TE Connectivity 794954-2 2-Position VAL-U-LOK Receptacle Housing | Suqin
Short Description:
-
Manufacturer & Series: Manufactured by TE Connectivity under the VAL-U-LOK product family, designated with part number 794954-2 as a receptacle housing.
-
Configuration & Layout: Features a 2-position dual-row (2 x 1 grid) inline configuration with a 4.2 mm (0.165 in) centerline pitch and row-to-row spacing.
-
Electrical Ratings: Engineered to support an operating voltage up to 600 VAC for concurrent power and signal circuit applications.
-
Material & Flammability: Molded from natural-colored nylon thermopolymer resin achieving a standard UL 94V-2 flammability rating.
-
Mechanical Mounting & Range: Designed for free-hanging (cable mount) termination utilizing crimp methods, compatible with insulation diameters ranging from 1.2 mm to 3.1 mm (0.047 in to 0.122 in).
Product Detail
Product Tags
Factory-original TE Connectivity VAL-U-LOK Series 794954-2 2-position dual-row free-hanging receptacle housing. Features UL 94V-2 natural nylon construction, 4.2 mm pitch, and 600 VAC rating. Available via Suzhou Suqin.
Data Overview
| Parameter | Technical Specification |
| Manufacturer | TE Connectivity |
| Part Number | 794954-2 |
| Series / Tradename | VAL-U-LOK |
| Product Category | Power Connectors |
| Connector Product Type | Housing |
| Connector & Housing Type | Receptacle |
| Number of Positions | 2 |
| Number of Rows | 2 (2 x 1 Arrangement) |
| Centerline (Pitch) | 4.2 mm [0.165 in] |
| Row-to-Row Spacing | 4.2 mm [0.165 in] |
| Operating Voltage | 600 VAC |
| Connector System | Wire-to-Board / Wire-to-Wire |
| Termination Method | Crimp |
| Connector Mounting Type | Cable Mount (Free-Hanging) |
| Insertion Force | 15 N |
| Primary Product Color | Natural |
| Housing Material | Nylon |
| Flammability Rating | UL 94V-2 |
| Sealable | No |
| Contact Layout / Type | Inline / Receptacle |
| Connector Length | 5.4 mm [0.21 in] |
| Connector Height | 10.8 mm [0.425 in] |
| Connector Width | 20 mm [0.787 in] |
| Compatible Insulation Diameter Range | 1.2 – 3.1 mm [0.047 – .122 in] |
| Operating Temperature Range | -40°C to +105°C [-40°F to +221°F] |
| Circuit Application | Power & Signal |
Product Details
| Mechanical Structure & Mounting | Electrical Transmission & Insulation | Environmental Sealing & Material |
| 2-Position Free-Hanging Housing Dual-row 2-circuit inline receptacle housing equipped with an integrated external mechanical locking latch. | 600 VAC High-Voltage Grid 4.2 mm pitch contact matrix designed for reliable power and signal wire-to-wire or wire-to-board routing. | UL 94V-2 Natural Nylon Shell Non-sealable nylon polymer base housing offering structural isolation and an operational range of -40°C to +105°C. |
| Provides a positive mechanical lock to prevent accidental unmating while maintaining a 15 N insertion force requirement. | Delivers robust electrical isolation between the 2 inline circuits under high-voltage environments across industrial wire applications. | Ensures compliance with standard flammability guidelines while accommodating wire insulation diameters up to 3.1 mm. |
Our advantage
● Brand supply diversification,
Convenient one-stop shopping
● Covers a wide range of fields
Automobile, electromechanical, industrial, communication, etc.
● Complete information, fast delivery
Reduce intermediate links
● Good after-sales service
Quick response, professional reply
● Original genuine guarantee
Support professional consultation
● After-sales problems
Ensure that the imported original products are genuine. If there is a quality problem, it will be solved within one month of receiving the goods.
Q1: Are crimp terminals included inside the factory bulk packaging of part number 794954-2?
A: No. Part number 794954-2 refers exclusively to the empty plastic receptacle housing. The matching female crimp contacts must be selected and ordered as separate line items based on your specific wire gauge requirements.
Q2: Why is the 794954-2 classified as a 2-row connector when it only has 2 total positions?
A: The connector features a 2 x 1 matrix orientation, meaning it has 1 column and 2 rows. This vertical stacking layout minimizes the horizontal footprint on wire-to-board or wire-to-wire connections where space is constrained.
Q3: What are the strict limitations regarding wire insulation diameters for this VAL-U-LOK housing?
A: To ensure correct terminal insertion and secure retention within the nylon housing cavities, the wire insulation outer diameter must fall strictly within the range of 1.2 mm to 3.1 mm (0.047 in to 0.122 in).
