TE Connectivity MCON 1.2 Series 1-1564559-1 4-Pin Male Tab Housing | Suqin
Manufacturer & Series: Manufactured by TE Connectivity under the MCON 1.2mm product family, carrying the part number 1-1564559-1.

Configuration & Layout: Designed as a 4-position, single-row rectangular housing configured for male 1.2mm tab contacts.

Environmental Sealing: Features a sealable inline design supporting waterproof automotive wiring assemblies under harsh conditions.

Material Composition: Injection-molded from 30% glass-fiber reinforced Polybutylene Terephthalate (PBT GF30) in standard black, operational within temperatures from -40°C to 125°C.

Mating & Keying: Integrates mechanical Keying Code A and a primary locking lance feature for secure terminal retention and correct connector alignment.
inquiry detail
Molex MX150 Series 0334721206 12-Position Sealed Receptacle Housing | Suqin
Manufacturer & Series: Manufactured by Molex under the high-performance MX150 sealed connector family (Part Number: 0334721206 / Base Number: 033472).

Configuration & Pitch: Features a 12-position rectangular housing in a dual-row (2 x 6) layout with a 3.50 mm [0.138 in] centerline pitch.

Locking & CPA Security: Utilizes an integrated latch holder mechanism coupled with a red Connector Position Assurance (CPA) slide lock to prevent accidental unmating under high vibration.

Material Composition: Constructed from a rugged, glass-filled Polyamide and Syndiotactic Polystyrene alloy blend (PA/SPS-GF20) for enhanced dimensional stability and chemical resistance.

Mating & Contacts: Designed to accommodate MX150 female socket crimp terminals (sold separately) and mates with corresponding MX150 male blade housings (such as the 33482 series).
inquiry detail
DEUTSCH DT Series DT06-12SB 12-Pin Black Receptacle Housing | Suqin
Series & Manufacturer: Manufactured by TE Connectivity under the DEUTSCH DT product family, carrying the part number DT06-12SB.

Configuration & Layout: Designed as a 12-position, dual-row rectangular housing configured for female size 16 socket contacts.

Environmental Sealing: Rated to IP68 and IP6K9K ingress protection standards, featuring an integrated orange radial seal and an orange rear wire seal to prevent moisture and dust ingress.

Material Composition: Injection-molded from glass-fiber reinforced Polyamide (PA GF) in standard industrial black, built to operate within a temperature range of -55°C to 125°C.

Mating & Retention Security: Features Keying Code B alignment to prevent mismatching and integrates housing latches compatible with secondary Terminal Position Assurance (Wedge Lock W12S, sold separately).
inquiry detail
DEUTSCH DT Series DT06-12SA 12-Pin Gray Receptacle Housing | Suqin
Series & Manufacturer: Manufactured by TE Connectivity under the DEUTSCH DT product family, carrying the part number DT06-12SA.

Configuration & Layout: Designed as a 12-position, dual-row rectangular housing configured for female size 16 socket contacts.

Environmental Sealing: Rated to IP68 and IP6K9K ingress protection standards, featuring an integrated orange radial seal and a red-orange rear wire seal to prevent moisture and dust ingress.

Material Composition: Injection-molded from 15% glass-fiber reinforced Polyamide (PA66-GF15) in standard industrial gray, built to operate within a temperature range of -55°C to 125°C.

Mating & Retention Security: Features Keying Code A alignment to prevent mismatching and integrates housing latches compatible with secondary Terminal Position Assurance (Wedge Lock W12S, sold separately).
inquiry detail
KET 090 II Series MG651026 2-Position Receptacle Housing | Suqin
Manufacturer & Series: Manufactured by KET (Korea Electric Terminal) under the 090 II product series with part number MG651026.

Configuration & Layout: Features a 2-position single-row layout configuration with a 4.00 mm center pitch and a mating tab width of 0.090 inches.

Locking & Assurance: Equipped with a housing lance primary locking mechanism and an integrated Terminal Position Assurance (TPA) system to prevent terminal back-out under vibration.

Material Composition: Injection-molded from unsealed, natural-colored Polybutylene Terephthalate (PBT) thermopolymer material.

Mating Compatibility: Directly mates with KET male housing MG641029 and accepts female socket contacts ST730675-3, ST730676-3, and ST730677-3.
inquiry detail
Molex Micro-Fit 3.0 0436450600 6-Position Receptacle Housing | Suqin
Manufacturer & Series: Manufactured by Molex under the Micro-Fit 3.0 product family, belonging to the 043645 base product series with part number 0436450600.

Configuration & Layout: Features a 6-position single-row in-line configuration with a 3.00 mm (0.118 in) centerline pitch.

Locking Mechanism: Equipped with an integrated external passive latch lock mechanism to secure mechanical retention and prevent accidental unmating under physical stress.

Material Composition: Injection-molded from black thermoplastic polyester material, offering an operational temperature rating of -40°C to 105°C.

Mounting & Termination: Designed for free-hanging (in-line) cable wire harness assemblies, utilizing crimp termination methods for female socket contacts.
inquiry detail
Molex MicroClasp 0513534000 40-Position Receptacle Housing | Suqin
Manufacturer & Series: Manufactured by Molex under the MicroClasp product family, belonging to the 051353 base product series with part number 0513534000.

Configuration & Layout: Features a high-density 40-position dual-row matrix layout with a 2.00 mm (0.079 in) centerline pitch and 5.00 mm (0.197 in) row-to-row spacing.

Locking Mechanism: Equipped with an integrated centralized external latch lock mechanism to secure structural retention against inadvertent demating under vibration.

Material Composition: Injection-molded from unsealed white Polyamide (PA66, Nylon 6/6) thermopolymer material offering a continuous operational temperature rating of -40°C to 105°C.

Mounting & Termination: Designed for free-hanging (in-line) cable wire harness assemblies, utilizing crimp termination methods for female socket contacts.
inquiry detail
Molex Mini-Fit Jr. 0039012066 6-Position Panel Mount Plug Housing | Suqin
Manufacturer & Series: Manufactured by Molex under the Mini-Fit Jr. product family, belonging to the 5559 series with base part number 003901.

Configuration & Layout: Designed as a 6-position dual-row (2 x 3 matrix) rectangular connector housing with a 4.20 mm (0.165 in) pitch and row spacing.

Mounting & Integration: Engineered for panel mounting applications featuring integrated snap-in ears for toolless, secure chassis installation.

Material & Flammability: Constructed from high-integrity Polyamide (PA66, Nylon 6/6) insulation polymer in an ivory color finish.

Mating & Security: Utilizes a positive locking ramp mechanism for secure connection with compatible mating receptacle housings.
inquiry detail
Molex stAK50h 1600290013 27-Position Hybrid Receptacle Housing | Suqin
Manufacturer & Series: Manufactured by Molex within the stAK50h product family, designated under the 160029 base series with part number 1600290013.

Configuration & Layout: Features a hybrid rectangular 27-position matrix layout, partitioned into 19 dedicated signal channels and 8 dedicated power channels.

Mechanical Locking & Verification: Equipped with an integrated primary latch lock mechanism paired with a secondary Connector Position Assurance (CPA) component.

Material Composition: Injection-molded from glass-filled Syndiotactic Polystyrene (SPS) insulation polymer, finished in a blue housing color specification.

Mounting & Termination: Optimized for free-hanging (in-line) cable mounting configurations utilizing crimp contact termination methods for female sockets.
inquiry detail
