Yazaki 7287-1918-90 | 26-Way Blue Hybrid Connector | 025+060 Receptacle

Short Description:

Manufacturer: Yazaki
Part Number: 7287-1918-90 / 7287191890
Series: 025+060 Hybrid Series
Positions: 26 Way (Mixed Signal & Power)
Connector Type: Receptacle (Female Housing)
Color: Blue (Mechanical Keying)
Pitch/Interface: 0.64mm (025) + 1.5mm (060)
Operating Temp: -40°C to +85°C
Application: Body Control Module, Instrument Panels, Engine Harnesses

Product Detail

Product Tags

Source original Yazaki 7287-1918-90 26-position blue hybrid connectors at Suzhou Suqin Electronic. Features 025+060 terminal system for combined signal and power delivery in automotive BCM and dash systems.

Data Overview

Attribute Category	Technical Specification
Brand	Yazaki
Model / PN	7287-1918-90
Number of Positions	26 (Hybrid)
Gender	Receptacle (Female)
Number of Rows	2 Row
Color	Blue
Terminal Size(s)	0.64mm (025) & 1.5mm (060)
Housing Material	PBT / Polyester
Operating Temperature	-40°C to +85°C
Mounting Type	Free Hanging (In-Line)
Status	Active Bulk Supply
Compliance	RoHS Compliant

Product Details

Modular Design & Engineering	Functional Reliability & Performance	Strategic Business Benefits
Hybrid 025+060 Pin Configuration	Integrates 22 small signal pins (0.64mm) and 4 medium power pins (1.5mm) within a single housing.	High Density Integration: Reduces the number of connectors needed on the PCB, saving critical space and reducing total harness weight.
Vibrant Blue Color Coding	Provides distinct visual and mechanical keying unique to the 7287-1918-90 series.	Error-Free Assembly: Eliminates the risk of mis-mating on complex assembly lines where multiple similar connectors are present, reducing rework costs.
High-Impact Thermoplastic Housing	Specifically engineered to withstand automotive vibrations and temperature fluctuations (-40°C to +85°C).	Long-Term System Stability: Ensures consistent electrical contact for critical vehicle sensors and modules, minimizing field warranty claims.
Integrated Secondary Locking	Features a robust primary latch and terminal position assurance (TPA) capability.	Uncompromised Connection: Prevents terminal “back-out” during high-vibration road conditions, ensuring 100% signal integrity for safety-critical systems.

Our advantage

● Brand supply diversification,
Convenient one-stop shopping

● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.

● Complete information, fast delivery
Reduce intermediate links

● Good after-sales service
Quick response, professional reply

● Original genuine guarantee
Support professional consultation

● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.

Q1: What terminals are required for the Yazaki 7287-1918-90?

A: This is a hybrid connector. You will need 22 pieces of 0.64mm (025 series) terminals for signal transmission and 4 pieces of 1.5mm (060 series) terminals for power. Suzhou Suqin Electronic can provide the matching terminal part numbers upon request.

Q2: What does the blue color signify for this Yazaki series?

A: The blue color indicates a specific mechanical keying code. It is designed to prevent accidental connection to same-size headers (e.g., grey or black versions) that have different internal keying patterns, ensuring that the correct harness is always connected to the correct module port.

Q3: Can these connectors withstand engine-level temperatures?

A: The 7287-1918-90 is rated for up to +85°C, making it perfect for vehicle cabins, instrument panels, and body control modules. For high-heat engine-mounted applications requiring higher ratings, please consult our engineering team for a reinforced PBT alternative.
