Amphenol ATM06-2S ATM Series 2-Way Plug Housing | Gray DTM Compatible
-
Manufacturer: Amphenol Sine Systems
-
Part Number: ATM06-2S
-
Series: ATM Series™ (Deutsch DTM Series Compatible)
-
Number of Positions: 2 Positions
-
Contact Type: Female Socket (Size 20)
-
Wire Range: 16 – 22 AWG (0.5 – 1.5mm²)
-
Sealing Protection: IP68 / IP69K (Mated)
-
Operating Temp: -55°C to +125°C
-
Mounting Type: Free Hanging (In-Line)
-
Fastening Type: Integrated Latch Lock
-
-
Amphenol AT04-6P-RD01 6-Way Receptacle Housing | Gray AT Series
-
Manufacturer: Amphenol Sine Systems
-
Part Number: AT04-6P-RD01
-
Series: AT Series™ (Deutsch DT Series Compatible)
-
Number of Positions: 6 Positions
-
Number of Rows: 2 Rows x 3
-
Contact Type: Male Pin (Size 16)
-
Wire Range: 14-20 AWG (2.0-0.5mm²)
-
Sealing Protection: IP67 (Mated)
-
Operating Temp: -55°C to +125°C
-
Color: Gray
-
-
Amphenol AT04-2P-PM16 2-Way Panel Mount Receptacle | 13A IP67
-
Manufacturer: Amphenol Sine Systems
-
Part Number: AT04-2P-PM16
-
Series: AT Series™ (DEUTSCH DT Compatible)
-
Positions: 2 Position
-
Contact Size: Size 16 (13 Amps)
-
Mounting Style: Panel Mount (Self-Threading)
-
Seal Type: Reduced Diameter Seal (1.35mm – 3.05mm)
-
IP Rating: IP67 (Mated)
-
Operating Temp: -55°C to +125°C
-
Wire Range: 14-20 AWG (2.0 – 0.5 mm²)
-
-
Amphenol 3FA1-NZSJ-C01E0 FAKRA Gen 3 Jack Housing | Code Z Water Blue
-
Manufacturer: Amphenol RF
-
Part Number: 3FA1-NZSJ-C01E0
-
Series: FAKRA Generation 3.0
-
Connector Style: Straight Jack (Female Housing)
-
Keying Code: Code Z (Universal / Neutral)
-
Color: Water Blue
-
Compatibility: Mates with all FAKRA Keying Codes
-
Interface Type: SMB Base RF Interface
-
Body Material: High-grade PPE/PS Plastic
-
Application: GPS, Telematics, ADAS, Infotainment Systems
-
-
Amphenol 10142348-010LF MicroSpace™ 1.27mm | 10-Pin Receptacle Housing
-
Manufacturer: Amphenol ICC (FCI)
-
Part Number: 10142348-010LF
-
Series: Minitek MicroSpace™ 1.27mm
-
Number of Positions: 10 (Dual Row)
-
Pitch: 1.27 mm (Micro-miniature)
-
Contact Type: Female Socket (Crimp)
-
Operating Temperature: -40°C to 130°C
-
Key Features: TPA (Terminal Position Assurance) & Primary Latch Lock
-
Compliance: LV214 Severity Level (Automotive Grade)
-
-
Amphenol AT04-08PA-BM04 BoardLock™ | 8-Pin Gray PCB Receptacle IP67
- Manufacturer: Amphenol SINE Systems
- Part Number: AT04-08PA-BM04
- Series: AT Series (BoardLock™)
- Number of Positions: 8 Position (2 Rows)
- Connector Type: Receptacle (Female Housing) with Male Pins
- Mounting Type: PCB Board Mount (Straight / Solder Pin)
- Current Rating: 13 Amps
- Ingress Protection: IP67 (Sealed)
- Operating Temp: -55°C to +125°C
- Mating Part: Compatible with AT06-08SA plugs
-
Amphenol ELPM2A02 ePower-Lite Mini 2-Way Plug Kit | Sealed 12 AWG Power Connector
- Manufacturer: Amphenol Industrial Operations
- Part Number: ELPM2A02 (ePower-Lite Mini Series)
- Kit Content: Complete Plug Assembly (Housing, Contacts, and Seals)
- Positions: 2 Position, Single Row
- Wire Compatibility: 12 AWG (optimized for 4mm² wire)
- Termination: Precision Crimp
- Mounting: Free Hanging (In-Line) / Panel Mount Capability
- Ingress Protection: Fully Sealed (Automotive Grade)
- Locking Mechanism: Integrated Latch Holder for secure mating
-
Amphenol 10142348-006LF MicroSpace™ Receptacle | 6-Pos, 1.27mm Pitch
- Manufacturer: Amphenol ICC (FCI)
- Part Number: 10142348-006LF
- Series: MicroSpace™ 1.27mm
- Number of Positions: 6 Positions (Dual Row)
- Pitch: 1.27mm (Note: Mating interface pitch is 1.27mm)
- Connector Type: Receptacle Housing for Female Sockets
- Fastening Type: Secure Latch Lock
- Operating Temp: -40°C to +130°C
- Special Feature: Integrated TPA (Terminal Position Lock)
- Standard Compliance: LV214 Automotive Severity Level
-
Amphenol 10142348-016LF MicroSpace™ 1.27mm Receptacle | 16-Way, Top Latch
- Manufacturer: Amphenol (MicroSpace™ Platform)
- Part Number: 10142348-016LF
- Number of Positions: 16 Ways
- Pitch: 1.27mm (0.050in) Staggered
- Design: Top Latch, Staggered Configuration
- Current Rating: 4A per contact
- Temperature Range: -40°C to +130°C
- Material: High Temperature Thermoplastic (UL 94 V-0)
- Mating Type: Wire-to-Board Receptacle
