TE Connectivity 770034-1 Universal MATE-N-LOK II 3POS Plug | Suqin
-
Part Number & Series: TE Connectivity / AMP | Part Number: 770034-1 | Series: Universal MATE-N-LOK II
-
Product Type & Circuit Layout: Wire-to-Wire Free-Hanging Plug Housing; single-row, 3-position (3POS / 3 Circuits) inline layout
-
Pitch & Voltage Rating: 6.35 mm (.250 in) centerline pitch; 600 VAC max operating voltage rating
-
Material & Flammability: Natural Polyamide (Nylon, UL 94V-0 rated); non-sealed; operating temperature -55°C to +120°C
-
Packaging & Compatibility: Original bag packaging (250 PC/Bag); accepts Universal MATE-N-LOK II socket contacts; mates with 3POS Universal MATE-N-LOK II cap housings or PCB headers; RoHS compliant
-
-

TE Connectivity 2392558-3 HVA HD400 3POS Socket Cover | Suqin
-
Part Number & Series: TE Connectivity / HIVONEX | Part Number: 2392558-3 (HVA HD400 Series / Raychem)
-
Product Type & Circuit Layout: Automotive High-Voltage Socket Connector Cover / Clip; designed for 3-position (3POS) 4 mm diameter socket terminal assemblies
-
Shell & Structural Configuration: Circular flanged cap with integrated multi-tine internal retention ring for socket terminal alignment and retention
-
Material & Operating Range: Natural glass-fiber reinforced polyamide (PA GF); operating temperature range from -40°C to 140°C (-40°F to 284°F)
-
Packaging & Compliance: Industrial bulk packaging (4,000 EA/Box); RoHS compliant
-
-

TE Connectivity AMP 368165-1 Econoseal J – Mark II Mounting Clip | Suqin
-
Part Number & Series: TE Connectivity / AMP | Part Number: 368165-1 (Econoseal J – Mark II (+) / Econoseal .250 Series)
-
Product Type & Circuit Layout: Automotive Connector Housing Mounting Clip; designed for 070 / EJ MK-II(+) series plug and cap housing attachment
-
Shell & Structural Configuration: Single-piece molded Nylon clip featuring slide-rail housing engagement channel and push-in panel anchor
-
Material & Mounting Type: Black unfilled Nylon 66 (PA66) with UL 94HB flammability rating; panel mount push-in installation style
-
Packaging & Compliance: Original factory sealed bulk bag packaging containing 1,000 pieces (1,000 EA/Bag); RoHS compliant
-
-

TE Connectivity AMP 1379658-1 TH/.025 4-Pin Black Receptacle Housing | Suqin
-
Part Number & Series: TE Connectivity / AMP | Part Number: 1379658-1 (TH/.025 Connector System Series)
-
Product Type & Circuit Layout: 4-Position (1 x 4 Single Row Layout) Wire-to-Wire Receptacle Housing for Female Terminals; 2.20 mm [.087 in] centerline pitch
-
Locking & Contact Retention: Primary locking lance design with Terminal Position Assurance (TPA) secondary lock to ensure positive contact seating
-
Material & Thermal Limits: Black Polybutylene Terephthalate (PBT) thermoplastic body rated UL 94HB; operating temperature range from -40 °C to +100 °C [-40 °F to +212 °F]
-
Application & Termination: Free-hanging (in-line) mounting for automotive wire harness signal circuits; mates with .64 mm [.025 in] tab size female crimp terminals
-
-

TE Connectivity AMP 747553-3 AMPLIMITE HDP-20 25-Pin D-Sub Receptacle Housing | Suqin
-
Part Number & Series: TE Connectivity / AMP | Part Number: 747553-3 (AMPLIMITE HDP-20 Series)
-
Product Type & Circuit Layout: 25-Position (2-Row D-Sub Layout) Wire-to-Wire Receptacle Housing; Shell Size 3 with 2.77 mm [.109 in] contact centerline spacing
-
Shell & Structural Configuration: Stamped steel shell enclosure providing mechanical robustness and contact cavity alignment for 25 socket contacts
-
Material & Mounting Type: Black thermoplastic insert housed within plated steel shell; integrated panel mount flange configuration with dual mounting holes
-
Contact & Termination Method: Crimp snap-in cavity retention; accepts HDP-20 size 20DF female socket crimp contacts (ordered separately)
-
-

