Amphenol

  • Electronic components ：EX40306E12I 2.5MM² individually shielded cable Connector

    Electronic components ：EX40306E12I 2.5MM² individually shielded cable Connector

    • Model & Classification: EX series industrial heavy-duty connector component, part number EX40306E12I.

    • Environmental Protection: Engineered with a sealed interface meeting IP67/IP68 ingress protection standards when mated.

    • Material Composition: Manufactured from high-grade die-cast aluminum alloy (or ruggedized thermoplastic) with a chemical-resistant surface coating.

    • Temperature Range: Rated for continuous operation within a thermal architecture of -40°C to 125°C.

    • Termination & Interface: Supports multi-contact insertion with defined mechanical keying to prevent cross-mating in dense panel layouts.

    detail
  • Amphenol AT04-3P-PM05 3-Pin Panel Mount Receptacle Housing | Suqin

    Amphenol AT04-3P-PM05 3-Pin Panel Mount Receptacle Housing | Suqin

    • Manufacturer & Series: Amphenol Sine Systems AT Series (PanelMate™ subclass) receptacle housing, part number AT04-3P-PM05.

    • Mounting Configuration: Panel mount type with integrated mounting flange, factory-fitted environmental gasket, and built-in threaded inserts.

    • Position Layout: 1 row containing 3 positions designed for crimp contact termination using male pin contacts.

    • Material Specifications: Constructed from thermoplastic insulation material with an operational temperature rating of -55°C to 125°C.

    • Component Note: Housing shell only; mating pin contacts are sold separately depending on application wire gauge.

    detail
  • Amphenol AT04-6P-PM05 6-Pin Panel Mount Receptacle Gray | Suqin

    Amphenol AT04-6P-PM05 6-Pin Panel Mount Receptacle Gray | Suqin

    • Manufacturer & Series: Genuine Amphenol SINE Systems AT Series (PanelMate family) receptacle, part number AT04-6P-PM05.

    • Mounting Configuration: Flange mount receptacle with straight mounting angle, pre-installed environmental gasket, and mechanical threaded inserts.

    • Electrical Parameters: 6 positions arranged in 3 rows; rated for a maximum of 13A per contact with an insulation resistance of 1 GOhms.

    • Material & Environment: Gray thermoplastic (TP) housing engineered for operating temperatures from -55°C to 125°C.

    • Wire Accommodation: Accepts crimp termination for wire sizes ranging from 14 AWG to 20 AWG using size 16 male pin contacts.

    detail
  • Amphenol TSL-FRD08PL 8-Way Sealed Blue Receptacle Housing Assembly | Suqin

    Amphenol TSL-FRD08PL 8-Way Sealed Blue Receptacle Housing Assembly | Suqin

    • Brand Manufacturer: Amphenol (Amphenol Technology (ShenZhen) Co., LTD)

    • MPN (Part Number): TSL-FRD08PL

    • Product Series: SSL Series

    • Connector Component Type: Receptacle Assembly

    • Total Position Count: 8 Positions (8 WAY)

    • Primary Housing Color: Blue

    • Main Housing Material: NY 66 (Nylon 66), UL94V-0 Flame Retardant Rated

    • Allocation Block Material: High-Performance PBT

    • Overall Product Length: 49.0 ± 0.5 mm

    • Cross-Sectional Width: 21.5 ± 0.5 mm

    • Cross-Sectional Height: 18.5 ± 0.5 mm

    • Document Revision Status: Document No. TSL-FRD()P(), Rev. B

    • Primary Application Domains: Automotive Wire Harnesses, Industrial Automation, Heavy Machinery, Commercial Vehicle Electronic Systems

    detail
  • Amphenol TSL-FPD08SL 8-Way Sealed Blue Plug Connector Assembly | Suqin

    Amphenol TSL-FPD08SL 8-Way Sealed Blue Plug Connector Assembly | Suqin

    • Brand Manufacturer: Amphenol (Amphenol Technology (ShenZhen) Co., LTD)

    • MPN (Part Number): TSL-FPD08SL

    • Product Series: SSL Series

    • Connector Component Type: Plug Assembly

    • Total Position Count: 8 Positions (8 WAY)

