JST ZNDP-10V-A-S | 10-Position 1.50mm Pitch ZND Series Receptacle Housing
Short Description:
-
Manufacturer: JST Sales America Inc.
-
Series: ZND Series
-
Part Number: ZNDP-10V-A-S
-
Positions: 10 Positions
-
Pitch: 1.50mm (0.059″)
-
Connector Type: Receptacle Housing
-
Fastening Type: Latch Lock
-
Material: Glass-Filled Polyamide (PA66) / Nylon 6/6
-
Keying: Controlled Key Design
-
Mounting: Free Hanging (In-Line)
-
Operating Temp: -25°C to 85°C
Product Detail
Product Tags
Purchase genuine JST ZNDP-10V-A-S 10-position receptacle housings at Suzhou Suqin. 1.50mm pitch, PA66 glass-filled material, with latch lock and controlled keying for secure, error-free industrial signal connections.
Data Overview
| Attribute Category | Technical Specifications |
| Manufacturer | JST Sales America Inc. |
| Series | ZND Series |
| Part Number | ZNDP-10V-A-S |
| Connector Type | Receptacle Housing |
| Contact Type | Female Socket |
| Number of Positions | 10 |
| Number of Rows | 1 |
| Pitch (Centerline) | 1.50mm (0.059″) |
| Mounting Type | Free Hanging (In-Line) |
| Termination Method | Crimp |
| Housing Color | Natural |
| Material (Insulation) | Polyamide (PA66), Nylon 6/6, Glass Filled |
| Operating Temperature | -25°C to 85°C |
Product Details
| Error-Proof Design with Controlled Keying | Secure Mechanical Stability (Latch Lock) | High-Performance Material Science |
| Precision Controlled Keying Feature: Features a specialized keying structure that ensures only compatible components can mate. | Integrated Latch Lock Fastening: Engineered with a robust internal latching mechanism that provides a positive tactile “click” during mating. | Glass-Filled Polyamide (PA66) Construction: Manufactured using premium Nylon 6/6 reinforced with glass fiber for superior rigidity. |
| Mismating Prevention: This physical barrier prevents accidental incorrect connections during high-speed assembly or field maintenance. | High Retention Force: Protects against accidental disconnection caused by industrial vibration or mechanical stress on the wire-to-board link. | Thermal & Chemical Resistance: Maintains structural integrity and electrical insulation across a wide temperature range of -25°C to 85°C. |
| Benefit: Eliminates potential short circuits and system failures caused by human error, drastically improving assembly yield and device safety. | Benefit: Guarantees uninterrupted signal integrity in demanding environments, reducing costly downtime and field service calls. | Benefit: Extends the operational lifespan of the connection in harsh industrial environments, ensuring long-term product reliability. |
