51110-1060 Connectors 2.00mm Pitch, Milli-Grid Receptacle Housing MOLEX
Short Description:
2.00mm Pitch
Milli-Grid Receptacle Housing
10 Circuits
without Center Polarization Key
with Locking Ramp
Lead-Free
Product Detail
Product Tags
Molex 51110-1060 Milli-Grid™ Receptacle Housing Connector Datasheet
Pitch：2.00mm (.079″)
Circuits：10-position
Polarization：Without center key design
Locking Mechanism：Integrated locking ramp
Contact Compatibility：50394-8051/8052 crimp contacts
Current Rating：4.5A per circuit
Contact Resistance ：40 mΩ (tin-plated option)
Environmental：RoHS-compliant, lead-free
Operating Temp：-40°C to +105°C
Data Overview
| Circuits (maximum) | 10 |
| Flammability | 94V-0 |
| Number of Rows | 2 |
| Net Weight | 0.212/g |
| Color – Resin | Black |
Contact Features
| Gender | Receptacle |
| Material – Resin | Polyester |
| Pitch – Mating Interface | 2.00mm |
| Packaging Type | Bag |
| Temperature Range – Operating | -40° to +105°C |
