YAZAKI

  • Yazaki 7282-2763-30 4 Pin 025 Series Automotive Connector Housing | Suqin

    Yazaki 7282-2763-30 4 Pin 025 Series Automotive Connector Housing | Suqin

    • Part Number & Series: Yazaki | Mfr Part Number: 7282-2763-30 | Part Aliases: 7282-2763-30 | Series: 025 (0.64mm) Automotive Series

    • Product Type & Circuit Layout: Wire-to-Wire Plug Housing (Female Cavity); 4-position (4POS / 4 Circuits, 2×2 grid) layout

    • Mounting & Cable Interface: Cable Mount / Free Hanging; designed for crimp terminal insertion with rear cable entry ports

    • Material & Physical Characteristics: Thermoplastic black housing body; integrated mechanical locking latch and polarity keying mechanism

    • Packaging & Operating Range: Original bag packaging (50 pcs/bag); operating temperature range -40°C to +100°C; RoHS compliant

  • 7282-1064 Yazaki 2.3II+8.0 Series 6-Position Male Hybrid Housing | Suqin

    7282-1064 Yazaki 2.3II+8.0 Series 6-Position Male Hybrid Housing | Suqin

    • Manufacturer & Series: Manufactured by Yazaki under the Hybrid Connector 2.3II+8.0 product family, designated with part number 7282-1064 as an unsealed male wire harness housing.

    • Hybrid Contact Architecture: Configured with a 6-pole mixed layout accommodating dual terminal tab widths of 2.30 mm and 8.00 mm for concurrent signal and power transmission.

    • Material Composition: Injection-molded from natural-colored high-grade Polybutylene Terephthalate (PBT) thermoplastic polymer resin.

    • Mechanical Integration: Equipped with an integrated clip installation structural channel to facilitate chassis or bracket mounting configurations.

    • Physical Envelope: Features compact outer dimensions measuring 46.80 mm in length, 27.60 mm in width, and 25.60 mm in height.

  • Yazaki 7287-1918-90 | 26-Way Blue Hybrid Connector | 025+060 Receptacle

    Yazaki 7287-1918-90 | 26-Way Blue Hybrid Connector | 025+060 Receptacle

    • Manufacturer: Yazaki

    • Part Number: 7287-1918-90 / 7287191890

    • Series: 025+060 Hybrid Series

    • Positions: 26 Way (Mixed Signal & Power)

    • Connector Type: Receptacle (Female Housing)

    • Color: Blue (Mechanical Keying)

    • Pitch/Interface: 0.64mm (025) + 1.5mm (060)

    • Operating Temp: -40°C to +85°C

    • Application: Body Control Module, Instrument Panels, Engine Harnesses

  • Yazaki 7116-4103-02 Female Automobile Connector Terminal | 15A 300V HV/HVN Series

    Yazaki 7116-4103-02 Female Automobile Connector Terminal | 15A 300V HV/HVN Series

    • Manufacturer: Yazaki (矢崎)

    • Part Number: 7116-4103-02

    • Terminal Type: Female Receptacle Terminal

    • Current Rating: 15A Per Contact (Continuous)

    • Voltage Rating: Up to 300V

    • Wire Range: 22–14 AWG (0.50 – 1.50 mm²)

    • Operating Temp: -40°C to +125°C

    • Contact Plating: Tin Electroplating (Anti-oxidation)

    • Termination: Crimp Type

    • Primary Application: Power Distribution, Blower Motors, and Automotive Lighting.

  • Yazaki 7123-6234-40 3-Way 250 Series Connector | Female Housing

    Yazaki 7123-6234-40 3-Way 250 Series Connector | Female Housing

    • Manufacturer: Yazaki (Japan)

    • Part Number: 7123-6234-40

    • Series: 250 Series (6.3mm Tab Width)

    • Number of Positions: 3 Position

    • Connector Gender: Receptacle (Female Housing)

    • Mounting Type: Cable Mount (Free Hanging)

    • Color: Light Gray (Standard Coding)

    • Housing Material: High-Strength Polyamide (Nylon)

    • Terminal Size: .250 (6.3mm) for High Current

    • Termination Style: Crimp (Secure Wire-to-Wire/Board)

  • Yazaki 7282-8497-90 4-Way Male Plug | Hybrid 9.5mm+1.5mm Sealed Blue

    Yazaki 7282-8497-90 4-Way Male Plug | Hybrid 9.5mm+1.5mm Sealed Blue

    • Manufacturer: Yazaki
    • Part Number: 7282-8497-90 (7282849790)
    • Series: 060 + 375 Hybrid Series
    • Number of Positions: 4 Ways
    • Cavity Layout: 2 x Power (9.5mm) + 2 x Signal (1.5mm)
    • Gender: Plug (Male Housing)
    • Mating Part: 7283-8497-90 (Female)
    • OEM Standards: Ford 3M5T-14A624-UDB / Daimler A9635450343
    • Sealing: Fully Sealed / Waterproof
    • Material: Heavy-Duty PBT
  • Yazaki 7120-1010 Insulation Sleeve | Green Automotive Terminal Cover

    Yazaki 7120-1010 Insulation Sleeve | Green Automotive Terminal Cover

    • Manufacturer: Yazaki
    • Part Number: 7120-1010 (71201010)
    • Product Type: Insulation Sleeve / Terminal Accessory
    • Application: Automotive Electrical Terminals
    • Color: Green (High Visibility)
    • Packaging: Reel / Cut Tape
    • Series: Automotive Connector Accessories
  • Yazaki 7282-6444-70 Male Connector | 2-Way, 1.5mm Tab, Yellow PBT

    Yazaki 7282-6444-70 Male Connector | 2-Way, 1.5mm Tab, Yellow PBT

    • Manufacturer: Yazaki
    • Part Number: 7282-6444-70
    • Connection Type: Wire Harness Connector (Unsealed)
    • Number of Poles: 2-Way
    • Tab Size: 1.5mm
    • Gender: Male
    • Color: Yellow
    • Current Classification: Medium Current (15A Ref.)
    • Mounting: Clip Installation Structure Supported
    • Mating Part: 7283-6444-70
  • Yazaki 58 Connector Y-Type 2-Pole Male Housing | Sealed, 40A High Current, 9.5mm Tab

    Yazaki 58 Connector Y-Type 2-Pole Male Housing | Sealed, 40A High Current, 9.5mm Tab

    • Series: Yazaki 58 Connector Y-Type

    • Configuration: 2 Positions (Poles), Male Housing

    • Current Rating: Approx. 40A (High Power Application)

    • Tab Size: 9.50mm (Large Blade for High Current)

    • Protection: Sealed / Waterproof System

    • Material: PBT (Polybutylene Terephthalate), Gray

    • Operating Temperature: -40°C to 120°C

    • Mates With: 7123-4220-40

    • Dimensions: 59.80mm (L) x 33.00mm (W) x 28.45mm (H)

123456 Next > >> Page 1 / 12
