3FAH-NZSJ-C01W0 FAKRA Jack Connector | Universal Code Z Water Blue | 6GHz RF Jack

Short Description:

Part Number: 3FAH-NZSJ-C01W0
Series: FAKRA Generation 1 (Automotive Grade)
Keycode: Z – Water Blue (Universal Compatibility)
Connector Type: Jack (Female Socket)
Frequency Range: DC to 6 GHz
Impedance: 50 Ohms
Compatible Cables: RG-174, RG-316, LMR-100A, Belden 7805A, DACAR 462
Contact Material: Beryllium Copper (Gold Plated)
Body Material: Brass (Nickel Plated)
Operating Temp: -65°C to +165°C

Product Detail

Product Tags

Buy 3FAH-NZSJ-C01W0 FAKRA Jack at Suzhou Suqin Electronic. Universal Code Z (Water Blue) design, 6GHz frequency, 50 Ohm impedance. Compatible with RG-174/316 cables for automotive telematics.

Data Overview

Attribute Category	Technical Specification
Manufacturer	Suzhou Suqin Electronic (Premium RF Series)
Model / PN	3FAH-NZSJ-C01W0
Connector Gender	Jack (Female)
Orientation	Straight
Keying / Color	Code Z / Water Blue (Universal)
Center Contact	Gold Plated Beryllium Copper
Insulator	PTFE (Teflon)
Maximum Frequency	6 GHz
Impedance	50 Ω
Termination Style	Cable – Crimp
Mating Cycles	100 Cycles Min
Unit Weight	3.64 Grams
Cable Compatibility	RG-174, RG-188, RG-316, LMR-100A

Product Details

Physical Integrity & Signal Shielding	Technical & Assembly Advantages	Strategic Business Benefits
Universal Code Z (Water Blue)	Features the “Z” keying system which mates with all other FAKRA keying codes (A, B, C, etc.).	Eliminate Mating Errors: Simplifies inventory management and prevents assembly line errors by providing a “one-size-fits-all” interface for testing and multi-signal ports.
6 GHz High-Frequency Support	Engineered to maintain consistent 50 Ohm impedance across frequencies up to 6 GHz.	Future-Proof Connectivity: Supports high-speed data protocols including GPS, SDARS, and 5G/V2X communications, ensuring no signal lag in modern smart vehicles.
Beryllium Copper Gold Contacts	Utilizing high-conductivity BeCu with premium gold plating to ensure low contact resistance.	Extreme Reliability: Maintains superior electrical performance under high-vibration and extreme temperature shifts, reducing long-term field maintenance costs.
Robust Push-on Coupling	Designed with a secure locking mechanism that provides tactile feedback during engagement.	Efficient Installation: Speed up the harness assembly process with a reliable “snap-lock” connection that guarantees it won’t vibrate loose over time.

Our advantage

● Brand supply diversification,
Convenient one-stop shopping

● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.

● Complete information, fast delivery
Reduce intermediate links

● Good after-sales service
Quick response, professional reply

● Original genuine guarantee
Support professional consultation

● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.

Q1: What is the primary advantage of using “Code Z” for FAKRA connectors?

A: Code Z (Water Blue) is known as the Universal Keying code. It is designed to mate with all other FAKRA color codes. This makes it ideal for diagnostic tools, test environments, or multi-function ports where you want to ensure connectivity regardless of the specific mating code used on the device.

Q2: Is this FAKRA connector compatible with RG-174 and RG-316 cables?

A: Yes, the 3FAH-NZSJ-C01W0 is specifically designed for subminiature coaxial cables including RG-174, RG-316, and LMR-100A. It uses a standard crimp termination that provides excellent pull-out strength and signal shielding.

Q3: Can this connector handle temperatures up to 165°C?

A: Yes, featuring a high-grade PTFE insulator and robust brass/nickel construction, this connector is rated for an operating temperature range of -65°C to +165°C, making it suitable for engine compartments and other high-heat automotive environments.
