoplastic) |
| Contact Plating | Silver Plated (Superior Conductivity) |
| Sealing System | High-Grade Silicone Multi-Lip Seal |
| Operating Temperature | -40°C to +125°C |
| Durability | ≥ 50 Mating Cycles |
Product Details
| Engineering Features | Technical Advantages | Customer Benefits |
| 90° Low-Profile Elbow Design | Reduces the vertical installation height by more than 50% compared to straight plugs. | Extreme Space Optimization: Allows for much thinner housing designs in PDU and Battery modules, meeting the trend of vehicle light-weighting and miniaturization. |
| Integrated 360° Shielding Mesh | Provides complete coverage for EMI/RFI suppression through a low-resistance path. | Zero Interference: Ensures high-voltage pulses do not disrupt sensitive signal lines (like sensors or CAN-bus), guaranteeing the safety of the vehicle’s electronic brain. |
| Dual-Action CPA (Connector Position Assurance) | Features a secondary red locking latch to confirm full mating engagement. | Vibration-Proof Safety: Prevents connector loosening even under extreme road shock (G-force), eliminating the risk of electrical arcing and vehicle breakdown. |
| Visual & Mechanical Keying (K01) | Utilizes specific “K01” keying slots and color-coded shells (Orange/Natural). | Eliminate Assembly Errors: Ensures that only correct circuits are mated during complex harness installation, preventing costly hardware damage from accidental cross-connection. |
Our advantage
● Brand supply diversification,
Convenient one-stop shopping
● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.
● Complete information, fast delivery
Reduce intermediate links
● Good after-sales service
Quick response, professional reply
● Original genuine guarantee
Support professional consultation
● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.
Q1: What is the recommended cable size for the AAUS01AS0-028K01?
A: This model is designed for high-voltage automotive-grade shielded cables. For typical 25A – 40A applications, we recommend using 2.5mm² to 6.0mm² cables. Please ensure you select the matching 2.8mm terminal based on your specific wire gauge.
Q2: Is AAUS01AS0-028K01 fully compatible with PowerLok series?
A: Yes, the AAUS01AS0-028K01 is engineered to be fully intermateable with standard PowerLok 1-pos 2.8mm headers. It follows the same mechanical keying and electrical protocols, making it an ideal drop-in replacement or component for EV charging and power modules.
Q3: Can this connector be used in an unsealed environment?
A: While the connector is rated for IP67/IP68 (when mated), its design is specifically for high-reliability environments where moisture and dust resistance are required. If used in a completely open environment, we recommend using a protective backshell or heat-shrink tubing to ensure the wire-entry point remains sealed.
