  • DTM06-4S TE Connectivity Deutsch 4-Pin Sealed Plug Housing | Suqin

    DTM06-4S TE Connectivity Deutsch 4-Pin Sealed Plug Housing | Suqin

    • Part Number & Series: TE Connectivity Deutsch DTM06-4S (Base: DTM06) | DTM Series

    • Type & Layout: 4-Position, 2-Row, Sealed Female Socket Plug Housing (Free Hanging / In-Line)

    • Ingress Protection: IP68 and IP6K9K rated heavy-duty environmental sealing with integrated silicone rear wire seal

    • Material & Temp: Gray thermoplastic housing, -55 deg C to +125 deg C operating range, integrated positive latch lock

    • Termination & Mating: Crimp termination; requires DEUTSCH Size 20 female socket contacts and WM-4S wedgelock (sold separately)

  • 1-1564520-1 TE HDSCS 12-Pin Tab Housing Key A IP67 PBT-GF30 | Suqin

    1-1564520-1 TE HDSCS 12-Pin Tab Housing Key A IP67 PBT-GF30 | Suqin

    • Model & Specs: TE Connectivity 1-1564520-1 | 12-position, 2-row, 4.00 mm pitch sealed male tab housing (HDSCS Series).

    • Electrical & Contacts: 12V/24V/48V architecture (60 VDC max), 10 A max current; accepts 1.6 mm tab terminals.

    • Material & Rating: Black PBT-GF30 thermoplastic, UL 94V-0 flammability, IP67 sealed, -40 deg C to +140 deg C operating range.

    • Mating & Process: Key A polarization, terminal primary lock with integrated slide lock mechanism; free-hanging wire-to-wire mount.

  • 1-1670919-1 TE MCON 1.2mm 6-Pin Sealed Black Housing | Suqin

    1-1670919-1 TE MCON 1.2mm 6-Pin Sealed Black Housing | Suqin

    • Model & Specs: TE Connectivity 1-1670919-1 | 6-position, 1-row, 4.00 mm pitch sealed female receptacle housing (MCON 1.2mm series).

    • Electrical & Contacts: 12V/24V/48V nominal architecture, 22 A max current; accepts 1.2 mm tab socket terminals.

    • Material & Rating: Black PA6-GF15 thermoplastic, IPX4K/IPX9K sealed, -40 deg C to +130 deg C operating range.

    • Mating & Process: Key A polarization, locking lance with purple TPA retainer; free-hanging wire-to-board/wire-to-wire mount.

  • 1534100-1 TE Connectivity 12-Pin 2.54mm Pitch Black Housing | Suqin

    1534100-1 TE Connectivity 12-Pin 2.54mm Pitch Black Housing | Suqin

    • Model & Specs: TE Connectivity 1534100-1 | 12-position, 2-row, 2.54 mm pitch unsealed female receptacle housing.

    • Electrical & Contacts: 12V/24V nominal architecture, 7.5 A max current; accepts 0.64 mm tab socket terminals.

    • Material & Rating: Black PBT-GF15 thermoplastic, UL 94HB flammability, -40 deg C to +120 deg C operating range.

    • Mating & Process: Key A polarization, locking lance with TPA; free-hanging wire-to-board/wire-to-wire mount; KOMAX v5.0 compliant.

  • 2371035-2 TE HVA HD400 3-Pin High Voltage Orange Housing | Suqin

    2371035-2 TE HVA HD400 3-Pin High Voltage Orange Housing | Suqin

    • Manufacturer & Series: Part number 2371035-2, manufactured by TE Connectivity as part of the HVA HD400 high-voltage automotive connector series.

    • Electrical & Power Capacity: Rated for 1000 VDC/VAC operating voltage and up to 70 A maximum contact current rating in 12 V nominal architecture automotive systems.

    • Contact & Configuration: 3-position mixed/hybrid circular housing for female socket contacts, accepting 1.2mm tab and 4mm pin size terminals in Key B coding alignment.

    • Environmental Sealing & Durability: Features IPX9K environmental sealing protection and glass-filled polyamide (PA GF) orange housing operating from -40 deg C to +140 deg C.

