Molex

  • Molex 0522660411 Mizu-P25 Waterproof 4-Pin Connector Plug | Suqin

    Molex 0522660411 Mizu-P25 Waterproof 4-Pin Connector Plug | Suqin

    • Brand Manufacturer: Molex

    • MPN (Part Number): 0522660411 (Series 52266)

    • DigiKey Part Alias: 522660411-ND

    • Product Series: Mizu-P25 Waterproof, Splash Proof Mini-System

    • Connector Profile Type: Plug Housing (Male Pin Shroud)

    • Total Circuit Positions: 4 Positions

    • Centerline Pitch Spacing: 0.098″ (2.50mm)

    • Row Configuration: 1 Row (Single Row)

    • Mounting Assembly Style: Free Hanging (In-Line) / Cable Mount

    detail
  • Molex 43025-1800 Micro-Fit 3.0 Receptacle Housing 18-Pin Dual Row | Suqin

    Molex 43025-1800 Micro-Fit 3.0 Receptacle Housing 18-Pin Dual Row | Suqin

    • Brand Manufacturer: Molex

    • MPN (Part Number): 43025-1800

    • Part Number Aliases: 0430251800

    • Product Series: Micro-Fit 3.0 Series (43025)

    • Connector Configuration: Housing Shell for Female Terminals (Receptacle)

    • Total Circuit Positions: 18 Positions

    • Row Architecture: Dual Row (2 Rows Layout)

    • Pitch Spacing Matrix: 3.00mm (0.118 inch) Centerline

    • Row Spacing Matrix: 3.00mm (0.118 inch) Centerline

    detail
  • Molex 0436401200 | Micro-Fit 3.0 12-Pin Panel Mount Plug Housin

    Molex 0436401200 | Micro-Fit 3.0 12-Pin Panel Mount Plug Housin

    • Brand Manufacturer: Molex

    • MPN (Part Number): 0436401200 / 43640-1200

    • Product Connector Series: Micro-Fit 3.0 43640

    • Circuit Positions: 12 Positions / 12 Pin Configuration

    • Row Architecture: Single Row (1 Row Layout)

    • Pitch Spacing Matrix: 0.118 Inches / 3.00mm

    • Connector Configuration: Plug Housing (Accepts Male Crimp Pins)

    • Mounting Attachment Type: Panel Mount via Integrated Snap-In Wings

    • Mating Retention Style: Positive Locking Ramp Mechanism

    • Insulation Base Material: Polyamide (PA), Durable Nylon

    • Operating Thermal Range: Minus 40 Degrees Celsius to 105 Degrees Celsius

    • Mating Notice: Crimp Terminals / Contacts are Sold Separately

    detail
  • 0190030011 | Molex InsulKrimp 18-22 AWG Fully Insulated Female Quick Disconnect

    0190030011 | Molex InsulKrimp 18-22 AWG Fully Insulated Female Quick Disconnect

    • Manufacturer: Molex

    • Part Number: 0190030011 / 019003-0011

    • Series Name: InsulKrimp

    • Product Type: Quick Connect / Quick Disconnect Female Receptacle Terminal

    • Insulation Class: Fully Insulated Nylon Housing

    • Wire Gauge Compatibility: 18-22 AWG (American Wire Gauge)

    • Mating Tab Width: 0.187 inch (4.75 mm)

    • Mating Tab Thickness: 0.020 inch (0.51 mm)

    • Termination Method: Crimp Style

    • Contact Material Base: High-Conductivity Brass

    • Contact Surface Finish: Corrosion-Resistant Tin Plating

    • Color Identifier: Red (Industry Standard for 18-22 AWG Wire Range)

    • Mounting Type: Free Hanging / In-Line Wire Routing

    • Maximum Insulation Diameter: 0.135 inch (3.43 mm)

    • Overall Component Length: 0.780 inch (19.81 mm)

    detail
  • Molex 334721601 MX150 Sealed Female Connector | 16-Pin Dual Row Receptacle

    Molex 334721601 MX150 Sealed Female Connector | 16-Pin Dual Row Receptacle

    • Brand: Molex (MX150 Series)

    • Part Number: 334721601 (33472-1601)

    • Circuits: 16 Position (Dual Row 2×8)

    • Gender: Receptacle Housing (Female)

    • Pitch: 3.50 mm

    • Sealing Type: Mat-Sealed (Waterproof/Dustproof)

    • Keying Option: Option A (Black)

    • Housing Material: High-Performance SPS/Nylon

    • Operating Temp: -40°C to +125°C

    • Standard Compliance: Automotive Grade / RoHS

    detail
  • Molex 0438600025 Shielded RJ45 Jack | 90° Right Angle EMI Finger

    Molex 0438600025 Shielded RJ45 Jack | 90° Right Angle EMI Finger

    • Manufacturer: Molex

    • Part Number: 0438600025 (43860-0025)

    • Connector Type: RJ45 (8p8c) Modular Jack

    • Orientation: 90° Angle (Right Angle)

    • Shielding: Shielded with EMI Fingers

    • Performance: Cat3 Rated

    • Contact Plating: 50.0µin (1.27µm) Gold over Nickel

    • Mounting Type: Through Hole (Solder)

    • Special Features: Integrated Board Locks (PCB Retention)

    • Tab Direction: Tab Up

    detail
  • Molex 2005020271 stAK50h 27-Pin Right-Angle Header | Automotive PCB Plug

    Molex 2005020271 stAK50h 27-Pin Right-Angle Header | Automotive PCB Plug

    • Manufacturer: Molex

    • Part Number: 2005020271

    • Series: stAK50h (High-Density Automotive)

    • Positions: 27 Circuits (5-Row Configuration)

    • Orientation: Right Angle (Horizontal PCB Mount)

    • Mounting Type: Through Hole (Solder)

    • Voltage Rating: 14V DC

    • Housing Material: Glass-filled SPS (Black)

    • Temperature Range: -40°C to +105°C

    • Standards: USCAR-2 Compliant / UL 94V-0

    detail
  • 2005021231 Molex stAK50h 23-Pin Hybrid Header | 40A Power & Signal

    2005021231 Molex stAK50h 23-Pin Hybrid Header | 40A Power & Signal

    • Manufacturer: Molex

    • Part Number: 2005021231

    • Series: stAK50h (High-Density Automotive)

    • Circuit Configuration: 23 Positions (Hybrid Power + Signal)

    • Current Rating: 40.0A (Power) / 5.0A (Signal) per contact

    • Orientation: Right Angle (Space-saving)

    • Keying / Color: Key 1 / Dark Gray

    • Automotive Standards: LV-214 (-40° to +105°C), GMW3191

    • Mounting Type: Through Hole (Standard PCB)

    • Interface Pitch: 2.00mm, 8.10mm (Hybrid Pitch)

    detail
  • Molex 2159221600 Micro-Fit 16-Circuit Plug | Panel Mount 3.0mm

    Molex 2159221600 Micro-Fit 16-Circuit Plug | Panel Mount 3.0mm

    • Manufacturer: Molex

    • Part Number: 2159221600

    • Series: Micro-Fit 3.0 / Micro-Fit Plus Family

    • Number of Positions: 16 Circuits (Dual Row 2×8)

    • Pitch: 0.118″ (3.00 mm)

    • Mounting Type: Panel Mount (Snap-In)

    • Gender: Plug (Male Pin Housing)

    • Termination: Crimp (Wire-to-Wire)

    • Material: Polyamide (PA66) / Nylon 6/6

    • Safety Standard: Glow Wire Compliant

    • Operating Temp: -40°C to +105°C

    detail
<< < Previous 123456 Next > >> Page 2 / 27
