JST SM Series SMP-10V-BC 10-Position Plug Housing Black | Suqin
Short Description:
-
Manufacturer & Series: JST (JST Commercial) SM series 10-position single-row wire housing, classified as a plug gender component under part number SMP-10V-BC.
-
Locking Mechanism: Equipped with an integrated mechanical arm lock assembly built into the black housing shell for secure locking retention.
-
Mounting & Termination: Designed for cable mount / free-hanging installation utilizing a crimp termination style for wire-to-wire circuit applications.
-
Electrical Capacity: Engineered to support a maximum continuous current rating of 3 A and an operational voltage architecture of 250 VAC / 250 VDC.
-
Wire Range & Pitch: Features a 2.5 mm (0.098 in) centerline pitch, compatible with conductor wire gauges spanning from 28 AWG to 22 AWG.
Product Detail
Product Tags
Factory-original JST SM Series SMP-10V-BC 10-position single-row plug housing with an integrated arm lock. Features a 2.5 mm pitch, cable mount style, and 250 VAC/VDC voltage rating. Available via Suzhou Suqin.
Data Overview
| Parameter | Technical Specification |
| Manufacturer | JST (JST Commercial) |
| Part Number | SMP-10V-BC |
| Series | SM Series |
| Product Type | Wire Housings (Headers & Wire Housings) |
| Housing Gender / Type | Plug |
| Number of Positions | 10 Position |
| Number of Rows | 1 Row |
| Centerline Pitch | 2.5 mm (0.098 in) |
| Mounting Style | Cable Mount / Free Hanging |
| Termination Style | Crimp |
| Mounting Angle | Straight |
| Locking Feature | Integrated Arm Lock |
| Application | Wire-to-Wire |
| Compatible Wire Gauge | 28 AWG to 22 AWG |
| Current Rating | 3 A |
| Voltage Rating | 250 VAC, 250 VDC |
| Insulation Resistance | 500 MOhms Minimum |
| Housing Color | Black |
| Compatible Contact Gender | Pin (Male) / Socket (Female) Specification Matching |
| Compatible Contact Material | Phosphor Bronze / Tin Plated |
| Operating Temperature Range | -25°C to 85°C |
| RoHS Status | Compliant |
Product Details
| Mechanical Structure & Locking | Electrical Transmission & Insulation | Wire Adaptation & Temperature |
| 10-Position Arm Lock Plug Single-row rectangular plug shell featuring integrated dual-sided molding arm lock latches. | 250V / 3A Single-Row Grid 2.5 mm pitch layout providing an insulation resistance barrier of 500 MOhms minimum. | 22-28 AWG Wire-to-Wire Casing Straight entry housing accommodating compatible phosphor bronze tin-plated contacts. |
| Delivers secure point-to-point mating retention, preventing accidental harness disconnection under pull forces. | Prevents high-voltage leakage and cross-circuit tracking across 10 independent signal or low-power channels. | Permits standard crimp-to-wire assembly across standard wire gauges within a -25°C to 85°C thermal range. |
Our advantage
● Brand supply diversification,
Convenient one-stop shopping
● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.
● Complete information, fast delivery
Reduce intermediate links
● Good after-sales service
Quick response, professional reply
● Original genuine guarantee
Support professional consultation
● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.
Q1: Are the internal metal crimp terminals included with the SMP-10V-BC housing?
A: No. The SMP-10V-BC part number specifies the 10-position plastic plug housing only. The matching phosphor bronze tin-plated crimp contacts (supporting 22 AWG to 28 AWG wire sizes) must be specified and purchased as separate line items.
Q2: What functional mechanism does the “Arm Lock” provide on this SM Series housing?
A: The arm lock is an integrated friction and mechanical latching mechanism molded into both sides of the connector body. Upon mating the plug with a corresponding SM Series receptacle, the latches lock automatically to resist external wire pull forces and mechanical vibration.
Q3: Can this housing be utilized in outdoor or high-moisture exposure environments?
A: No. According to the manufacturer specifications, this component is an unsealed wire housing. Applications exposed to moisture, dust, or liquid splash require secondary environmental protection, such as waterproof enclosures or heat-shrink sealing jackets.
