Molex 105308-1216 Nano-Fit TPA Receptacle Housing Dual Row 16 Ckt | Suqin
Short Description:
-
Manufacturer and Series: Molex Nano-Fit 105308 Series, Part Number 105308-1216 (Aliases: 1053081216 / 01053081216).
-
Housing Type: Dual-row crimp receptacle housing with 16 circuits (positions), designed for straight wire-to-board applications.
-
Pitch and Spacing: Features 2.5 mm pitch and 2.5 mm row spacing for high-density electronic layouts.
-
TPA Integration: Compatible with optional Nano-Fit Terminal Position Assurance (TPA) retainers to secure terminals.
-
Electrical Ratings: Maximum current rating of 6.5A per circuit, compatible with socket (female) contact crimp terminals.
-
Material and Temperature: Molded from black Nylon meeting UL 94 V-0 flammability standards; operating range from -40 to +115 degrees Celsius.
-
Sourcing Availability: Factory-direct wholesale distribution via Suzhou Suqin with standard bulk packaging for tier-1 manufacturing supply chains.
Product Detail
Product Tags
Sourcing Molex 105308-1216 Nano-Fit TPA receptacle housings from Suzhou Suqin. Features 2.5mm pitch, dual row, 16 circuits black crimp housing for wire-to-board power configurations.
Data Overview
| Technical Parameter | Specification Value |
| Manufacturer | Molex |
| Product Category | Headers and Wire Housings |
| Part Number / MPN | 105308-1216 |
| Part Number Aliases | 1053081216 / 01053081216 |
| Tradename / Series | Nano-Fit / 105308 |
| Product Type | Wire Housings (Receptacle Housing) |
| Application Environment | Wire-to-Board Power / Signal Systems |
| Number of Positions (Circuits) | 16 Position |
| Number of Rows | 2 Row |
| Pitch | 2.5 mm (0.098 in) |
| Row Spacing | 2.5 mm (0.098 in) |
| Mounting Style | Cable Mount / Free Hanging |
| Termination Style | Crimp |
| Mounting Angle | Straight |
| Contact Gender | Socket (Female) |
| Housing Material | Nylon |
| Housing Color | Black |
| Flammability Rating | UL 94 V-0 |
| Current Rating | 6.5 A |
| Operating Temperature Range | -40 to +115 degrees Celsius |
| Unit Weight | 1.340 g |
| Packaging Format | Bulk |
Product Details
| Features (Design & Specs) | Advantages (Mechanical & Electrical) | Engineering & Supply Benefits |
| 2.5 mm Pitch Dual-Row Geometry | Lowers the required PCB real estate compared to standard 3.96 mm power connectors while maintaining a 16-circuit capacity. | Enables product designers to decrease overall board dimensions in space-constrained electronic modules. |
| Integrated Housing Lock & TPA Slot | Provides positive locking latch engagement with an audible click and accepts secondary terminal position verification retainers. | Prevents contact back-outs during wire harness routing and eliminates accidental unmating under continuous operational vibration. |
| Fully Isolated Crimp Cavities | Uses individual deep nylon walls to separate adjacent female socket terminals, blocking external dust and debris. | Minimizes the risk of electrical shorting or arcing between circuits, ensuring stable power delivery across the connector interface. |
| UL 94 V-0 Flame-Retardant Nylon | Withstands constant thermal exposure up to 115 degrees Celsius without structural degradation or loss of insulation properties. | Meets standard industrial safety and flammability regulations for power supplies, industrial controls, and medical appliances. |
