Molex 5055650801 Micro-Lock PLUS Receptacle | 8-Pin, 1.25mm Pitch, Black
- Manufacturer: Molex
- Part Number: 5055650801
- Series: Micro-Lock PLUS 505565
- Number of Positions: 8 Positions, Single Row
- Pitch: 1.25mm (0.049″)
- Connector Type: Receptacle Housing (Female Socket)
- Mounting Type: Free Hanging (In-Line)
- Material: Black Polybutylene Terephthalate (PBT)
- Operating Temp: -40°C to 105°C
- Note: Contacts are not included and must be purchased separately.
-

Molex 0334721201 MX150 Mat-Sealed Female Connector | 12-Circuit, Key A, Black
- Manufacturer: Molex
- Part Number: 0334721201 (33472 Series)
- Product Line: MX150 Sealed Connector System
- Circuits: 12 Positions (Dual Row)
- Gender: Receptacle (Female Housing)
- Keying: Keying Option A (Black)
- Pitch: 3.50mm Mating Interface
- Sealing: Mat-Sealed (Waterproof/Dustproof)
- Temperature Range: -40°C to +125°C
- Material: High-performance SPS/Nylon
-

Molex 105308-1208 Nano-Fit Receptacle Housing | 8-Pos, 2.50mm Pitch, Dual Row
- Manufacturer: Molex
- Part Number: 105308-1208 (Series: Nano-Fit)
- Configuration: 8 Positions, Dual Row (2 x 4)
- Pitch & Row Spacing: 2.50 mm (0.098 in)
- Connector Type: Receptacle (Crimp Style)
- Fastening Type: Positive Latch Lock
- Material: Polyamide (PA4T), Glass Filled
- Mounting Type: Free Hanging / In-Line
- Note: Terminals/Contacts sold separately.
-

Molex 43640-0400 Micro-Fit 3.0 Plug Housing | 4-Pin, 3mm Pitch, Panel Mount
- Manufacturer: Molex
- Part Number: 43640-0400 (Alias: 0436400400)
- Series: Micro-Fit 3.0 (Series 43640)
- Configuration: 4 Positions, Single Row
- Pitch: 3.00 mm (0.118 in)
- Mounting Type: Panel Mount (Plug Housing)
- Current Rating: 5A (Power Application)
- Material Rating: Polyester, UL 94V-0
- Operating Temp: -40°C to +105°C
-
Molex 09-50-8063 KK 396 Receptacle Housing | 6-Pin, 3.96mm Pitch, UL 94V-0
-
Part Number: Molex 09-50-8063 (Also known as 0009508063)
-
Series: KK® 396 (Series 41695)
-
Configuration: 6 Positions, Single Row
-
Pitch: 3.96mm (0.156″)
-
Connector Type: Receptacle Housing (Female)
-
Material Rating: Polyester, UL 94V-0 (High Flammability Resistance)
-
Features: Friction Lock Ramp & Polarized Design
-
Application: Power, Wire-to-Board Systems
-
Note: Crimp terminals are sold separately.
-
-

Molex 0511102051 Milli-Grid Receptacle Housing | 2.00mm Pitch, 20-Pin, Dual Row, Locking Ramp
Part Number: Molex 0511102051 (Series: Milli-Grid 51110)
Configuration: 20 Positions, Dual Row (2 x 10)
Pitch: 0.079″ (2.00mm) High-Density Spacing
Connection Type: Wire-to-Board Receptacle (Female Socket Housing)
Key Features: Integrated Locking Ramp & Polarizing Key
Material Rating: Glass-Filled Polyester, Black (Operating Temp: -40°C to 105°C)
Note: Crimp terminals/contacts are sold separately. -

Molex 33482-3601 MX150 Sealed Male 6-Pin Connector | Crimp, 3.5mm Pitch | IATF 16949 Certified Supply
Molex 33482-3601 is a 6-pin male connector from the sealed MX150 series, featuring a 3.5mm pitch and crimp termination. IATF 16949 certified, it ensures reliable performance in automotive and industrial environments.
-

502225-0801 PCB Headers and Receptacles 2.50mm, 3.50mm, 3.70mm CMC Header, Right-Angle, 80 Circuits MOLEX
502225-0801 MOLEX CMC Header | Right-Angle 80-Position | 2.50/3.50/3.70mm Pitch | T2 Copper Alloy Contact
-

87568-1693 Milli-Grid Receptacle Housing | 16-Position Dual Row |0.38µm Gold (Au) Selective Plating| MOLEX
87568-1693 MOLEX Milli-Grid Receptacle Housing | 16-Position Dual Row | 0.38µm Gold Plating | IDT Locking System
