Amphenol AT04-08PA-BM04 BoardLock™ | 8-Pin Gray PCB Receptacle IP67

Short Description:

Manufacturer: Amphenol SINE Systems
Part Number: AT04-08PA-BM04
Series: AT Series (BoardLock™)
Number of Positions: 8 Position (2 Rows)
Connector Type: Receptacle (Female Housing) with Male Pins
Mounting Type: PCB Board Mount (Straight / Solder Pin)
Current Rating: 13 Amps
Ingress Protection: IP67 (Sealed)
Operating Temp: -55°C to +125°C
Mating Part: Compatible with AT06-08SA plugs

Product Detail

Product Tags

Shop Amphenol AT04-08PA-BM04 BoardLock™ series. An 8-position, gray PCB mount receptacle with nickel-plated contacts. IP67 rated, 13A current, and -55°C to 125°C range for rugged board-to-wire applications.

Data Overview

Attribute	Specification
Brand	Amphenol SINE Systems
Part Number	AT04-08PA-BM04
Tradename	BoardLock™
Number of Positions	8
Number of Rows	2
Contact Type / Plating	Male Pin / Nickel
Current Rating	13 A
Voltage Rating	250 V
Termination Style	Solder Pin
Mounting Style	PCB Mount (Straight)
Ingress Protection	IP67
Housing Material	Thermoplastic (TP)
Dimensions (L x W x H)	36.4 mm x 22.5 mm x 21.2 mm
Insulation Resistance	1 GOhms

Product Details

Product Features	Engineering Advantages	Customer Benefits
BoardLock™ Integrated PCB Mount	Features specialized solder pins and potting features for direct board integration.	Simplified Manufacturing: Eliminates the need for manual wire-to-board transitions, reducing assembly time and footprint on the PCB while enhancing structural stability.
IP67 Rated Environmental Seal	Designed with high-performance thermoplastic and seals to resist moisture and dust.	Proven Reliability: Protects sensitive PCB components from water ingress and harsh environmental contaminants, ensuring long-term system integrity in outdoor or off-road conditions.
Nickel-Plated Copper Alloy Pins	High-conductivity male pins with 13A current capacity and low resistance.	Efficient Power Delivery: Provides stable electrical performance for power and signal distribution, reducing heat buildup and preventing circuit failures under load.
Rugged Thermoplastic (TP) Housing	Withstands extreme temperatures from -55°C to 125°C and offers high insulation.	All-Climate Dependability: Ensures the connector housing remains stable and crack-resistant in extreme cold or intense heat, ideal for heavy-duty industrial machinery.

Our advantage

● Brand supply diversification,
Convenient one-stop shopping

● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.

● Complete information, fast delivery
Reduce intermediate links

● Good after-sales service
Quick response, professional reply

● Original genuine guarantee
Support professional consultation

● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.

Q1: Is the AT04-08PA-BM04 compatible with DEUTSCH DT series plugs?

A: Yes, the Amphenol AT series is designed to be fully intermateable with the industry-standard DEUTSCH DT 8-pin series (e.g., DT06-08SA), providing a high-quality alternative for PCB-integrated designs.

Q2: What is the benefit of the “BoardLock™” feature?

A: BoardLock™ technology refers to Amphenol’s specialized design for board-level integration. It includes features that allow for potting (sealing the back of the board) and secure mechanical attachment, which is essential for protecting the PCB in high-vibration automotive or industrial environments.

Q3: Can this connector withstand high-pressure washdowns?

A: Yes, when properly mated with a compatible AT series plug, the connection is rated IP67, meaning it is dust-tight and can withstand immersion in water up to 1 meter, making it suitable for exterior-mounted electronics.
