  • Amphenol MPS02-BSFA032S 32-Pos MicroSpace™ 1.27mm Receptacle | High Density

    Amphenol MPS02-BSFA032S 32-Pos MicroSpace™ 1.27mm Receptacle | High Density

    • Manufacturer: Amphenol ICC (FCI)

    • Part Number: MPS02-BSFA032S

    • Series: MicroSpace™ 1.27mm Platform

    • Number of Positions: 32 Position (Dual Row 2×16)

    • Pitch: 1.27 mm (0.050″)

    • Connector Type: Receptacle Housing

    • Locking Style: Positive Latch (Vibration Resistant)

    • Termination: Crimp (Wire-to-Board)

    • Operating Temp: -40°C to +130°C

    • Compliance: Automotive LV214 Severity-2 Standards

    detail
  • Amphenol 10155504-A006LF 6-Pin MicroSpace Receptacle | 1.27mm Pitch

    Amphenol 10155504-A006LF 6-Pin MicroSpace Receptacle | 1.27mm Pitch

    • Manufacturer: Amphenol ICC (FCI)

    • Part Number: 10155504-A006LF

    • Series: MicroSpace™ 1.27mm Platform

    • Number of Positions: 6 Pins (2 Rows x 3)

    • Pitch: 1.27 mm (0.050″)

    • Connector Type: Receptacle Housing

    • Locking Type: Positive Latch Lock (Anti-Vibration)

    • Termination: Crimp (Wire-to-Board)

    • Operating Temp: -40°C to +130°C (High-Temperature Grade)

    • Compliance: Meets LV214 Severity-2 vibration standards for automotive.

    detail
  • Amphenol 865637PLTXLF 37 Way Male D-Sub Crimp Connector | Shell C

    Amphenol 865637PLTXLF 37 Way Male D-Sub Crimp Connector | Shell C

    • Manufacturer: Amphenol (formerly FCI)

    • Part Number: 865637PLTXLF

    • Series: 8656 Series

    • Number of Positions: 37 Pins

    • Gender: Male (Header)

    • Termination Style: Crimp (Removable Contacts)

    • Shell Size: C

    • Current Rating: 5A

    • Mounting Type: Standard 3.1mm Through Hole

    • Shell Plating: Matte Tin (EMI/RFI Shielding)

    • Operating Temp: -55°C to +105°C

    • Wire Gauge: 20-28 AWG (Depends on contact)

    detail
  • Amphenol HVSL1200022A1H10 2-Pole High Voltage Receptacle | 1000V 350A HVIL

    Amphenol HVSL1200022A1H10 2-Pole High Voltage Receptacle | 1000V 350A HVIL

    • Manufacturer: Amphenol

    • Part Number: HVSL1200022A1H10

    • Series: HVSL1200 (High Voltage Sealed)

    • Number of Positions: 2 Pole (Plus HVIL)

    • Rated Voltage: 1,000 V DC

    • Rated Current: 350 A (at 40°C)

    • High Voltage Interlock (HVIL): Yes (Integrated)

    • Protection Level: IP67 / IP6K9K (Mated)

    • Wire Gauge Range: 70 mm² to 95 mm²

    • Coding: A-Coding (Orange)

    • Application: Battery Packs, Inverters, PDU, and EV Powertrains.

    detail
  • Amphenol AT04-08PA-EC01:Male Cable Connector 8pol A-Key, End Cap

    Amphenol AT04-08PA-EC01:Male Cable Connector 8pol A-Key, End Cap

    • Manufacturer: Amphenol Sine Systems

    • Part Number: AT04-08PA-EC01

    • Series: AT Series (Deutsch DT Compatible)

    • Number of Positions: 8 Position

    • Connector Type: Receptacle (Male Pins)

    • Special Feature: EC01 (End Cap for Backshells/Heat Shrink)

    • Keying: A-Key (Grey)

    • Contact Size: Size 16 (13 Amps)

    • Ingress Protection: IP67, IP68, IP69K (Mated)

    • Operating Temp: -55°C to +125°C

    • Housing Material: Rugged Thermoplastic

    detail
  • Amphenol MPS02-BSFA0240 24-Way Hybrid Plug Connector | Power + Signal

    Amphenol MPS02-BSFA0240 24-Way Hybrid Plug Connector | Power + Signal

    • Manufacturer: Amphenol PCD / Amphenol Automotive

    • Part Number: MPS02-BSFA0240

    • Series: MPS (Modular Power System)

    • Pin Count: 24 Position (Hybrid Power & Signal)

    • Gender: Female (Plug)

    • Wire Gauge Range: Supports different gauges for Power & Signal circuits.

    • Sealing: Environmental Sealed (IP67/IP68 Mated)

    • Locking Mechanism: Robust Latch Lock with CPA (Connector Position Assurance) Capable.

    • Polarization: Code A

    • Primary Application: EV Battery PDU, Inverters, Motor Controllers, Industrial Automation

    detail
  • Amphenol PCD HVSL362062B116I 2-Pole HV Plug with HVIL | 6 AWG

    Amphenol PCD HVSL362062B116I 2-Pole HV Plug with HVIL | 6 AWG

    • Manufacturer: Amphenol PCD Shenzhen

    • Part Number: HVSL362062B116I

    • Series: Excel|mate HVSL Series

    • Configuration: 2-Pole Power Positions + HVIL

    • Gender: Plug (Housing for Female Sockets)

    • Wire Gauge: 6 AWG (Discrete Wire)

    • Ingress Protection: Environmental Sealed (Typically IP67)

    • Contact Finish: Gold Plated

    • Voltage Architecture: Typically up to 1000V DC

    • Features: Integrated High Voltage Interlock Loop (HVIL)

    • Color: Orange (HV Standard)

    detail
  • HVSC1P80FV116 1-Pos High Voltage Connector | 16mm² Shielded EV Header

    HVSC1P80FV116 1-Pos High Voltage Connector | 16mm² Shielded EV Header

    • Product Series: HVSC (High Voltage Sealed Connector)

    • Full Model: HVSC1P80FV116

    • Cable Compatibility: Optimized for 16mm² Shielded High-Voltage Cable

    • Rated Voltage: 1000V DC

    • Rated Current: Approx. 80A – 120A (Based on 16mm² wire)

    • Configuration: 1-Position, 90-Degree Right Angle

    • Ingress Protection: IP67, IP68, IPK9K (Mated)

    • Shielding: 360° EMI/RFI Full Coverage

    • Safety Standards: UL 94V-0 Flammability, Orange Safety Housing

    detail
  • HVC2PG36FS110 High Voltage 2-Pin EV Connector Plug | Gray Housing

    HVC2PG36FS110 High Voltage 2-Pin EV Connector Plug | Gray Housing

    • Model Number: HVC2PG36FS110
    • Product Type: High Voltage Connector (HVC)
    • Configuration: 2-Pin (2P)
    • Application: New Energy Vehicles (EV/HEV)
    • Gender: Male Plug
    • Series/Size: 36 Series
    • Housing Color: Gray (FS)
    • System Type: Power Delivery & Charging Systems
    • Features: Robust, High-Voltage Sealed Connection
    detail