    • Primary Housing Color: Blue

    • Main Housing Material: NY 66 (Nylon 66), UL94V-0 Flame Retardant Rated

    • Inner Gasket Material: Silicon Rubber Moisture Seal

    • Protection Cap Material: High-Performance PBT

    • Overall Product Length: 35.0 ± 0.5 mm

    • Cross-Sectional Width: 23.0 ± 0.5 mm

    • Cross-Sectional Height: 20.0 ± 0.5 mm

    • Document Revision Status: Document No. TSL-FPD()S(), Rev. B

    • Primary Application Domains: Automotive Wire Harnesses, Industrial Control Systems, Marine Electronics, Commercial Vehicles

    detail
  • Amphenol TSL-FRD10PG 10-Way Sealed Gray Receptacle Housing Assembly | Suqin

    Amphenol TSL-FRD10PG 10-Way Sealed Gray Receptacle Housing Assembly | Suqin

    • Brand Manufacturer: Amphenol (Amphenol Technology (ShenZhen) Co., LTD)

    • MPN (Part Number): TSL-FRD10PG

    • Product Series: SSL Series

    • Connector Component Type: Receptacle Assembly

    • Total Position Count: 10 Positions (10 WAY)

    • Primary Housing Color: Gray

    • Main Housing Material: NY 66 (Nylon 66), UL94V-0 Flame Retardant Rated

    • Allocation Block Material: High-Performance PBT

    • Overall Product Length: 49.0 ± 0.5 mm

    • Cross-Sectional Width: 21.5 ± 0.5 mm

    • Cross-Sectional Height: 18.5 ± 0.5 mm

    • Document Revision Status: Document No. TSL-FRD()P(), Rev. B

    detail
  • Amphenol TSL-FPD10SG 10-Way Sealed Gray Plug Assembly | Suqin

    Amphenol TSL-FPD10SG 10-Way Sealed Gray Plug Assembly | Suqin

    • Brand Manufacturer: Amphenol

    • MPN (Part Number): TSL-FPD10SG

    • Product Series: SSL Series

    • Connector Component Type: Plug Assembly

    • Total Position Count: 10 Positions

    • Primary Housing Color: Gray

    • Main Housing Material: NY 66 (Nylon 66), UL94V-0 Rated

    • Inner Gasket Material: Premium Silicon Rubber

    • Protection Cap Material: High-Performance PBT

    • Key Dimensions: 35.0 ± 0.5 mm / 23.0 ± 0.5 mm

    • Ingress Protection: Environmentally Sealed / Waterproof

    detail
  • Amphenol TSL-FPD10SB 10-Pin Sealed Female Automotive Connector Plug | Suqin

    Amphenol TSL-FPD10SB 10-Pin Sealed Female Automotive Connector Plug | Suqin

    • Brand Manufacturer: Amphenol

    • MPN (Part Number): TSL-FPD10SB

    • Product Series: TSL Series

    • Connector Type: Receptacle / Plug Housing

    • Total Position Count: 10 Positions

    • Contact Gender: Female Socket

    • Housing Material: Impact-Resistant Engineering Thermoplastic

    • Primary Product Color: Industrial Black

    • Ingress Protection: Environmentally Sealed / Waterproof

    • Sealing Component: High-Visibility Orange Silicone Rubber O-Ring

    • Locking Mechanism: Heavy-Duty Integrated Snap-Lock Latch

    • Terminal Layout: Clear Numerical Cavity Markings (1 to 10)

    • Primary Applications: Automotive Electronics, Heavy Machinery, Marine Systems, Industrial Automation Sensors

    detail
  • Amphenol PT06E-14-18S(SR) MIL-DTL-26482 Series I 18-Pin Circular Plug | Suqin

    Amphenol PT06E-14-18S(SR) MIL-DTL-26482 Series I 18-Pin Circular Plug | Suqin

    • Brand Manufacturer: Amphenol Industrial Operations

    • MPN (Part Number): PT06E-14-18S(SR)

    • Base Series: PT Series (MIL-DTL-26482 Series I Standard)

    • Connector Configuration: Free Hanging (In-Line) Plug

    • Contact Gender: Female Sockets (18 Positions)

    • Shell Size & Insert Layout: 14-18 Matrix

    • Termination Method: Precision Solder Cup

    • Mating Coupling Type: 3-Point Quick Bayonet Lock

    • Housing Material & Finish: Aluminum with Olive Drab Chromate over Cadmium Plating

    detail
123456 Next > >> Page 1 / 35
