  • 5601230200 Molex DuraClik 2-Pin 2.00mm Receptacle Housing | Suqin

    5601230200 Molex DuraClik 2-Pin 2.00mm Receptacle Housing | Suqin

    • Manufacturer & Series: Part number 5601230200, manufactured by Molex as part of the DuraClik 560123 product family (ISL housing type).

    • Configuration & Pitch: Features a single-row, 2-position receptacle housing design with a 2.00 mm (0.079 in) pitch centerline.

    • Mounting & Fastening: Configured for free-hanging (in-line) wire termination with an integrated positive latch holder mechanism for secure connector locking.

    • Material & Physical Construction: Molded from white glass-filled Polybutylene Terephthalate (PBT) resin providing thermal and mechanical durability.

    • Contact & Application System: Accepts non-gendered crimp contacts (sold separately), engineered for high-vibration automotive and industrial wire-to-board applications.

  • 148028-6001 Molex MX150 6-Pin Panel Mount Plug Housing | Suqin

    148028-6001 Molex MX150 6-Pin Panel Mount Plug Housing | Suqin

    • Manufacturer & Series: Part number 148028-6001, manufactured by Molex as part of the MX150 sealed automotive connector product family (Series 148028).

    • Configuration & Mounting: Features a 2-row, 6-position (2×3) panel mount plug housing with a 3.5 mm (0.138 in) pitch centerline and straight mounting orientation.

    • Sealing & Polarization: Equipped with an integrated blue silicone gasket for panel sealing and keying Polarization A (black housing) to ensure proper mating alignment.

    • Material & Thermal Rating: Molded from UL 94V-0 rated glass-filled nylon, supporting an operating temperature range from -40 deg C to +125 deg C.

    • Terminal Retention & Application: Designed for male pin blade contacts with integrated terminal position assurance (TPA) lock, suitable for automotive, off-highway, and industrial harness applications.

  • 39-01-4050 Molex Mini-Fit Jr. 4.2mm 5-Circuit Receptacle Housing | Suqin

    39-01-4050 Molex Mini-Fit Jr. 4.2mm 5-Circuit Receptacle Housing | Suqin

    • Manufacturer & Series: Part number 39-01-4050 (5557-05R), manufactured by Molex as part of the Mini-Fit Jr. 5557 series power connector family.

    • Structural Configuration: 5-position, 1-row inline cable-mount / free-hanging receptacle housing with a 4.20 mm (0.165 in) pitch centerline.

    • Electrical Ratings: Rated for high-current power transmission up to 13 A per circuit and operating voltages up to 600 V AC/DC.

    • Material & Flammability Grade: Constructed from natural polyamide (PA / Nylon) meeting UL 94V-2 flammability standards, rated for temperatures from -40 deg C to +105 deg C.

    • Mating & Interconnect Versatility: Features positive locking latches and polarized geometry to ensure secure alignment for wire-to-board and wire-to-wire harness configurations.

  • 51353-1600 Molex MicroClasp 2.00mm 16-Circuit Receptacle Housing | Suqin

    51353-1600 Molex MicroClasp 2.00mm 16-Circuit Receptacle Housing | Suqin

    • Manufacturer & Series: Part number 51353-1600, manufactured by Molex as part of the MicroClasp 51353 series wire-to-board connector system.

    • Structural Configuration: 16-position, 2-row (2×8 grid) free-hanging / cable-mount receptacle housing with a 2.00 mm (0.079 in) pitch centerline.

    • Material & Flammability Grade: Molded from white nylon resin meeting UL 94 V-0 flammability standards for industrial and commercial signal applications.

    • Mechanical Latching: Features an outer positive lock latching mechanism to prevent accidental disconnection caused by vibration or cable tension.

    • Contact & Termination: Designed to accept MicroClasp crimp female socket contacts (sold separately) for discrete wire-to-board signal routing.

  • 47725-9040 Molex MX150 12-Position Panel Mount Male Connector | Suqin

    47725-9040 Molex MX150 12-Position Panel Mount Male Connector | Suqin

    • Manufacturer & Series: Part number 47725-9040, manufactured by Molex as part of the MX150 47725 series sealed panel mount male connector family.

    • Structural Configuration: 12-position, 2-row (2×6 grid) panel mount male plug assembly with a 3.5 mm (0.138 in) pitch and Keying Option D geometry.