    • Retention & Mechanical Features: Equipped with integrated primary locking, Terminal Position Assurance (TPA), strain relief, and 180 deg cable exit angle for cable-to-panel and in-line mounting.

  • 368538-1 TE Connectivity Crimping terminal rubber 2-Pin Male Plug Housing

    368538-1 TE Connectivity Crimping terminal rubber 2-Pin Male Plug Housing

    • Manufacturer & Series: Part number 368538-1, manufactured by TE Connectivity / AMP as part of the .070 MULTILOCK product family.

    • Configuration & Pitch: Single-row, 2-position male plug housing featuring a 3.50 mm (0.138 in) pitch centerline layout.

    • Mounting & Termination: Cable mount / free-hanging configuration designed for crimp contact termination accepting wire sizes from 22 AWG to 16 AWG.

    • Material & Physical Dimensions: Molded from white Polybutylene Terephthalate (PBT) resin, measuring 10.4 mm in length, 15.15 mm in width, and 21.0 mm in height.

    • Application Scope: Engineered for automotive wire-to-wire harness applications, offering secure contact retention and low-profile mating alignment.

  • 794953-2 TE Connectivity AMP 2-Position Panel Mount Plug Housing | Suqin

    794953-2 TE Connectivity AMP 2-Position Panel Mount Plug Housing | Suqin

    • Manufacturer & Product Line: Part number 794953-2, manufactured by TE Connectivity / AMP as a 2-position dual-row panel mount plug housing.

    • Mechanical & Mounting Design: Features a 4.2 mm (.165 in) centerline pitch with flexible side panel mount retention wings for secure wire-to-panel and wire-to-wire mounting.

    • Material & Thermal Specifications: Molded from natural nylon meeting UL 94V-2 flammability standards, rated for an operating temperature range of -40 deg C to +105 deg C (-40 deg F to +221 deg F).

    • Electrical Capabilities: Rated for 600 VAC operating voltage across combined power and signal circuits in unsealed commercial and industrial harnesses.

    • Contact & Cable Compatibility: Accepts crimp pin contacts for discrete wire and cable applications with compatible insulation diameters ranging from 1.2 mm to 3.1 mm (.047 in to .122 in).

  • 1-176282-1 AMP Universal Power 2-Position Cap Housing | Suqin

    1-176282-1 AMP Universal Power 2-Position Cap Housing | Suqin

    • Manufacturer & Series: Part number 1-176282-1, engineered as a cap housing within the AMP Universal Power connector system.

    • Structural Configuration: 2-position, 1-row free-hanging (in-line) configuration featuring a standard 3.96 mm (0.156 in) centerline pitch.

    • Electrical Ratings: Designed for power and signal circuit applications with a stable operating voltage rating of 300 VAC.

    • Material & Thermal Integrity: Constructed from natural-colored PA 6/6 thermoplastic with a UL 94V-0 flammability rating, operating reliably from -30 °C to 105 °C.

    • Mechanical Design: Utilizes a crimp termination method to wire and cable, incorporating polarization for accurate mating alignment and a built-in latch mechanism for secure mating retention.

  • 794805-1 4-Position Mini-Universal MATE-N-LOK Plug Housing | Suqin

    794805-1 4-Position Mini-Universal MATE-N-LOK Plug Housing | Suqin

    • Manufacturer & Series: Part number 794805-1, engineered as a key component of the Mini-Universal MATE-N-LOK connector system.

    • Structural Configuration: 4-position, 2-row free-hanging plug housing featuring a standard 4.17 mm (0.164 in) centerline pitch for wire-to-wire integration.

    • Electrical Ratings: Designed to support demanding power and signal circuits with a robust operating voltage rating of 600 VAC.

    • Material & Thermal Integrity: Constructed from white nylon with a UL 94V-0 flammability rating, ensuring mechanical stability across an operating temperature range of -20 °C to 105 °C.

    • Compliance & Standards: Fully certified and recognized under strict industry standards, including UL E28476 and CSA LR 7189.
