Amphenol PT06E-14-18S(SR) MIL-DTL-26482 Series I 18-Pin Circular Plug | Suqin
Short Description:
-
Brand Manufacturer: Amphenol Industrial Operations
-
MPN (Part Number): PT06E-14-18S(SR)
-
Base Series: PT Series (MIL-DTL-26482 Series I Standard)
-
Connector Configuration: Free Hanging (In-Line) Plug
-
Contact Gender: Female Sockets (18 Positions)
-
Shell Size & Insert Layout: 14-18 Matrix
-
Termination Method: Precision Solder Cup
-
Mating Coupling Type: 3-Point Quick Bayonet Lock
-
Housing Material & Finish: Aluminum with Olive Drab Chromate over Cadmium Plating
Product Detail
Product Tags
Buy genuine Amphenol PT06E-14-18S(SR) MIL-DTL-26482 standard 18-position circular connector plug at Suqin. Features 18 gold-plated female sockets, solder cup termination, quick bayonet coupling, and environmental strain relief backshell. Perfect for rugged industrial and aerospace applications.
Data Overview
| Technical Parametric Attributes | Spec Detail Values |
| Manufacturer | Amphenol Industrial Operations |
| Manufacturer Part Number | PT06E-14-18S(SR) |
| Base Product Number | PT06E |
| Connector Type | Cable Plug Housing with Female Sockets |
| Number of Positions | 18 Positions |
| Shell Size – Insert Layout | 14-18 |
| Military Standard Qualification | MIL-DTL-26482 Series I |
| Contact Gender Type | Female Socket |
| Termination Style | Solder Cup Type |
| Mating Mechanism | 3-Point Bayonet Lock |
| Shell Base Material | High-Grade Aluminum Alloy |
| Shell Surface Plating | Olive Drab Chromate over Cadmium |
| Backshell Assembly Style | Integrated Strain Relief (SR Clamp) |
| Contact Base Material | Copper Alloy |
| Contact Mating Interface Plating | Gold Layer Finish |
| Dielectric Insert Material | Rugged Neoprene |
| Operating Temperature Range | -55°C to 125°C |
| Shielding Performance | Unshielded Configuration |
| Insert Orientation Alignment | N (Normal Polarization Style) |
| Environmental Protection Status | Environmentally Sealed Structure |
Product Details
| Core Performance Attributes | Engineering & Deployment Advantages | Operational & Commercial Value |
| MIL-DTL-26482 Qualified 3-Point Bayonet Coupling | Provides clear audible and tactile feedback verification when fully locked, preventing incomplete engagement. | Eliminates field connector decoupling risks caused by high-vibration off-road or transit environments, dropping diagnostic downtime to zero. |
| Integrated Heavy-Duty Strain Relief Backshell (SR) | Features a dual-screw mechanical cable clamp assembly that anchors the wiring bundle directly to the metal housing. | Relieves pull and flex tension directly away from delicate internal solder cups, eliminating field wire-break failure headaches during installation. |
| Gold-Plated Contacts with Resilient Neoprene Inserts | Combines oxidation-resistant gold-mated copper surfaces with a high-dielectric, moisture-impermeable neoprene core. | Ensures highly stable millivolt signal and power delivery over low-current data lines under extreme thermal conditions ranging from -55°C to 125°C. |
