1-1718646-1 | TE 3-Pin Heavy Duty Sealed Connector Series (AMP MCP) Receptacle Housing Coding A
-
Manufacturer: TE Connectivity / AMP
-
Series: Heavy Duty Sealed Connector Series (HDSCS) / AMP MCP 2.8
-
Part Number: 1-1718646-1
-
Number of Positions: 3 Positions
-
Number of Rows: 1 Row
-
Connector Type: Housing for Female Terminals (Receptacle)
-
Sealable: Yes (Waterproof / Dustproof Environmentally Sealed)
-
Keying Code: Coding A
-
Primary Product Color: Black
-
Housing Material: PBT GF (Glass Fiber Reinforced Polybutylene Terephthalate)
-
Mating Tab Width: 2.8 mm (.11 in)
-
Connector System: Wire-to-Board | Wire-to-Device | Wire-to-Wire
-
Mating Alignment: Keyed (Coding A Mechancial Alignment)
-
Operating Temperature Range: -40°C to 140°C (-40°F to 284°F)
-
-
MG610335-5 6pin waterproof Automotive Connector KET Female Connector
-
Manufacturer: KET (Korea Electric Terminal)
-
Part Number: MG610335-5
-
Series: SWP Series
-
Number of Positions: 6 Way (Dual Row)
-
Gender: Female Receptacle
-
Sealing Rating: Waterproof (High-Performance Sealing)
-
Pitch: 6.2 mm (Large Pitch for High Power/Signal Isolation)
-
Housing Material: PBT (Polybutylene Terephthalate)
-
Color: Black
-
Application: Engine compartments, chassis wiring, industrial marine equipment.
-
-
Sumitomo 8240-0531 | Sealed Female Terminal 0.3-0.5mm² | Tin Plated
-
Manufacturer: Sumitomo Wiring Systems
-
Part Number: 8240-0531
-
Type: Receptacle / Female Terminal
-
Sealing Type: Sealed (Waterproof Application)
-
Wire Range: 0.3 – 0.5 mm²
-
Plating Material: Tin (Sn)
-
Operating Temp: -40°C to +120°C
-
Main Function: Signal/Power transmission with waterproof fixation
-
Application: Automotive Engine Bay, Chassis, and Sensor Harnesses
-
-
Sumitomo 6189-8093 20-Pin Female Sealed Connector | Automotive Plug
-
Manufacturer: Sumitomo
-
Part Number: 6189-8093
-
Number of Positions: 20 Pin (Dual Row)
-
Connector Type: Female Housing (Socket)
-
Sealing Type: Sealed (Waterproof / Dustproof)
-
Housing Material: High-Grade PBT (Black)
-
Terminal Compatibility: 0.64mm / 1.5mm Series (System dependent)
-
Operating Temp: -40°C to +125°C
-
Primary Application: Dashboard, ECU, Infotainment, Body Control Modules.
-
-
N022524434C: Automotive TERMINAL(S) FOR AMPHENOL 3.6mm RADSOK Power Contact
-
Manufacturer: Amphenol
-
Part Number: N022524434C
-
Series: RADSOK® / RadLok™
-
Contact Type: Socket (Female Terminal)
-
Contact Size: 3.6 mm
-
Current Capacity: 70A – 100A (Depending on wire gauge)
-
Termination Style: Crimp
-
Plating: Silver (Ag) or Nickel (Ni) specialized coating
-
Applications: EV/HEV Battery Systems, Power Storage (ESS), Heavy Machinery.
-
Mating Cycles: 500+ Cycles (High Durability)
-
-
KUM TN025-00200 Female Crimp Terminal | 0.64mm (025) Series
-
Manufacturer: KUM (Korea Electric Terminal)
-
Part Number: TN025-00200
-
Series: 025 (0.64 mm) Series
-
Terminal Type: Female Crimp Terminal
-
Contact Material: Phosphor Bronze (Superior Conductivity)
-
Gender: Female (Receptacle)
-
Operating Temperature: -40°C to +105°C
-
Application: Automotive Signal, ECU, BCM, and Sensor Systems.
-
Mounting: Compatible with KUM 025 Series Connector Housings.
-
-
Amphenol HVC2P28FS104 Automobile connector 2-core plug sheath plastic
-
Manufacturer: Aptiv (formerly Delphi)
-
Part Number: HVC2P28FS104
-
Series: HVC 280 (High Voltage Connector)
-
Number of Positions: 2 Position
-
Gender: Female (Receptacle)
-
Current Rating: Up to 40A (Dependent on wire gauge)
-
Operating Voltage: Up to 600V – 1000V DC (Typical for HVC series)
-
Safety Features: Integrated HVIL (High Voltage Interlock Loop)
-
Shielding: 360° EMI/RFI Shielding for signal integrity
-
Sealing: IP67 / IP6K9K (Mated)
-
-
AT04-12PA-BM02 Automotive Connectors 12 Position PCB Flangeless (Snap Fit) Board MountReceptacle Amphenol
12 Position PCB Flangeless (Snap Fit) Board MountReceptacle,
Pin
Gold Plated Contacts Included
Potting
Grey -
ATP04-2P-PM07G 2 Pin Receptacle Amphenol
No. of Positions: 2
Housing Material: Thermoplastic
Seal: Silicone Rubber
Mating Cycles: 100
AWG: 10-14
Amperage: 25A
Contact Type (Pin/Socket): Pin
Color: Black
