DEUTSCH

  • DEUTSCH DT06-12SA-EP08 DT Series 12 Position Plug Housing

    DEUTSCH DT06-12SA-EP08 DT Series 12 Position Plug Housing

    • Product Identity: TE Connectivity / DEUTSCH DT Series, Part Number DT06-12SA-EP08 (Modification EP08).

    • Configuration: 12-position, dual-row (2×6 layout) plug housing designed for socket (female) contacts on a 4.44 mm (0.175 in) centerline pitch.

    • Sealing & Features: Sealable design incorporating enhanced seal retention and an integrated end cap (-EP08 modification) for superior wire bundle support and IP68/IP6K9K environmental protection.

    • Material & Specs: Molded in black Polyamide Glass Filled (PA GF / PA66-GF15); rated for 250 VAC/DC, 13A per circuit (Size 16), and operating temperatures from -55°C to +125°C.

  • DEUTSCH DTP06-2S 2-Pin 25A Female Connector Housing | Suqin

    DEUTSCH DTP06-2S 2-Pin 25A Female Connector Housing | Suqin

    • Part Number & Series: DEUTSCH | Part Number: DTP06-2S (DTP Series)

    • Product Type & Circuit Layout: 2-Way Wire-to-Wire Plug Housing for Female Socket Terminals; 1-row x 2-position configuration

    • Electrical & Contact Rating: Accommodates Size 12 socket contacts (2.39 mm mating pin diameter); rated for 25 A max per contact up to 200 VAC/VDC

    • Material & Environmental Protection: Glass-filled polyamide (PA GF) body in gray; IP68 and IP6K9K protection rating with integrated rear N-seal grommet

    • Mounting & Dimensions: Free-hanging (in-line) mounting with integrated primary housing lock; 6.7 mm pitch; 34.6 mm H x 18.6 mm W x 18.6 mm L

  • DEUTSCH DT04-12PB 12-Pin Automotive Receptacle Housing | Suqin

    DEUTSCH DT04-12PB 12-Pin Automotive Receptacle Housing | Suqin

    • Part Number & Series: DEUTSCH | Part Number: DT04-12PB (DT Series)

    • Product Type & Circuit Layout: 12-Way Wire-to-Wire Housing for Male Terminals; 2-row x 6-position grid

    • Electrical & Contact Rating: Accommodates Size 16 pin contacts (1.59 mm pin diameter); rated for 13 A max per contact up to 250 VAC/VDC

    • Material & Environmental Protection: Glass-filled polyamide (PA GF) body in black; IP68 and IP6K9K protection rating with rear wire sealing grommet

    • Keying & Mounting: Key Code B polarization; free-hanging (in-line) mounting architecture with integrated housing primary lock

  • DTP04-2P TE Connectivity DEUTSCH DTP Series 2-Pin Receptacle | Suqin

    DTP04-2P TE Connectivity DEUTSCH DTP Series 2-Pin Receptacle | Suqin

    • Part Number & Series: TE Connectivity DEUTSCH DTP04-2P | DEUTSCH DTP Series

    • Type & Layout: 2-Position, 1-Row, 6.71 mm (.264 in) Pitch, Receptacle Housing for Male Pin Terminals (Free-Hanging / In-Line)

    • Current & Contacts: Accommodates Size 12 Pin Contacts (2.4 mm / .094 in mating pin dia.), 25 A maximum current rating per circuit

    • Environmental Protection: IP68 and IP6K9K ingress protection ratings with N-Seal silicone rubber wire grommet and perimeter interface gasket

    • Material & Temp: Glass-filled polyamide (PA GF) gray housing, UL 94V-0 flammability rating, -55 deg C to +125 deg C operating temperature range

  • DEUTSCH DT Series DT06-12SA 12-Pin Gray Receptacle Housing | Suqin

    DEUTSCH DT Series DT06-12SA 12-Pin Gray Receptacle Housing | Suqin

    • Series & Manufacturer: Manufactured by TE Connectivity under the DEUTSCH DT product family, carrying the part number DT06-12SA.

    • Configuration & Layout: Designed as a 12-position, dual-row rectangular housing configured for female size 16 socket contacts.

