Amphenol HVC2P63FS104 | 2-Pole 40A High Voltage EV Connector | 1000V Shielded
Short Description:
-
Manufacturer: Amphenol (Excel-Mate HVC Series)
-
Part Number: HVC2P63FS104
-
Number of Positions: 2-Pole
-
Rated Current: 40A
-
Rated Voltage: 1000V DC
-
Wire Size: 4.0 mm²
-
Safety Feature: Integrated High Voltage Interlock (HVIL)
-
Shielding: 360° EMI/RFI Shielded
-
Protection Level: IP67, IP6K9K (Mated)
-
Operating Temp: -55°C to +125°C
-
Application: EV/HEV Power Distribution, OBC, Air Conditioning, PTC.
Product Detail
Product Tags
Shop original Amphenol HVC2P63FS104 2-pole high-voltage connectors at Suzhou Suqin. Rated for 40A/1000V with HVIL and 360° EMI shielding. IP67/IP6K9K waterproof for EV power systems.
Data Overview
| Attribute Category | Technical Specification |
| Brand | Amphenol |
| Model / PN | HVC2P63FS104 |
| Connector Type | Plug (2-Way) |
| Number of Poles | 2P |
| Operating Voltage | 1000V DC |
| Rated Current | 40A |
| Dielectric Strength | 3000V AC |
| Insulation Resistance | 1000MΩ (at 25°C) |
| Contact Resistance | < 10 mΩ |
| Operating Temperature | -55°C to +125°C |
| Ingress Protection | IP67, IP6K9K (Mated) |
| Mechanical Lifecycle | 100 Cycles |
| Primary Color | Orange (RAL 2003) |
| Compliance | RoHS Compliant |
Product Details
| Advanced HV Safety & Signal Integrity | High-Power Performance & Thermal Stability | Rugged Environmental Resilience |
| Integrated High Voltage Interlock (HVIL) | Features a dedicated secondary safety loop that monitors the connection status in real-time. | Risk Mitigation: Prevents high-voltage arcing during accidental disconnection, ensuring operator safety and protecting sensitive onboard electronics. |
| 360° Full EMI/RFI Shielding | Encased in a high-conductivity metallic shield to suppress electromagnetic interference from high-frequency switching. | Signal Purity: Protects the vehicle’s low-voltage communication systems (CAN/LIN bus) from noise, ensuring reliable autonomous and ECU logic operations. |
| Precision Cold-Pressed (Crimp) Termination | Designed for high-quality crimp connections with 4.0mm² orange high-voltage cables for low-resistance contact. | Optimal Efficiency: Minimizes voltage drop and heat buildup during sustained 40A loads, maximizing energy efficiency for EV auxiliary power systems. |
| Ergonomic Rectangular Housing (Orange) | Molded in high-visibility orange thermoplastic with a secure latching mechanism for quick and error-proof mating. | Field Serviceability: Facilitates fast assembly and clear visual identification of high-voltage circuits, meeting global automotive safety standards. |
