  • TE Connectivity 2-1418883-1 LEAVYSEAL 62 Position Receptacle Housing Key B

    TE Connectivity 2-1418883-1 LEAVYSEAL 62 Position Receptacle Housing Key B

    • Product Identity: TE Connectivity LEAVYSEAL Series, Part Number 2-1418883-1 (Keying Code B).

    • Configuration: 62-position mixed and hybrid receptacle housing featuring a multi-row layout (3 | 4 rows) with 4 mm and 5 mm centerline pitches.

    • Sealing & Interface: Sealable wire-to-board, wire-to-device, and wire-to-wire automotive connector system with a yellow locking lever assist, 90° cable exit strain relief, and IP67/IP69K rating.

    • Material & Specs: Molded in gray glass-filled PBT thermoplastic (UL 94HB); rated for 36 VDC, supporting 1.5K and 2.8mm contact sizes (up to 40A max current), operating from -40°C to +120°C (Max +140°C).

  • TE Connectivity 1-1823440-3 LEAVYSEAL 22 Position Receptacle Housing

    TE Connectivity 1-1823440-3 LEAVYSEAL 22 Position Receptacle Housing

    • Product Identity: TE Connectivity LEAVYSEAL Series, Part Number 1-1823440-3.

    • Configuration: 22-position mixed and hybrid receptacle housing featuring a multi-row layout (3 | 4 rows) with 4 mm and 6 mm centerline pitches.

    • Sealing & Interface: Sealable wire-to-wire automotive connector system equipped with a red slide lock mechanism, 90° cable exit strain relief, and primary locking features.

    • Material & Specs: Molded in black PBT GF30 thermoplastic; rated for 42 VDC, supporting 1.5K and 2.8mm contact sizes (up to 20A and 32A), with IP67/IP69K environmental protection and operating temperatures from -40°C to +120°C.

  • DEUTSCH DT06-12SA-EP08 DT Series 12 Position Plug Housing

    DEUTSCH DT06-12SA-EP08 DT Series 12 Position Plug Housing

    • Product Identity: TE Connectivity / DEUTSCH DT Series, Part Number DT06-12SA-EP08 (Modification EP08).

    • Configuration: 12-position, dual-row (2×6 layout) plug housing designed for socket (female) contacts on a 4.44 mm (0.175 in) centerline pitch.

    • Sealing & Features: Sealable design incorporating enhanced seal retention and an integrated end cap (-EP08 modification) for superior wire bundle support and IP68/IP6K9K environmental protection.

    • Material & Specs: Molded in black Polyamide Glass Filled (PA GF / PA66-GF15); rated for 250 VAC/DC, 13A per circuit (Size 16), and operating temperatures from -55°C to +125°C.

  • TE Connectivity 1717112-2 0.64/025 Series 2.2mm 24 Position Receptacle Housing

    TE Connectivity 1717112-2 0.64/025 Series 2.2mm 24 Position Receptacle Housing

    • Product Identity: TE Connectivity 0.64/025 Connector System, Part Number 1717112-2.

    • Configuration: 24-position, dual-row (2×12 layout) receptacle housing designed for female terminals on a 2.2 mm (0.08 in) centerline pitch.

    • Mounting & System: Free-hanging (in-line) wire-to-wire automotive signal housing with integrated primary locking features.

    • Material & Specs: Molded in black Polybutylene Terephthalate (PBT) with UL 94HB flammability rating; rated for 12 VDC and operating temperatures from -30°C to +105°C.

  • JST SMR-10V-B SM Series 2.5mm 10 Position Receptacle Housing

    JST SMR-10V-B SM Series 2.5mm 10 Position Receptacle Housing

    • Product Identity: JST Sales America SM Series, Part Number SMR-10V-B.

    • Configuration: 10-position, single-row (1×10 layout) receptacle housing with a 2.50 mm (0.098 in) pitch designed for male pin contacts.

    • Mounting & Termination: Wire-to-wire connection system utilizing crimp termination compatibility for wire gauges from 28 AWG to 22 AWG.

    • Material & Specs: Molded in black Polyamide (PA) with a UL 94V-0 flammability rating; rated for 250 VAC/DC, 3A, and operating temperatures from -25°C to +85°C.

  • JST SMR-02V-B SM Series 2.5mm 2 Position Receptacle Housing

    JST SMR-02V-B SM Series 2.5mm 2 Position Receptacle Housing

    • Product Identity: JST Sales America Inc. SM Series, Part Number SMR-02V-B (Base Model SMR-02V).

    • Configuration: 2-position, single-row (1×2 layout) receptacle housing with a 2.50 mm (0.098 in) pitch for male pin contacts.

    • Mounting & Retention: Free-hanging (in-line) wire-to-wire mounting style featuring a positive arm latch lock mechanism for secure mating.

    • Material & Specs: Molded in black Polyamide 6 (PA6 Nylon 6); designed for crimp pin termination with operating temperatures ranging from -25°C to +85°C.

  • Molex 0936010449 GWconnect S-QD17 Female Insert, 10A 250V

    Molex 0936010449 GWconnect S-QD17 Female Insert, 10A 250V

    • Product Identity: Molex GWconnect S-QD Series, Part Number 0936010449 (Series 93601).

    • Configuration: 17-position plus Ground (17P+PE) female socket insert without contacts for heavy-duty industrial connectors.

    • Termination & Mating: Crimp termination design engineered to fit standard GWconnect heavy-duty connector enclosures and hoods.

    • Material & Specs: Molded from gray polycarbonate (PC) thermoplastic with UL 94V-0 flammability rating; rated for 10A, 250V, 4kV impulse voltage, and -40°C to +125°C operation.

  • TE Connectivity 206036-2 CPC Size 17-3 Pin Receptacle Housing

    TE Connectivity 206036-2 CPC Size 17-3 Pin Receptacle Housing

    • Product Identity: TE Connectivity AMP Circular Plastic Connectors (CPC) Series, Part Number 206036-2.

    • Configuration: 3-position, size 17 circular receptacle housing configured for pin contacts in a power wire-to-panel setup.

    • Mounting & Threading: Panel mount flange design featuring 15/16-20 UNEF-2A coupling threads and keyway mating alignment.

    • Material & Specs: Molded in black glass-filled polyamide (PA 6.6 GF) with UL 94V-0 flammability rating; rated for 600 VAC/VDC, 34A max current, and -55°C to +105°C operation.

  • Molex 90142-0014 C-Grid 2.54mm 14 Pin Receptacle Housing

    Molex 90142-0014 C-Grid 2.54mm 14 Pin Receptacle Housing

    • Product Identity: Molex C-Grid 90142 Series, Part Number 90142-0014 (Alias 0901420014).

    • Configuration: 14-position, 2-row (2×7 layout) female socket receptacle housing with 2.54 mm (0.100 in) pitch and row spacing.

    • Mounting & Termination: Cable mount / free-hanging straight wire-to-board connector utilizing crimp terminal contact retention.

    • Material & Specs: Molded in black Polyphenylene Oxide (PPO) thermoplastic rated UL 94V-0; operates reliably from -55°C to +105°C at up to 3A per circuit.