    • Environmental Sealing: Rated to IP68 and IP6K9K ingress protection standards, featuring an integrated orange radial seal and a red-orange rear wire seal to prevent moisture and dust ingress.

    • Material Composition: Injection-molded from 15% glass-fiber reinforced Polyamide (PA66-GF15) in standard industrial gray, built to operate within a temperature range of -55°C to 125°C.

    • Mating & Retention Security: Features Keying Code A alignment to prevent mismatching and integrates housing latches compatible with secondary Terminal Position Assurance (Wedge Lock W12S, sold separately).

  • DT04-08PA DEUTSCH 8-Pin Receptacle | IP68/IP6K9K Waterproof Gray Housing

    DT04-08PA DEUTSCH 8-Pin Receptacle | IP68/IP6K9K Waterproof Gray Housing

    • Manufacturer: TE Connectivity / DEUTSCH

    • Part Number: DT04-08PA

    • Number of Positions: 8 Pin (2 Rows)

    • Connector Type: Receptacle (Housing for Male Pins)

    • Voltage Architecture: 12V, 24V, 48V (Up to 250V Max)

    • Ingress Protection: IP68 & IP6K9K (Waterproof & Steam Jet Resistant)

    • Operating Temp: -55°C to +125°C [-67°F to +257°F]

    • Keying Code: A (Gray)

    • Material: Glass Filled Polyamide (PA GF)

    • Standard Compliance: SAE J2030 (Heavy Duty Standards)

  • DT06-3S-P032 DEUTSCH 3-Pin Black Plug | IP68/IP6K9K Sealed Housing

    DT06-3S-P032 DEUTSCH 3-Pin Black Plug | IP68/IP6K9K Sealed Housing

    • Manufacturer: TE Connectivity / DEUTSCH

    • Part Number: DT06-3S-P032

    • Connector Type: Housing for Female Terminals (Plug)

    • Number of Positions: 3 Pin (2 Rows)

    • Housing Color: Black (Enhanced UV & Chemical Resistance)

    • Special Modification: P032 (Blocked Gasket for Enhanced Sealing)

    • Ingress Protection: IP68 & IP6K9K (Waterproof & Steam Jet Resistant)

    • Operating Temp: -55°C to +125°C [-67°F to +257°F]

    • Material: Glass Filled Polyamide (PA GF)

    • Mating Wedge Lock: W3S (Sold Separately)

  • DT06-12SC-EP06 DEUTSCH 12-Pin Green Plug | Keying Code C & Enhanced Seal

    DT06-12SC-EP06 DEUTSCH 12-Pin Green Plug | Keying Code C & Enhanced Seal

      • Manufacturer: DEUTSCH (TE Connectivity)

      • Part Number: DT06-12SC-EP06

      • Color / Keying: Green / Code C (Mechanical Polarization)

      • Modification Code: EP06 (End Cap + Enhanced Seal Retention)

      • Number of Positions: 12 Pin (Dual Row)

      • Contact Size: Size 16 (Rated 13 Amps)

      • Ingress Protection: IP68 & IP6K9K (Waterproof & Steam Jet Resistant)

      • Housing Material: PA GF (Glass Filled Polyamide)

      • Operating Temp: -55°C to +125°C [-67°F to +257°F]

      • Mating Wedge Lock: W12S (Sold Separately)

  • DT04-4P-E003 DEUTSCH 4-Pin Gray Receptacle | E003 End Cap & IP68

    DT04-4P-E003 DEUTSCH 4-Pin Gray Receptacle | E003 End Cap & IP68

    • Manufacturer: DEUTSCH (TE Connectivity)

    • Part Number: DT04-4P-E003

    • Modification Code: E003 (Integrated Protective End Cap)

    • Number of Positions: 4 Pin (Dual Row)

    • Connector Type: Housing for Male Terminals (Receptacle)

    • Primary Color: Gray

    • Contact Size: Size 16 (Mating Pin 1.59 mm)

    • Current Rating: 13 Amps (Max per circuit)

    • Environmental Rating: IP68, IP6K9K (Waterproof & Dustproof)

    • Operating Temp: -55°C to +125°C [-67°F to +257°F]

    • Mating Wedge Lock: W4P (Sold Separately)

123456 Next > >> Page 1 / 8
