JAE MX80A04SZ1A 4-Pin Waterproof Connector Housing | IP67 Sealed Socket

Short Description:

Manufacturer: JAE Electronics
Part Number: MX80A04SZ1A
Series: MX80 Series (Ultra-Compact Waterproof)
Positions: 4 Position (Single Row)
Pitch: 2.54 mm (0.100″)
Connector Type: Female Socket Housing
Ingress Protection: IP67 (Mated condition)
Temperature Range: -40°C to +125°C
Material: Glass-Filled PBT (Black)
Locking Style: Positive Latch Lock
Key Application: Automotive side mirrors, cameras, and sensors.

Product Detail

Product Tags

Shop JAE MX80A04SZ1A 4-way waterproof socket housing. Features a compact 2.54mm pitch, IP67 sealing, and -40°C to 125°C range. Ideal for space-constrained automotive sensors and mirror applications. Reliable and durable.

Data Overview

Attribute Category	Technical Specification
Brand	JAE Electronics
Model	MX80A04SZ1A
Base Product Number	MX80A
Number of Positions	4
Pitch (Mating)	2.54 mm (0.100″)
Connector Type	Socket (Female Housing)
Contact Type	Female Socket (Contacts sold separately)
Mounting Type	Free Hanging (In-Line)
Termination Style	Crimp
Color	Black
Operating Temp Range	-40°C to +125°C
Ingress Protection	IP67 (Dust Tight, Water Resistant)
Material Flammability	UL 94V-0 (Compatible)

Product Details

Product Features & Specs	Technical Advantages	Strategic Business Benefits
Ultra-Compact 2.54mm Pitch Design	Drastically reduces the footprint compared to standard waterproof connectors.	Space Optimization: Allows engineers to integrate more sensors into tight spaces like rear-view mirrors and LED lighting modules, enabling sleeker vehicle designs.
IP67 Rated Environmental Sealing	Integrated silicone rubber seal prevents the ingress of high-pressure water and dust.	Zero Maintenance Reliability: Eliminates intermittent signal failures caused by moisture corrosion, significantly lowering vehicle warranty costs and improving safety ratings.
Glass-Filled PBT Construction	Provides exceptional structural rigidity and thermal stability up to 125°C.	Engine-Grade Durability: Ensures the connector remains functional in high-vibration and high-heat environments, preventing cracking or melting over the vehicle’s lifespan.
Integrated Latch Locking Mechanism	Features an audible “click” during mating to confirm a secure connection.	Enhanced Assembly Efficiency: Simplifies manual installation on assembly lines and prevents accidental disconnection due to road shock or human error.

Our advantage

● Brand supply diversification,
Convenient one-stop shopping

● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.

● Complete information, fast delivery
Reduce intermediate links

● Good after-sales service
Quick response, professional reply

● Original genuine guarantee
Support professional consultation

● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.

Q1: Does the MX80A04SZ1A housing come with female contacts?

A: No, the MX80A04SZ1A is a housing-only component. You must order the MX80 series female crimp contacts separately. We recommend selecting the appropriate terminal based on your wire gauge (typically 0.13 to 0.35 mm²) for optimal IP67 sealing.

Q2: Is this connector suitable for high-temperature areas near the engine?

A: Yes, it is rated for operating temperatures between -40°C and +125°C. Its glass-filled PBT construction makes it ideal for harsh automotive environments, including under-hood sensor applications where thermal cycling is frequent.

Q3: Can I use this connector for non-automotive applications?

A: Absolutely. While designed for automotive standards, the MX80A04SZ1A is an excellent choice for any industrial or outdoor application requiring a miniaturized, waterproof connection, such as outdoor LED signage, drones, or marine electronics.
