DF60A-5S-10.16C Hirose EnerBee 5-Position Power Socket Housing | Suqin
Short Description:
-
Manufacturer & Series: Part number DF60A-5S-10.16C (Alias: 680-3076-0-00), manufactured by Hirose Electric as part of the EnerBee DF60 series power connectors.
-
Structural Configuration: 5-position, single-row cable mount receptacle housing featuring a 10.16 mm (0.400 in) centerline pitch.
-
Electrical & Thermal Limits: Engineered for high-current power transmission up to 55 A and rated at 1 kV voltage, operating across a temperature range of -55 deg C to +105 deg C with 1 GOhms minimum insulation resistance.
-
Wire Compatibility: Accommodates crimp socket contacts for wire gauge sizes ranging from 12 AWG to 8 AWG.
-
Material & Mechanical Design: Constructed from black polybutylene terephthalate (PBT) housing, equipped with a positive latching system to ensure secure retention under vibrational loads.
Product Detail
Product Tags
Industrial Hirose DF60A-5S-10.16C EnerBee 5-position single-row power socket housing. Rated for 55A and 1kV, with 10.16mm pitch, PBT black housing, operating from -55 to +105 deg C. Available via Suzhou Suqin.
Data Overview
| Technical Parameter | Specification Value |
| Mfr. Part Number | DF60A-5S-10.16C |
| Part Aliases | 680-3076-0-00 |
| Manufacturer | Hirose Electric |
| Connector Series | DF60 |
| Tradename | EnerBee |
| Product Type | Power to the Board / Power Connectors |
| Type | Socket Housing / Receptacle |
| Number of Positions | 5 |
| Number of Rows | 1 |
| Pitch (Centerline) | 10.16 mm (0.400 in) |
| Current Rating | 55 A |
| Voltage Rating | 1 kV (1000 V) |
| Wire Gauge Range | 12 AWG to 8 AWG |
| Contact Gender | Socket (Female) |
| Termination Style | Crimp |
| Mounting Style | Cable Mount / Free Hanging |
| Mounting Angle | Straight |
| Housing Material | Polybutylene Terephthalate (PBT) |
| Housing Color | Black |
| Contact Material | Copper |
| Contact Plating | Gold |
| Insulation Resistance | 1 GOhms min. |
| Minimum Operating Temperature | -55 deg C |
| Maximum Operating Temperature | +105 deg C |
| Packaging | Bulk |
Product Details
| 10.16mm Pitch High Power Design | PBT Polymer Thermal Integrity | EnerBee Mechanical Latching Interface |
| High-Current Power Density Features a 5-position, single-row layout with a 10.16mm pitch, supporting high power transfer up to 55A per contact at 1kV for wire-to-board applications. | Industrial Environmental Endurance Molded from black polybutylene terephthalate (PBT) material, maintaining structural stability, 1 GOhms insulation resistance, and reliable performance from -55 deg C to +105 deg C. | Secure Locking System Designed with Hirose EnerBee positive locking latches and crimp contact retention, accommodating 12 AWG to 8 AWG wire sizes to prevent accidental disconnection. |
Our advantage
● Brand supply diversification,
Convenient one-stop shopping
● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.
● Complete information, fast delivery
Reduce intermediate links
● Good after-sales service
Quick response, professional reply
● Original genuine guarantee
Support professional consultation
● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.
Q1: What is the current capacity and electrical rating of the Hirose DF60A-5S-10.16C socket housing?
The DF60A-5S-10.16C is engineered for high-power applications, supporting up to 55 A current rating per contact and a voltage rating of 1 kV (1000 V).
Q2: What wire gauge range and contact termination method does this connector support?
This socket housing utilizes a crimp termination method for female socket contacts and supports wire gauge sizes ranging from 12 AWG to 8 AWG.
Q3: What material is used for the housing and what is its operational temperature range?
The housing is constructed from black Polybutylene Terephthalate (PBT) and is rated to operate across a temperature range of -55 deg C to +105 deg C with 1 GOhms minimum insulation resistance.
