Amphenol PCD HVSL362062B116I 2-Pole HV Plug with HVIL | 6 AWG
Short Description:
-
Manufacturer: Amphenol PCD Shenzhen
-
Part Number: HVSL362062B116I
-
Series: Excel|mate HVSL Series
-
Configuration: 2-Pole Power Positions + HVIL
-
Gender: Plug (Housing for Female Sockets)
-
Wire Gauge: 6 AWG (Discrete Wire)
-
Ingress Protection: Environmental Sealed (Typically IP67)
-
Contact Finish: Gold Plated
-
Voltage Architecture: Typically up to 1000V DC
-
Features: Integrated High Voltage Interlock Loop (HVIL)
-
Color: Orange (HV Standard)
Product Detail
Product Tags
Shop Amphenol PCD HVSL362062B116I. A high-performance 2-pole sealed plug connector with integrated HVIL from the Excel|mate series. Designed for 6 AWG discrete wire with gold-plated female sockets and robust latch lock. Ideal for safe high-voltage power in EVs and industrial machinery.
Data Overview
| Attribute Category | Technical Specification |
| Brand | Amphenol PCD Shenzhen |
| Part Number | HVSL362062B116I |
| Connector Series | Excel |
| Connector Type | Environment Environmentally Sealed Plug (Cable End) |
| Number of Positions | 2 Power Poles |
| Secondary Function | Integrated High Voltage Interlock Loop (HVIL) |
| Contact Gender | Female Socket |
| Contact Plating | Gold Plated (Over Nickel) |
| Compatible Wire Gauge | 6 AWG Discrete Wire |
| Termination Style | Crimp |
| Locking Type | Primary Latch Lock (with HVIL) |
| Color | Orange (HV Power Identification) |
| IP Rating (Sealed) | Typically IP67 (Mated) |
| Rated Voltage (Typical) | Up to 1000V DC |
| Current Rating (Approx.) | Typically ~120A (Dependent on Wire/Contact) |
| Operating Temp (Max) | Typically -40°C to +125°C |
Product Details
| Features & Technology | Engineering Advantages | Strategic Benefits |
| Integrated HVIL (High Voltage Interlock Loop) | Incorporates a secondary circuit loop that monitors the mating state of the connector. | Critical Operator Safety Measure: Specifically breaks the low-voltage interlock signal circuit before the main power contacts are disconnected when uncoupling under load. This prevents hazardous arcing and protects personnel from electric shock. |
| High-Current 6 AWG Contact System | Features robust female socket contacts sized for substantial 6 AWG power conductors. | Efficient High-Power Transfer: Designed to handle continuous heavy-current loads (typically ~120A) necessary for EV battery connections or industrial power modules, ensuring minimal power loss. |
| Gold-Plated Contact Interface | Optimizes the female contacts with ultra-low contact resistance and superior conductivity. | Drastic Reduction in Heat Generation: Minimizes resistive heating at the connection point, extending the long-term reliability of both the connector and wire insulation in high-thermal-cycle applications. |
| Rugged Latch Locking & Environment Sealed | Utilizes a positive latch lock for secure mating and high-performance environmental seals. | Anti-Vibration & Extreme Durability: Guarantees connection integrity under intense vehicle vibrations and prevents moisture, dust, and corrosive automotive fluids from entering, extending vehicle service life in harsh environments (underbody/engine bay). |
