172258-3110 Molex Ultra-Fit 10-Position Receptacle Housing | Suqin
-
Manufacturer & Series: Part number 172258-3110, engineered as a receptacle housing within the Molex Ultra-Fit connector series.
-
Structural Configuration: 10-position, 2-row cable mount configuration featuring a 3.5 mm (0.138 in) centerline pitch and 3.5 mm (0.138 in) row spacing.
-
Application Scope: Designed for wire-to-board power circuit applications requiring reliable straight free-hanging connections.
-
Material & Thermal Integrity: Constructed from black nylon with a UL 94 V-0 flammability rating, maintaining structural and electrical stability across a temperature range of -40 deg C to +105 deg C.
-
Mechanical Design: Utilizes a crimp termination method to accommodate female socket contacts, incorporating a robust locking mechanism for secure mating retention.
-
-

172258-3114 Molex Ultra-Fit 14-Position Receptacle Housing | Suqin
-
Manufacturer & Series: Part number 172258-3114, engineered as a receptacle housing within the Molex Ultra-Fit connector series.
-
Structural Configuration: 14-position, 2-row cable mount configuration featuring a 3.5 mm (0.138 in) centerline pitch and 4.6 mm (0.181 in) row spacing.
-
Application Scope: Designed for wire-to-board power circuit applications requiring reliable straight free-hanging connections.
-
Material & Thermal Integrity: Constructed from black nylon with a UL 94 V-0 flammability rating, maintaining structural and electrical stability across a temperature range of -40 deg C to +105 deg C.
-
Mechanical Design: Utilizes a crimp termination method to accommodate female socket contacts, incorporating a robust locking mechanism for secure mating retention.
-
-

172258-3108 Molex Ultra-Fit 8-Position Receptacle Housing | Suqin
-
Manufacturer & Series: Part number 172258-3108, engineered as a receptacle housing within the Molex Ultra-Fit connector series.
-
Structural Configuration: 8-position, 2-row cable mount configuration featuring a 3.5 mm (0.138 in) centerline pitch and 4.6 mm (0.181 in) row spacing.
-
Application Scope: Designed for wire-to-board power circuit applications requiring reliable straight free-hanging connections.
-
Material & Thermal Integrity: Constructed from black nylon with a UL 94 V-0 flammability rating, maintaining structural and electrical stability across a temperature range of -40 °C to +105 °C.
-
Mechanical Design: Utilizes a crimp termination method to accommodate female socket contacts, incorporating a robust locking mechanism for secure mating retention.
-
-

33472-0606 Molex MX150 6-Position Female Receptacle | Suqin
-
Manufacturer & Series: Part number 33472-0606, an automotive-grade mat-sealed female connector assembly belonging to the Molex MX150 series.
-
Structural Configuration: 6-position, 2-row (2×3) cable mount receptacle featuring a standard 3.5 mm (0.138 in) pitch and Keying Option A in a black housing.
-
Electrical Ratings: Supports a maximum current rating of 22A, engineered for reliable power, wire-to-board, and wire-to-wire circuit applications.
-
Material & Thermal Integrity: Constructed from a modified polystyrene alloy (PS) housing, operating reliably across extreme temperatures from -40 °C to +125 °C.
-
Mechanical Design: Utilizes crimp termination and includes a Connector Position Assurance (CPA) mechanism to guarantee secure mating and prevent accidental disconnection.
-
-

Molex MX150 Series 0334721206 12-Position Sealed Receptacle Housing | Suqin
-
Manufacturer & Series: Manufactured by Molex under the high-performance MX150 sealed connector family (Part Number: 0334721206 / Base Number: 033472).
-
Configuration & Pitch: Features a 12-position rectangular housing in a dual-row (2 x 6) layout with a 3.50 mm [0.138 in] centerline pitch.
-
Locking & CPA Security: Utilizes an integrated latch holder mechanism coupled with a red Connector Position Assurance (CPA) slide lock to prevent accidental unmating under high vibration.
-
Material Composition: Constructed from a rugged, glass-filled Polyamide and Syndiotactic Polystyrene alloy blend (PA/SPS-GF20) for enhanced dimensional stability and chemical resistance.
-
Mating & Contacts: Designed to accommodate MX150 female socket crimp terminals (sold separately) and mates with corresponding MX150 male blade housings (such as the 33482 series).
-
-

Molex Micro-Fit 3.0 0436450600 6-Position Receptacle Housing | Suqin
-
Manufacturer & Series: Manufactured by Molex under the Micro-Fit 3.0 product family, belonging to the 043645 base product series with part number 0436450600.
-
Configuration & Layout: Features a 6-position single-row in-line configuration with a 3.00 mm (0.118 in) centerline pitch.
-
Locking Mechanism: Equipped with an integrated external passive latch lock mechanism to secure mechanical retention and prevent accidental unmating under physical stress.
-
Material Composition: Injection-molded from black thermoplastic polyester material, offering an operational temperature rating of -40°C to 105°C.
-
Mounting & Termination: Designed for free-hanging (in-line) cable wire harness assemblies, utilizing crimp termination methods for female socket contacts.
-
-

Molex MicroClasp 0513534000 40-Position Receptacle Housing | Suqin
-
Manufacturer & Series: Manufactured by Molex under the MicroClasp product family, belonging to the 051353 base product series with part number 0513534000.
-
Configuration & Layout: Features a high-density 40-position dual-row matrix layout with a 2.00 mm (0.079 in) centerline pitch and 5.00 mm (0.197 in) row-to-row spacing.
-
Locking Mechanism: Equipped with an integrated centralized external latch lock mechanism to secure structural retention against inadvertent demating under vibration.
-
Material Composition: Injection-molded from unsealed white Polyamide (PA66, Nylon 6/6) thermopolymer material offering a continuous operational temperature rating of -40°C to 105°C.
-
Mounting & Termination: Designed for free-hanging (in-line) cable wire harness assemblies, utilizing crimp termination methods for female socket contacts.
-
-

Molex Mini-Fit Jr. 0039012066 6-Position Panel Mount Plug Housing | Suqin
-
Manufacturer & Series: Manufactured by Molex under the Mini-Fit Jr. product family, belonging to the 5559 series with base part number 003901.
-
Configuration & Layout: Designed as a 6-position dual-row (2 x 3 matrix) rectangular connector housing with a 4.20 mm (0.165 in) pitch and row spacing.
-
Mounting & Integration: Engineered for panel mounting applications featuring integrated snap-in ears for toolless, secure chassis installation.
-
Material & Flammability: Constructed from high-integrity Polyamide (PA66, Nylon 6/6) insulation polymer in an ivory color finish.
-
Mating & Security: Utilizes a positive locking ramp mechanism for secure connection with compatible mating receptacle housings.
-
-

Molex stAK50h 1600290013 27-Position Hybrid Receptacle Housing | Suqin
-
Manufacturer & Series: Manufactured by Molex within the stAK50h product family, designated under the 160029 base series with part number 1600290013.
-
Configuration & Layout: Features a hybrid rectangular 27-position matrix layout, partitioned into 19 dedicated signal channels and 8 dedicated power channels.
-
Mechanical Locking & Verification: Equipped with an integrated primary latch lock mechanism paired with a secondary Connector Position Assurance (CPA) component.
-
Material Composition: Injection-molded from glass-filled Syndiotactic Polystyrene (SPS) insulation polymer, finished in a blue housing color specification.
-
Mounting & Termination: Optimized for free-hanging (in-line) cable mounting configurations utilizing crimp contact termination methods for female sockets.
-
