JST 03T-JWPF-VSLE-S | 3 Pin Waterproof Plug Housing | JWPF Series

Short Description:

Manufacturer: JST Sales America Inc.
Part Number: 03T-JWPF-VSLE-S
Series: JWPF (Waterproof/Sealed)
Number of Positions: 3 Pin (Single Row)
Pitch (Centerline): 2.00 mm (0.079″)
Ingress Protection: JIS C 0920 Grade Level 7 (IPX7 equivalent)
Insulation Material: Polybutylene Terephthalate (PBT)
Connector Type: Plug Housing for Male Pins
Operating Temperature: -55°C to 85°C
Application: Automotive, Outdoor Electronics, Power Distribution

Product Detail

Product Tags

Shop original JST 03T-JWPF-VSLE-S 3-pin waterproof plug housings. 2.00mm pitch, PBT material, JIS C 0920 Grade 7 (IPX7 equivalent). Reliable sealed connection for power & signal.

Data Overview

Attribute Category	Technical Specification
Brand	JST Sales America Inc.
Model / PN	03T-JWPF-VSLE-S
Connector Type	Plug Housing
Contact Type	Male Pin
Number of Positions	3
Pitch	2.00 mm (0.079″)
Housing Material	PBT (Natural Color)
Mounting Type	Free Hanging (In-Line)
Contact Termination	Crimp
Operating Voltage/Temp	-55°C ~ 85°C
Status	Active
Packaging	Bulk

Product Details

Waterproof & Environmental Excellence	Secure Mechanical Integrity	Compact & Efficient Integration
JIS C 0920 Grade 7 Compliance	Engineered with advanced sealing technology to meet Grade 7 standards, ensuring protection against temporary immersion in water.	Superior Protection: Provides a reliable hermetic seal for outdoor and high-humidity environments, preventing circuit corrosion and failure.
Latch Holder Fastening Type	Features a robust integrated latch mechanism that ensures a positive click-lock during mating.	Vibration Resistance: Prevents accidental decoupling in dynamic automotive or industrial applications, maintaining continuous power flow.
2.0mm Ultra-Compact Pitch	High-density 2.0mm spacing allows for significant space savings without compromising electrical performance.	Miniaturization: Ideal for modern portable electronics and compact vehicle wire harnesses where PCB/panel real estate is limited.
Premium PBT Insulation	Constructed from high-grade Polybutylene Terephthalate (PBT) for excellent chemical and thermal resistance.	Extreme Durability: Maintains mechanical stability across a wide temperature range (-55°C to 85°C), ensuring long-term field reliability.
