Amphenol

  • Amphenol ATBS-237-0405 AT Series 4-Pin Backshell Strain Relief | Suqin

    Amphenol ATBS-237-0405 AT Series 4-Pin Backshell Strain Relief | Suqin

    • Part Number & Brand: Amphenol SINE Systems | Part Number: ATBS-237-0405

    • Product Type & Series: AT Series Accessories | 4-Position Straight Cable Backshell

    • Compatibility & Gender: Designed for Amphenol AT Series 4-way receptacle (female) connector housings

    • Material & Structure: Black high-grade Thermoplastic (TP); tool-less hinged clamshell design with dual snap-fit retention latches

    • Function & Cable Exit: Delivers mechanical wire strain relief, harness bundle protection, and straight (180°) conduit adapter routing

  • HVC2P28FS102 Amphenol HVC Series 2-Pin 900V 40A EV High-Voltage Connector | Suqin

    HVC2P28FS102 Amphenol HVC Series 2-Pin 900V 40A EV High-Voltage Connector | Suqin

    • Part Number & Series: Amphenol HVC Series | Part Number: HVC2P28FS102 (HVC2P28 Sub-series)

    • Type & Orientation: 2-Position (2-Core) Straight Plastic High-Voltage EV Connector Assembly

    • Voltage & Current Rating: 900 V DC rated operational voltage, maximum continuous current capacity up to 40 A

    • Wire Accommodation: Compatible with conductor wire sizes ranging from 2.5 mm² to 5.0 mm²

    • Target Applications: Electric Vehicle (EV/HEV) On-Board Chargers (OBC), PTC Heaters, Electric Air Compressors, and auxiliary high-voltage power circuits

  • HVC2P63FS106: 2 POSITION PLUG HV LOOP EMC SHIELD Amphenol

    HVC2P63FS106: 2 POSITION PLUG HV LOOP EMC SHIELD Amphenol

    • Part Number & Series: Amphenol HVC2P63FS106 | HVC (High Voltage Connector) Series

    • Type & Circuit Layout: 2-Position, 1-Row High-Voltage Female Plug (Free Hanging / In-Line)

    • Voltage & Current Rating: 1000 V AC/DC (CAT III) operational voltage, 63 A continuous current capacity per contact

    • Cable Accommodation & Shielding: Designed for 6.0 mm² (10 AWG) shielded cable, integrated 360° EMC shield (>60 dB attenuation from 100 MHz to 1 GHz)

    • Material & Protection Specs: PBT + 30% Glass Fiber (UL94 V-0) housing, IP67 ingress protection rating (mated), operating temperature -40 deg C to +150 deg C

  • EX40302A Amphenol PCD EX Series 5-Pin Circular Receptacle Housing | Suqin

    EX40302A Amphenol PCD EX Series 5-Pin Circular Receptacle Housing | Suqin

    • Part Number & Series: Amphenol PCD Shenzhen EX40302A | EX Series

    • Connector Type & Mount: 5-Position Circular Receptacle Housing (For Male Pins), Flange / Panel Mount (Box Mount)

    • Locking & Shielding: Push-Pull Fastening Mechanism, 360° Shielded Metal Shell (Orientation A)

    • Shell Material & Finish: Aluminum Alloy with Zinc Nickel Plating (Silver Finish), Thermoplastic Insert (UL94 V-0)

    • Contact & Protection Specs: Accepts 1.6 mm and 3.0 mm Crimp Contacts (sold separately), IP68 / IP69K Ingress Protection, -40 deg C to +125 deg C operating range

  • HVSL282082D103I Amphenol HVSL282 2-Pin RA Plug Key D HVIL IP67 | Suqin

    HVSL282082D103I Amphenol HVSL282 2-Pin RA Plug Key D HVIL IP67 | Suqin

    • Model & Specs: Amphenol PCD HVSL282082D103I | 2-position, 1-row, right-angle wire exit sealed high-voltage plug connector kit (HVSL282 Series).

    • Electrical & Contacts: 1000 VDC rated voltage, 32 A max current (@ 70 deg C), integrated internal HVIL; terminates 2.5 mm2 individually shielded wire.

