Molex Micro-Fit 3.0 0436450600 6-Position Receptacle Housing | Suqin
Short Description:
-
Manufacturer & Series: Manufactured by Molex under the Micro-Fit 3.0 product family, belonging to the 043645 base product series with part number 0436450600.
-
Configuration & Layout: Features a 6-position single-row in-line configuration with a 3.00 mm (0.118 in) centerline pitch.
-
Locking Mechanism: Equipped with an integrated external passive latch lock mechanism to secure mechanical retention and prevent accidental unmating under physical stress.
-
Material Composition: Injection-molded from black thermoplastic polyester material, offering an operational temperature rating of -40°C to 105°C.
-
Mounting & Termination: Designed for free-hanging (in-line) cable wire harness assemblies, utilizing crimp termination methods for female socket contacts.
Product Detail
Product Tags
Factory-original Molex Micro-Fit 3.0 Series 0436450600 6-position single-row receptacle housing. Features 3.00 mm pitch, black polyester insulation, and integrated latch lock. Available via Suzhou Suqin.
Data Overview
| Parameter | Technical Specification |
| Manufacturer | Molex |
| Part Number | 0436450600 (Alternative: 43645-0600) |
| Base Product Number | 043645 |
| Series | Micro-Fit 3.0 43645 |
| Product Category | Headers & Wire Housings |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Pitch | 3.00 mm (0.118 in) |
| Mounting Type | Free Hanging (In-Line) |
| Contact Termination | Crimp |
| Fastening Type | Latch Lock |
| Insulation Material | Polyester |
| Housing Color | Black |
| Operating Temperature Range | -40°C to 105°C |
| Packaging | Bulk / Bag |
| Part Status | Active |
| Note | Contacts Sold Separately |
Product Details
| Mechanical Structure & Mounting | Electrical Transmission & Insulation | Environmental Sealing & Material |
| 6-Position Single-Row Layout Features a space-saving 1 x 6 inline configuration integrated with a top-mounted active latch lock. | 3.00mm Pitch Grid Centerline pitch design engineered for high-density wire-to-board and wire-to-wire signal routing applications. | Polyester Insulation Shell Non-sealed, black thermoplastic shell built to withstand continuous operational temperatures of -40°C to 105°C. |
| Prevents terminal back-out and provides polarization to eliminate mis-mating errors during manual cable routing. | Formulated with solid partition barriers between terminal cavities to isolate electrical potentials and prevent cross-circuit shorting. | Ensures structural dimensional stability, dielectric insulation resistance, and mechanical durability under industrial environments. |
Our advantage
● Brand supply diversification,
Convenient one-stop shopping
● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.
● Complete information, fast delivery
Reduce intermediate links
● Good after-sales service
Quick response, professional reply
● Original genuine guarantee
Support professional consultation
● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.
Q1: Are the internal female socket crimp terminals included with the 0436450600 housing?
A: No. The 0436450600 part number corresponds strictly to the empty plastic receptacle housing block. Internal female crimp socket terminals (such as Molex 43030 series) must be ordered separately to match your wire gauge requirements (typically 18-30 AWG).
Q2: Is this Micro-Fit 3.0 housing compatible with standard Micro-Fit series plugs?
A: Yes. The 0436450600 receptacle housing is designed to mate with 43640 series single-row plug housings (for wire-to-wire configurations) and 43650 series single-row headers (for wire-to-board configurations).
Q3: Does this 43645 series housing provide environmental or water ingress protection?
A: No. This connector is a non-sealed rectangular housing manufactured from polyester thermoplastic material. It is engineered for indoor, protected control boxes, or industrial electronics enclosures where direct exposure to water or high moisture is not present.