    • Material & Flammability Grade: Molded from stone gray PA6-GF30 polyamide material rated to UL 94 V-0 flammability standards, equipped with an integrated blue perimeter sealing gasket.

    • Environmental Resistance: Engineered for automotive wire-to-wire power applications operating across a temperature range of -40 deg C to +125 deg C at a rated voltage of 14 V.

    • Termination & Compatibility: Accepts crimp male terminal contacts (sold separately) for discrete wire gauges ranging from 22 AWG to 14 AWG.

  • 172258-3116 Molex Ultra-Fit Dual Row 16-Position Receptacle Housing | Suqin

    172258-3116 Molex Ultra-Fit Dual Row 16-Position Receptacle Housing | Suqin

    • Manufacturer & Series: Part number 172258-3116, manufactured by Molex as a dual-row receptacle housing within the Ultra-Fit 172258 series.

    • Structural Configuration: 16-position, 2-row cable mount configuration featuring a 3.5 mm (0.138 in) centerline pitch and 4.6 mm (0.181 in) row-to-row spacing.

    • Material & Flammability Grade: Molded from high-temperature black nylon insulation material rated to UL 94 V-0 flammability standards, designed to operate from -40 deg C to +105 deg C.

    • Mechanical Interface: Features Ultra-Fit positive lock retention and mechanical polarization keys to prevent mis-mating and handle severe vibrational stress.

    • Termination & Application: Accommodates crimp female socket contacts (sold separately) for high-density wire-to-board power distribution harness assemblies.

  • 172256-3103 Molex Ultra-Fit 3-Position Receptacle Housing | Suqin

    172256-3103 Molex Ultra-Fit 3-Position Receptacle Housing | Suqin

    • Manufacturer & Series: Part number 172256-3103, engineered as a receptacle housing within the Molex Ultra-Fit 172256 series.

    • Structural Configuration: 3-position, single-row cable mount configuration featuring a 3.5 mm (0.138 in) centerline pitch.

    • Material & Flammability Grade: Constructed from black nylon insulation material conforming to UL 94 V-0 flammability standards, rated for operation between -40 deg C and +105 deg C.

    • Mechanical Interface: Utilizes an Ultra-Fit positive lock and mechanical keying structure to ensure proper polarization and prevent mismating during harness assembly.

    • Termination & Compatibility: Designed for crimp female socket contacts (sold separately) in free-hanging wire-to-board and wire-to-wire power applications.

  • 0430250408 Molex Micro-Fit 3.0 4-Position Receptacle Housing | Suqin

    0430250408 Molex Micro-Fit 3.0 4-Position Receptacle Housing | Suqin

    • Manufacturer & Series: Part number 0430250408 (Base product number 043025), manufactured by Molex as part of the Micro-Fit 3.0 connector series.

    • Structural Configuration: 4-position, 2-row free-hanging (in-line) receptacle housing featuring a 3.00 mm (0.118 in) centerline pitch and 3.00 mm (0.118 in) row spacing.

    • Mechanical Fastening: Equipped with an integrated latch lock mechanism to ensure positive locking engagement with mating headers or plugs.

    • Material & Thermal Integrity: Molded from black polyamide (PA) nylon insulation material, engineered to operate across a temperature range of -40 deg C to +105 deg C.

    • Termination & Interface: Designed for crimp-style female socket contacts (sold separately) for wire-to-wire and wire-to-board power and signal assemblies.

  • 39-01-2080 Molex Mini-Fit Jr. 8-Position Receptacle Housing | Suqin

    39-01-2080 Molex Mini-Fit Jr. 8-Position Receptacle Housing | Suqin

    • Manufacturer & Series: Part number 39-01-2080, engineered as a receptacle housing within the Molex Mini-Fit Jr. 5557 series.

    • Structural Configuration: 8-position, 2-row cable mount configuration featuring a 4.2 mm (0.165 in) centerline pitch and 4.2 mm (0.165 in) row spacing.

    • Electrical Limits: Rated for electrical power and signal applications up to 13 A current capacity and 600 V voltage rating.

    • Material & Thermal Integrity: Constructed from natural translucent nylon meeting UL 94 V-2 flammability standards, maintaining operational stability from -40 deg C to +105 deg C.

    • Mechanical Interface: Accepts crimp female socket contacts for wire-to-board and wire-to-wire power connections, utilizing a positive locking mechanism for secure mating retention.
