Lear E02430500 HC 6.3mm Receptacle Ultrasonic Terminal, Silver Plated
-
Product Identity: Lear Automotive HC Series, Part Number E02430500.
-
Configuration: 6.3 mm size female receptacle terminal with a right-angle ultrasonic weld design.
-
Wire Range & Termination: Supports cable cross-sections from 0.5 mm² to 16 mm² (20 AWG to 6 AWG) via ultrasonic weld connection technology.
-
Material & Specs: Constructed with a copper (Cu) core base and silver (Ag) plating; rated for extreme thermal conditions from -40°C to +170°C.
-
-

Molex 39-01-2040 Mini-Fit Jr. 4.2mm 4 Pin Receptacle Housing
-
Product Identity: Molex Mini-Fit Jr. 5557 Series, Part Number 39-01-2040 (Alias 0039012040 / 5557-04R).
-
Configuration: 4-position, 2-row (2×2 layout) female socket receptacle housing with 4.20 mm (0.165 in) pitch and row spacing.
-
Mounting & Retention: Cable mount / free-hanging wire-to-board and wire-to-wire connector with positive latching lock mechanism.
-
Material & Specs: Molded in natural UL 94V-2 nylon; rated for up to 13A current capacity, 600V rating, and operating temperatures from -40°C to +105°C.
-
-

DEUTSCH DT04-2P-CE03 2 Pin IP68 Black Male Pin Housing End Cap
-
Product Identity: TE Connectivity DEUTSCH DT Series, Part Number DT04-2P-CE03.
-
Configuration: 2-position, 1-row male pin connector housing with 5.46 mm (0.215 in) pitch and Size 16 contact cavities.
-
Sealing & Protection: Environmentally sealed with E Seal and End Cap modification, achieving IP68 and IP6K9K ingress protection ratings.
-
Material & Specs: Molded in black glass-filled polyamide (PA GF); rated for 13A current capacity, 250 VDC/VAC, and operating temperatures from -55°C to +125°C.
-
-

Molex 2145252021 Micro-Lock PLUS 1.25mm 2 Pin Plug Housing
-
Product Identity: Molex Micro-Lock PLUS 214525 Series, Part Number 2145252021.
-
Configuration: 2-position, 1-row male pin plug housing with 1.25 mm (0.049 in) pitch.
-
Mounting & Retention: Free-hanging inline wire-to-wire connector featuring an integrated positive locking ramp mechanism.
-
Material & Specs: Molded in black Polyamide (PA) nylon; rated for operating temperatures from -40°C to +105°C.
-
-

TE Connectivity 178289-7 Dynamic D3100 16 Pin 3.81mm Receptacle Housing
-
Product Identity: TE Connectivity Dynamic 3000 Series (D3100 Sub-series), Part Number 178289-7.
-
Configuration: 16-position, 2-row (2×8 grid) female socket receptacle housing with 3.81 mm (0.15 in) pitch and 5.08 mm (0.2 in) row spacing.
-
Mounting & Retention: Free-hanging inline wire-to-board connector featuring an integrated positive locking latch mechanism.
-
Material & Specs: Molded in black UL 94V-0 glass-filled polyester (Polyester GF); rated for power and signal applications across -55°C to +105°C.
-
-

TE Connectivity 770849-6 SL-156 6 Pin 3.96mm Receptacle Housing
-
Product Identity: TE Connectivity SL-156 Series, Part Number 770849-6.
-
Configuration: 6-position, 1-row female socket receptacle housing with 3.96 mm (0.156 in) centerline pitch.
-
Mounting & Retention: Free-hanging inline wire-to-board connector featuring an integrated locking ramp and polarization tabs.
-
Material & Specs: Molded in natural UL 94V-0 glass-reinforced nylon (Nylon GF); rated for 250 VAC, 6.5A current capacity, and operating temperatures from -55°C to +105°C.
-
-

TE Connectivity 1-1827864-4 Dynamic D1200D 8 Pin 2.5mm Key X Receptacle Housing
-
Product Identity: TE Connectivity Dynamic 1000 Series (D1200D Sub-series), Part Number 1-1827864-4.
-
Configuration: 8-position, 2-row (2×4 grid) female socket receptacle housing with 2.5 mm (0.098 in) pitch, 3.3 mm row spacing, and Key X polarization.
-
Mounting & Retention: Free-hanging inline wire-to-board connector featuring an integrated positive locking latch mechanism.
-
Material & Specs: Molded in black UL 94V-0 glass-filled polyester (Polyester GF); rated for 1A current capacity and operating temperatures from -55°C to +105°C.
-
-

Amphenol RTS6BS10N6SHEC03 ecomate 6 Pin IP67/IP69K Circular Plug Housing | Suqin
-
Product Identity: Amphenol Sine Systems ecomate® Aquarius™ Series, Part Number RTS6BS10N6SHEC03 (Base Model RTS6BS10).
-
Configuration: Shell size 10-6, 6-position circular plug housing designed for size 20 female socket crimp contacts with Normal (N) keying orientation.
-
Mating & Sealing: Free-hanging inline mounting with a 1/3-turn bayonet lock mechanism and integrated endcap backshell delivering IP67/IP69K waterproof ingress protection.
-
Material & Specs: Molded in black UV-resistant UL 94 V-0 thermoplastic; operating temperature range -40°C to +125°C for harsh industrial outdoor environments.
-
-

TE AMP 211770-2 19 Pin CPC Shell Size 23 Circular Plug Housing | Suqin
-
Product Identity: TE Connectivity AMP Circular Plastic Connectors (CPC) Series 1, Part Number 211770-2.
-
Configuration: Shell Size 23, 19-position straight circular plug housing designed for female socket contacts in standard (non-reverse) gender arrangement.
-
Mating & Coupling: Free-hanging (in-line) wire-to-wire mounting equipped with Key A polarization and a 1-3/8 – 18 UNEF-2A threaded coupling ring.
-
Material & Specs: Molded in black UL 94V-0 thermoplastic; 600 VAC/VDC voltage rating; operating temperature range -55°C to +105°C for power and signal applications.
-