    • Material & Rating: Orange PA66+GF housing, copper alloy terminals, IP67 / IP6K9K (mated), IP2XB touch-proof, -40 deg C to +125 deg C operating range.

    • Mating & Process: Key D polarization, two-stage finger/thumb actuated latch with CPA; 360 deg wire-to-device shielding; USCAR-2 / USCAR-37 / LV-215 compliant.

  • T3325502U Amphenol C091 U 4-Pin Female Cable Connector | Suqin

    T3325502U Amphenol C091 U 4-Pin Female Cable Connector | Suqin

    • Manufacturer & Series: Part number T3325502U (C091 U family), manufactured by Amphenol Tuchel Industrial GmbH as a straight female cable connector.

    • Electrical Ratings: Configured with 4 silver-plated solder contacts rated for 300 V AC/DC and up to 10 A current capacity at 40 deg C ambient temperature.

    • Locking & Mechanical Design: Utilizes a quick-mating bayonet ring locking system for rapid and reliable coupling in unshielded industrial applications.

    • Cable Integration: Accommodates flexible cables with external diameters ranging from 6.0 mm to 8.0 mm, accepting wire gauges from 0.05 mm2 to 0.50 mm2.

    • Environmental & Protection Grade: Meets IP40 protection class when mated, with an operational temperature rating ranging from -40 deg C to +100 deg C.

  • HVSL364024A Amphenol PCD Excel|mate HVSL 364 4-Pin Box Mount Receptacle | Suqin

    HVSL364024A Amphenol PCD Excel|mate HVSL 364 4-Pin Box Mount Receptacle | Suqin

    • Manufacturer & Series: Part number HVSL364024A, engineered by Amphenol PCD Shenzhen as part of the Excel|mate HVSL 364 series.

    • Structural Configuration: 4-position, 2-row panel/box mount receptacle connector with a compact 2×2 grid arrangement.

    • Contact & Termination: Accommodates male pin contacts with tin finish, utilizing crimp termination for discrete wires ranging from 10 to 14 AWG.

    • Mechanical Locking & Mounting: Features a panel mount flange with perimeter sealing ring and a positive locking ramp mechanism for vibration-resistant retention.

    • Color & Application: Molded in high-visibility orange housing, designed for electric vehicle (EV) and industrial high-voltage power interconnect systems.

  • Amphenol HVC2P63FS104 | 2-Pole 40A High Voltage EV Connector | 1000V Shielded

    Amphenol HVC2P63FS104 | 2-Pole 40A High Voltage EV Connector | 1000V Shielded

    • Manufacturer: Amphenol (Excel-Mate HVC Series)

    • Part Number: HVC2P63FS104

    • Number of Positions: 2-Pole

    • Rated Current: 40A

    • Rated Voltage: 1000V DC

    • Wire Size: 4.0 mm²

    • Safety Feature: Integrated High Voltage Interlock (HVIL)

    • Shielding: 360° EMI/RFI Shielded

    • Protection Level: IP67, IP6K9K (Mated)

    • Operating Temp: -55°C to +125°C

    • Application: EV/HEV Power Distribution, OBC, Air Conditioning, PTC.

  • AT06-08SA-BLK 8-Way Plug Housing A-Key Female | Suqin

    AT06-08SA-BLK 8-Way Plug Housing A-Key Female | Suqin

    • Manufacturer & Cross-Reference: Part number AT06-08SA-BLK, an 8-way female plug housing designed as a direct comparable alternative to PN# DT06-08SA-EP07.

    • Structural Configuration: Features an A-Position Key design with a rectangular black thermoplastic housing, accommodating 8 size 16 socket contacts.

    • Electrical Ratings: Supports a continuous current capacity of 13A and a voltage rating of 250V, with a dielectric withstanding voltage showing less than 2mA leakage at 1500V AC.

    • Wire & Seal Integrity: Compatible with 14-20 AWG (2.0-0.5 mm2) wire ranges. Utilizes a silicone elastomer seal (2.24mm – 3.68mm diameter) with Enhanced Seal Retention (P012).

    • Environmental Endurance: Delivers IP68 (1 meter of water for 24 hours) and IP69K protection in mated conditions, operating reliably across a -55 °C to +125 °C temperature range.