TE Connectivity AMP 521205-1 RAST 5 5.00mm 3-Pin Blue Receptacle Housing | Suqin
-
Part Number & Series: TE Connectivity / AMP | Part Number: 521205-1 (RAST 5 Series)
-
Product Type & Circuit Layout: 3-Position (1 x 3 Row Layout) Wire-to-Board Receptacle Housing; 5.00 mm [.197 in] centerline pitch with both ends closed configuration
-
Keying & Polarization: Factory-molded 1C | 2D keying and polarization rib profile to prevent mechanical mismating during harness assembly
-
Material & Thermal Limits: Flame-retardant blue Polyamide (PA 6/66 Nylon) body rated UL 94V-0; operating temperature range from -40 °C to +110 °C [-40 °F to +230 °F]
-
Mounting & Cable Termination: Free-hanging (in-line) wire harness mounting; accepts crimp socket terminals supporting 22 to 14 AWG wire sizes for power and signal applications
-
-
TE Connectivity 282104-1 AMP Superseal 1.5mm 2-Pin Male Housing | Suqin
-
Part Number & Series: TE Connectivity / AMP | Part Number: 282104-1 (AMP Superseal 1.5mm Series)
-
Product Type & Circuit Layout: 2-Way Wire-to-Wire Tab Housing for Male Terminals; 1-row x 2-position layout
-
Electrical & Contact Rating: Accepts 1.5 mm tab contacts; rated up to 14 A max per contact for 12 V / 24 V / 48 V DC power architectures (24 VDC operating)
-
Material & Environmental Protection: Glass-reinforced polyamide (PA 66 GF) body in black; IP67, IPX6K, and IPX9K ingress protection rating against high-pressure washdowns
-
Mounting & Dimensions: Free-hanging (in-line) mounting with polarizing rib alignment; 6.0 mm pitch; 13.8 mm H x 19.8 mm W x 42.0 mm L; operating temperature -40 °C to +125 °C
-
-

TE Connectivity 1563125-1 MCON 10-Position Tab Housing | Suqin
-
Part Number & Brand: TE Connectivity / AMP | Part Number: 1563125-1 (MCON Series)
-
Product Type & Circuit Layout: 10-Way Mixed Wire-to-Wire Tab Housing for Male Contacts; 3-row hybrid grid layout
-
Electrical & Pitch: Rated for 14 VDC nominal automotive systems; mixed contact pitch of 2.54 mm and 5.2 mm with 4.24 mm row spacing
-
Material & Environment: Glass-reinforced polybutylene terephthalate (PBT-GF20) body in black; operating temperature range of -20 °C to +120 °C
-
Mounting & Latching: Free-hanging (in-line) mounting with integrated primary polarization keying and locking latch mechanism
-
-

TE Connectivity 794895-1 Mini-Universal MATE-N-LOK 6-Pin Plug Housing | Suqin
-
Part Number & Brand: TE Connectivity | Part Number: 794895-1
-
Product Series & Type: Mini-Universal MATE-N-LOK Series | 6-Position Dual-Row Plug Housing
-
Pitch & Contact Layout: 4.14mm (.162 in) centerline pitch, 4.14mm (.162 in) row-to-row spacing; 2 x 3 dual-row grid accepting socket crimp contacts
-
Material & Voltage Rating: White Nylon housing meeting UL 94V-0 flammability standard; rated for 600 VAC operation
-
Sealability & Mounting: Sealable wire-to-wire connector system; free-hanging (in-line) cable mounting for power and signal applications
-
