794805-1 4-Position Mini-Universal MATE-N-LOK Plug Housing | Suqin

Short Description:

Manufacturer & Series: Part number 794805-1, engineered as a key component of the Mini-Universal MATE-N-LOK connector system.
Structural Configuration: 4-position, 2-row free-hanging plug housing featuring a standard 4.17 mm (0.164 in) centerline pitch for wire-to-wire integration.
Electrical Ratings: Designed to support demanding power and signal circuits with a robust operating voltage rating of 600 VAC.
Material & Thermal Integrity: Constructed from white nylon with a UL 94V-0 flammability rating, ensuring mechanical stability across an operating temperature range of -20 °C to 105 °C.
Compliance & Standards: Fully certified and recognized under strict industry standards, including UL E28476 and CSA LR 7189.

Product Detail

Product Tags

Industrial 794805-1 Mini-Universal MATE-N-LOK 4-position, 2-row plug housing. Features a 4.17mm pitch, 600 VAC rating, and UL 94V-0 white nylon construction for reliable wire-to-wire connections. Available via Suzhou Suqin.

Data Overview

Technical Parameter	Specification Value
Mfr. Part Number	794805-1
Connector Series	Mini-Universal MATE-N-LOK
Product Type	Plug Housing
Connector System	Wire-to-Wire
Number of Positions	4
Number of Rows	2
Centerline (Pitch)	4.17 mm [0.164 in]
Row-to-Row Spacing	4.17 mm [0.164 in]
Operating Voltage	600 VAC
Housing Material	Nylon
Primary Product Color	White
Flammability Rating	UL 94V-0
Operating Temperature Range	-20 °C to 105 °C [-4 °F to 221 °F]
Termination Method	Crimp (Wire & Cable)
Sealable	Yes
Mounting Type	Free-Hanging (In-Line)
Circuit Application	Power & Signal
Agency Approvals	UL (E28476) / CSA (LR 7189)

Product Details

4.17mm Pitch 2-Row Geometry	High-Voltage Electrical Capacity	UL 94V-0 Nylon Integrity
Optimized Spatial Layout The compact 2×2 grid configuration with a 4.17 mm centerline pitch minimizes the spatial footprint while maintaining adequate isolation for power and signal routing.	600 VAC Operational Rating Engineered to handle high voltage loads up to 600 VAC safely, making it highly versatile for mixed power and signal wire-to-wire harness applications.	Industrial Grade Material Molded from white nylon featuring a UL 94V-0 flammability rating, providing excellent self-extinguishing properties and reliable thermal endurance up to 105 °C.

Our advantage

● Brand supply diversification,
Convenient one-stop shopping

● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.

● Complete information, fast delivery
Reduce intermediate links

● Good after-sales service
Quick response, professional reply

● Original genuine guarantee
Support professional consultation

● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.

Q1: What connector system does the 794805-1 housing belong to?

The 794805-1 is a core component of the Mini-Universal MATE-N-LOK connector system, designed specifically for secure wire-to-wire power and signal circuit applications.

Q2: What are the critical electrical ratings for this plug housing?

This housing is rated for a high operating voltage of up to 600 VAC. It utilizes a 4.17 mm (0.164 in) centerline pitch to safely isolate the 4 contact positions across its 2-row layout.

Q3: Is the 794805-1 material certified for industrial safety standards?

Yes, the housing is molded from high-quality white nylon that meets the stringent UL 94V-0 flammability rating. Furthermore, the product is fully certified and recognized by both UL (E28476) and CSA (LR 7189), operating reliably within a temperature range of -20 °C to 105 °C
